FABLOK®
2x2 FABRIC
DISPLAY STAND
Assembly Instructions
• 4 x FABLOK® SEG Frame 1000mm (w)
• 1 x Arch Mounting Kit
• 1 x 180° Linking Connector
• 2 x Half Feet Pair
A) Arch Mounting Kit
(On Top)
x1
B) 180˚ Invisible Foot
x1
C) Half Feet Pair
x2
01733 511030
sales@xldisplays.co.uk
A
*
B
C
*
*
C
C
*
C
Advertisement
Related Manuals for XL displays FABLOK 2x2 FABRIC DISPLAY STAND
Summary of Contents for XL displays FABLOK 2x2 FABRIC DISPLAY STAND
- Page 1 FABLOK® 2x2 FABRIC DISPLAY STAND Assembly Instructions • 4 x FABLOK® SEG Frame 1000mm (w) • 1 x Arch Mounting Kit • 1 x 180° Linking Connector • 2 x Half Feet Pair A) Arch Mounting Kit (On Top) B) 180˚ Invisible Foot C) Half Feet Pair 01733 511030 sales@xldisplays.co.uk...
- Page 2 FABLOK® SEG DISPLAY STAND Assembly Instructions Unfold bottom frame section Attach stabilising feet Connect height extenders (2250mm (h) frames only) Unfold top frame section Add top frame to bottom frame section Connect support pole(s) Install silicone edge graphics 01733 511030 sales@xldisplays.co.uk...
- Page 3 FABLOK® CUPBOARD Assembly Instructions Ensure all 1m wide frames are assembled, have graphics installed and stabilising feet removed Add 90-degree bottom connectors on both rear corners Add 90-degree top connectors on both rear corners Attach bottom door bar at the front of the cupboard Mount access panel on hinge connectors...
- Page 4 FABLOK® EXHIBITION ARCH INLINE MOUNTING Assembly Instructions Ensure all 1m (w) frames are assembled with graphics installed Lay arch roof on the floor and remove stabilising feet Organise the brackets for ‘inline’ mounting Connect the brackets to each corner of the arch roof Lift the arch roof into position to secure in place...
- Page 5 FABLOK® EXHIBITION ARCH ONTOP MOUNTING Assembly Instructions Ensure all 1m (w) f rames are assembled with graphics installed Lay arch roof on the floor and remove stabilising feet Organise the brackets for ‘ontop’ mounting Connect the brackets to each corner of the arch roof Lift the arch roof into position to secure in place...
- Page 6 FABLOK® 180 DEGREE 330mm 201mm CONNECTOR Assembly Instructions Align two FABLOK® frames 180° Connector (No Visible Foot) 180° Connector With Half Foot 180° Connector With Full Foot Remove stabilising feet and add linking connector/foot Add top connector to secure frames Insert plastic clips to pinch two frames together 01733 511030...
- Page 7 FABLOK® T-CONNECTOR Assembly Instructions Remove stabilising feet and align three FABLOK® frames in a T-configuration Lift the frames one-by-one to mount the T-connector Insert the top connector to secure the three frames 01733 511030 sales@xldisplays.co.uk...
- Page 8 FABLOK® 90 DEGREE CONNECTOR Assembly Instructions Align two FABLOK® frames in a 90° configuration and remove stabilising feet Lift the frames one-by-one to mount the bottom connector Insert the top connector to secure frames Mount the clear plastic clips top and bottom to secure the frames together 01733 511030 sales@xldisplays.co.uk...
