Eurostand Pop Up Counter 2x2
Assembly Instructions
1
3
available for assembly.
Place magnetic rails
vertically into hubs
and let snap into place.
2
4
www.xldisplays.co.uk
01733 511 030
Erect frame structure
ensuring centre magnetic
rods are connected.
Affix flexible magnetic rails
to centre hubs to form curve
shape, either end of pop up
frame.
Advertisement
Table of Contents
Related Manuals for XL displays Eurostand Pop Up Counter 2x2
Summary of Contents for XL displays Eurostand Pop Up Counter 2x2
- Page 1 Eurostand Pop Up Counter 2x2 www.xldisplays.co.uk Assembly Instructions 01733 511 030 Erect frame structure available for assembly. ensuring centre magnetic rods are connected. Place magnetic rails Affix flexible magnetic rails to centre hubs to form curve vertically into hubs shape, either end of pop up and let snap into place.
- Page 2 Eurostand Pop Up Counter 2x2 www.xldisplays.co.uk Assembly Instructions 01733 511 030 The assembled structure Insert the lower and middle is now ready to accept the shelves. Slightly angle the shelves. shelves to assist location. The shelves align together as illustrated above.
- Page 3 Eurostand Pop Up Counter 2x2 www.xldisplays.co.uk Assembly Instructions 01733 511 030 Affix both ends of the Open up the laminated table Secure the table top in place graphic to the rear top, align slots and channel in by wrapping the velcro (on...
