Installation instructions
Ethernet module
KERN KUM-04
Type TYKUM-04-A
Version 1.1
2025-01
GB
You can also find the current version of these instructions online at
https://www.kern-sohn.com/shop/de/DOWNLOADS/
Under the heading Operating instructions
KERN & Sohn GmbH
Ziegelei 1
72336 Balingen-Frommern
Germany
+0049-[0]7433-9933-0
+0049-[0]7433-9933-149
info@kern-sohn.com
TYKUM-04-A-IA-e-2511
Advertisement
Table of Contents
Related Manuals for KERN KUM-04
Summary of Contents for KERN KUM-04
- Page 1 KERN & Sohn GmbH Ziegelei 1 +0049-[0]7433-9933-0 72336 Balingen-Frommern +0049-[0]7433-9933-149 Germany info@kern-sohn.com Installation instructions Ethernet module KERN KUM-04 Type TYKUM-04-A Version 1.1 2025-01 You can also find the current version of these instructions online at https://www.kern-sohn.com/shop/de/DOWNLOADS/ Under the heading Operating instructions...
-
Page 2: Table Of Contents
Ethernet module Version 1.1 2025-01 Installation instructions Table of contents Scope of delivery ................... 3 General information and safety instructions ..........3 Technical data ....................4 Default settings ....................4 Installation ...................... 4 Installing the interface in the housing ..................4 5.1.1 Opening the terminal ........................ -
Page 3: Scope Of Delivery
Scope of delivery • Ethernet module • Interface cable (5 m) • RJ45 plug General information and safety instructions ⚠ DANGER Electric shock due to contact with live components Electric shock leads to serious injury or death Disconnect the appliance from the mains voltage before opening it. ... -
Page 4: Technical Data
Technical data CORE TYKUM-04-A TCP server Work mode TCP/IP Network protocol Network IP assignment Static/DHCP Internet Protocol Version IPv4 Default settings Parameters Standard setting Static IP 192.168.178.150 Subnet mask 255.255.255.0 Gateway 192.168.178.1 Username admin Password admin Port Installation INFORMATION • Always follow the instructions in this manual before starting work. •... - Page 5 NOTE Make sure that you do not damage any cables (e.g. by tearing them off or pinching them). Carefully open both halves of the terminal. TYKUM-04-A-IA-e-2511...
-
Page 6: Overview Of The Circuit Board
5.1.2 Overview of the circuit board The circuit board of certain display devices offers several slots for KERN accessories, with which you can expand the range of functions of your device if required. You can find information on this on our homepage: www.kern-sohn.com The illustration above shows examples of different slots. -
Page 7: Installation Of The Module
5.1.3 Installation of the module 1. Open the terminal (see section ).5.1.1 2. Remove the module from the packaging. 3. Unscrew the screws from the sleeves of a size L, 6-pin slot. 4. Attach module. TYKUM-04-A-IA-e-2511... - Page 8 As standard, there is a free prepared cable gland with a sealing cap on the ter- minal. An additional cable gland is closed with a screw. Optional accessories are required to use this cable entry. You can find information on this on our homep- age: www.kern-sohn.com TYKUM-04-A-IA-e-2511...
- Page 9 7. Remove the sealing pin from the cable gland. 8. Disconnect the interface cable on one side and expose the cable cores. TYKUM-04-A-IA-e-2511...
- Page 10 11. Guide the sealing cap over the protruding interface cable. 12. Connect the RJ45 plug to the interface cable according to the cable colours. NOTE When installed in the factory by KERN, the wiring in the connector is carried out in accordance with T568B Colour...
-
Page 11: Closing The Terminal
13. Tighten the sealing cap of the cable gland. 14. Plug the interface cable into the Ethernet connection of the module. 15. The module has been installed. 5.1.4 Closing the terminal 1. Check module for tight fit. NOTE Make sure that you do not damage any cables (e.g. by tearing them off or pinching them). -
Page 12: Connecting The Interface
Please note that all three commands, JNEA, JNEK and JNEG, must be entered in strict sequence to finalise the Ethernet interface setting. A detailed description can be found in the "KERN Communications Protocol" manual, available in the download area on our KERN homepage (www.kern-sohn.com) -
Page 13: Via The Configuration Page
5.3.2 Via the configuration page The configuration page can be called up in the address bar under the IP address of the module. After entering the user name and password (see section4 ), the default settings can be changed. NOTE ... -
Page 14: Small Breakdown Service
6 Small breakdown service Error Remedy • Ensure that the scales are switched on Connection cannot be established • Ensuring the cable connection • Check wiring at the plug • Disconnect the scales from the power supply (mains + No communication pos- sible after changing the battery) for a few minutes and restart IP address via KCP...
