Installation Instructions
Alibi-Memory Module with Real Time
Clock
KERN YMM-06
Type TYMM-06-A
Version 1.0
2023-09
GB
The current version of these instructions can also be found online under:
https://www.kern-sohn.com/shop/de/DOWNLOADS/
under the rubric Instruction manuals
KERN & Sohn GmbH
Ziegelei 1
72336 Balingen-Frommern
Germany
+0049-[0]7433-9933-0
+0049-[0]7433-9933-149
info@kern-sohn.com
TYMM-06-A-IA-e-2310
Advertisement
Table of Contents
Related Manuals for KERN YMM-06
Summary of Contents for KERN YMM-06
- Page 1 KERN & Sohn GmbH Ziegelei 1 +0049-[0]7433-9933-0 72336 Balingen-Frommern +0049-[0]7433-9933-149 Germany info@kern-sohn.com Installation Instructions Alibi-Memory Module with Real Time Clock KERN YMM-06 Type TYMM-06-A Version 1.0 2023-09 The current version of these instructions can also be found online under: https://www.kern-sohn.com/shop/de/DOWNLOADS/...
-
Page 2: Table Of Contents
Alibi-Memory Module with Real Time Clock Version 1.0 2023-09 Installation Instructions Contents Scope of delivery ................... 3 General and safety information ..............3 Installation ...................... 4 Opening the terminal ........................ 4 Overview of the circuit board ....................5 Installing the Memory Module ....................6 Installing the Real Time Clock .................... -
Page 3: Scope Of Delivery
1 Scope of delivery • Alibi-Memory Module YMM-04 • Real Time Clock YMM-05 2 General and safety information ⚠ DANGER The electrical shock caused by touching live components An electrical shock results in serious injury or death. Before opening the device, disconnect it from the power source. ... -
Page 4: Installation
3 Installation INFORMATION • It is important to follow the instructions in this manual before starting work. • The illustrations shown are examples and may differ from the actual product (e.g. positions of the components). 3.1 Opening the terminal 1. Disconnect the device from the power source. 2. -
Page 5: Overview Of The Circuit Board
3.2 Overview of the circuit board The circuit board of certain display devices offers several slots for KERN accessories, which allow you to extend the range of functions of your device if necessary. Information on this can be found on our homepage: www.kern- sohn.com... -
Page 6: Installing The Memory Module
3.3 Installing the Memory Module 1. Open the terminal (see chapter 3.1). 2. Remove the memory module from the packaging. 3. Plug the module into a size S, 6 pin slot. 4. The module has been installed. TYMM-06-A-IA-e-2310... -
Page 7: Installing The Real Time Clock
3.4 Installing the Real Time Clock 1. Open the terminal (see chapter 3.1). 2. Remove the Real Time Clock from the packaging. 3. Plug the Real Time Clock into a size S, 5 pin slot. 4. The Real Time Clock has been installed. TYMM-06-A-IA-e-2310... -
Page 8: Closing The Terminal
3.5 Closing the terminal 1. Check the memory module and real time clock for a tight fit. NOTICE Make sure that you do not damage any cables (e.g. by tearing them off or pinching them). Make sure that any existing seals are in their intended place. -
Page 9: Description Of The Components
4 Description of the components The Alibi memory module YMM-06 consists of the memory YMM-04 and the real time clock YMM-05. Only by combining the memory and the real time clock all the functions of the Alibi memory can be accessed. -
Page 10: Protection Of Stored Legally Relevant Data And Data Loss Prevention Measures
6 Protection of stored legally relevant data and data loss prevention measures • Protection of stored legally relevant data: o After a record is stored, it will be read back immediately and be verified byte by byte. If error is found that record will be marked as an invalid record. -
Page 11: Trouble Shooting
7 Trouble shooting INFORMATION To open a device or to access the service menu, the seal and thus the calibration must be broken. Please note that this will result in recalibration, otherwise the product may no longer be used in the legal- for-trade area.
