- Page 1 Touch screen programmable thermostat 24811460 Installer and user manual TA/600...
-
Page 2: General Precautions
General Precautions • Read the instructions carefully before beginning the installation and carry out the actions as specified by the manufacturer. • The installation, programming, commissioning and maintenance of the product must be carried out only by qualified technical personnel, correctly trained with regard to respecting the regulations in force, including the implementation of accident prevention measures and the disposal of packaging. -
Page 3: Installation
Installation Package contents Main unit 2 covers 2 hole-blanking adapters 2 screws for fastening to recessing back-box Support A Support B Support C Support D The supports and hole-blanking adapters can be used in suitable combinations to enable the device to be adapted to most of the domestic installation front plates on the market, using the notes on the following pages. - Page 4 How to combine/adapt the supports for domestic installations BTICINO front plates Support A (Light series, Light Tech series, Living International series) VIMAR front plates (Plana series, Eikon series) LEGRAND front plates Vela series (Vela Quadra, Vela Tonda), Cross series GEWISS front plate Support A Playbus series (Playbus, Playbus Young)
- Page 5 VIMAR front plates Support B Idea series (Idea, Idea Rondò) ABB front plate Support B (Elos series) GEWISS front plate Support B (SYSTEM series) BTICINO front plate (Axolute series, Luna series)
- Page 6 BTICINO front plate Support C (Livinglight Quadre) VIMAR front plate (ARCHÉ series) BTICINO front plate Support C (Livinglight Tonde) GEWISS cover plate (CHORUS series) AVE front plate Support D (44 series) BTICINO front plate (Livinglight AIR)
-
Page 7: Assembly Sequence
Assembly sequence Install the unit in a position which is suitable for cor- rect room temperature measurement, for example on an internal wall. Avoid installation in alcoves, behind doors or curtains, or near heat sources. If the support needs to be separated from the main unit, use a screwdriver for leverage at the point shown in figure E. -
Page 8: Electrical Connections
Electrical connections The connections are made ac- 230V~ cording to the type of equipment 50 Hz controlled by the programmable thermostat. Mains power supply wires VALVE N = neutral – L = live CLOSED Relay contacts OPEN NC = normally closed contact C = common NO = normally open contact Loads... -
Page 9: Description Of Device
Description of device ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ① ⑦ Screen lock on System in frost-protection mode ② ⑧ NIGHT program in operation The arrow indicates the active user profile ③ ⑨ ECO program in operation Button to access device set-up ④... -
Page 10: Operation Of Device
Operation of device When first turned on A the programmable thermostat is in heating mode and the Comfort program is on; the temperature measured is displayed. NOTE. The first touch on the screen turns on the backlighting and does not carry out any command. Setting date and time Briefly touch the area highlighted in figure A to display the current time;... - Page 11 Changing the system's operating mode Touch the area shown in figure D and continue touching until a beep indicates the mode is changed between: System in Heating mode System in Cooling mode System off System in Frost-protection mode When the system is off ( ), the image in figure E is displayed on the screen for a few seconds, to indicate that the system is off;...
- Page 12 Each time it is pressed, it shows the program in activation and the pre-set desired temperature for a few seconds H I; then the temperature detected reappear. Exclusion from thermal control To activate this mode press button until the icon appears. If the system is in "Heating"...
-
Page 13: Unlocking The Screen
Changing the pre-set temperature levels With any heat management program active (Eco, Com- fort, Night), press and hold down the area highlighted in figure A until the screen in figure B appears showing the name of the program to be changed. arrows B to change the pre-set Press on the temperature C for the program displayed. - Page 14 Configuration of general parameters of the device button A gives access to When the device is in "System off" mode (page 11), holding down the the device's configuration screens B. Note. After accessing the configuration screen, press button to display in sequence the parameters to be configured.
- Page 15 The first number flashes E; use the arrows to en- ter the first digit of the code, touch the area highlighted E to move on to the next digit; pressing button any time means the code entered is considered valid and you move on to the next parameter to be configured.
- Page 16 in external temperature and commands the switching on of the system as shown Set-point + differential in figure J. Set-point Press the button to move on to the next parameter to be configured. Set-point – differential Time Proportional Integral Algorithm ( If, on screen H, the proportional integral algorithm type has been chosen, the screen in figure K is displayed.
-
Page 17: Screen Backlighting
button in figure N to be able to enter Press the the value of the proportional band, using the arrows O. Press the button to move on to the next parameter to be configured. Set-point Time Cycle duration Minimum ON Proportional Prog. -
Page 18: Adjusting Display Brightness
Adjusting display brightness arrows C. Change the screen brightness using the O= Backlighting always off. Press the button to move on to the next parameter to be configured. Buttons beep Choose whether to activate/deactivate the buttons beep arrows D. using the Press the button to move on to the next parameter to be configured. -
Page 19: Technical Features
Technical Features • Power supply: 230 Vac 50/60Hz. • Consumption: 16mA. • Autonomous life without power supply: about 10 hrs. • Relay: max. voltage 250 V, max. current 5A with resistive load (2A with inductive load). • Type of action: 1B-U. •... - Page 20 www. came.com Came S.p.A. Via Martiri Della Libertà, 15 Via Cornia, 1/b - 1/c 31030 Dosson di Casier 33079 Sesto al Reghena Treviso - Italy Pordenone - Italy (+39) 0422 4940 (+39) 0434 698111 (+39) 0422 4941 (+39) 0434 698434...
