Summary of Contents for Qoltec 52488
- Page 1 Model: 52488...
- Page 2 Operating Instructions Intelligent charger for AGM, GEL and LiFePO4 batteries with 12V battery repair and testing function...
-
Page 3: About The Product
It allows the testing of 12 V batteries and offers many protective functions. The integrated charge management system ensures optimal charge and discharge curves for lead-acid and LiFePO4 batteries. Product: 52488 Output current : 0-6A Output voltage : 13.8-15V... -
Page 4: Battery Charging Procedure
Selecting the right charging mode ensures optimal charging and prolongs the life of the battery. Standard charging modes Charging mode for cars : Suitable for ordinary lead-acid batteries and maintenance-free batteries. AGM Start/Stop charging mode : A specialised charging mode optimised for AGM batteries used in vehicles with start/stop systems. - Page 5 The charger will automatically detect the current state of the battery and the ambient temperature and then adjust the charging process. Monitor the LCD display. When the battery is fully charged, the LCD display will show the charge level and the indicator light will be on continuously. Step 5 : Completion of Charging When fully charged, the LCD display will show full charge and the indicator light will always be on.
- Page 6 charge soon charging begins. Long charging Sulphation Stop Charging if the Battery is times Battery: A battery that Hot: If the battery becomes enough has not been used for a excessively during long time can become charging, stop charging sulphated, making immediately prevent...
-
Page 7: Battery Testing Procedure
Notes: Make sure you follow all safety rules when checking and topping up the electrolyte and when using the repair mode. Regular use and maintenance of batteries can help prevent problems associated with long charging times. If the problem persists, contact the service or customer service department of the charger manufacturer for further assistance. - Page 8 1) Clamp the red terminal of the tester to the positive ("+") terminal of the battery under test. 2) Tighten the black terminal on the negative ("-") terminal of the battery under test. 3) Ensure that the tester display lights up when the terminals are tightened.
- Page 9 3) If the battery is charged or discharged, the tester will display a message that the battery needs to be charged and tested again. 7. Resetting the Test (in the event of an error) 1) If any option error occurs, disconnect the terminal cable. 2) Reconnect the terminals to the battery to reset the parameters.
- Page 10 The internal resistance of a lead battery is complex and includes various components. There is no strict relationship between internal resistance and battery capacity. A sudden increase in internal resistance or a decrease in conductivity can signal the approaching end of battery life. 4.
-
Page 11: Lcd Display
7. Car Battery Voltage Stabilisation: Before carrying out a test on a car battery, wait for the voltage to stabilise, especially if the battery is fully charged. 8. Safe Use: Check that the insulation of the test device is intact and free from damage before use. - Page 12 24AH 290A 100AH 670A 25AH 295A 120AH 700A 26AH 300A 150AH 750A 28AH 310A 200AH 950A 31AH 320A...
- Page 13 ATTACHMENT...
