1
2
3
15/04/24
09/05/24
XX/XX/24
ELVIN
ELVIN
NAME
EN IMPORTANT - These instructions are for your safety. Please read
through them thoroughly prior to handling the product and retain
them for future reference. This product is only suitable for well
insulated spaces or occasional use.
V10524_5059340986869_MAND2_2324
5059340986869_MNL_IN_V02.indd 1
5059340986869_MNL_IN_V02.indd 1
4
5
XX/XX/24
XX/XX/24
NAME
NAME
Impala Ref: PRJ30510
EAN: 5059340986869
Page Size: A5
EN Radiant panel
electric radiator
5059340986869
5059340986654
5059340986661
5059340986678
5059340986753
5059340986777
5059340986791
5059340986814
5059340986838
5059340986845
5059340986876
5059340986890
09/05/2024 2:30:17 pm
09/05/2024 2:30:17 pm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kingfisher HD10-23ME
Summary of Contents for Kingfisher HD10-23ME
- Page 1 EAN: 5059340986869 15/04/24 09/05/24 XX/XX/24 XX/XX/24 XX/XX/24 Page Size: A5 ELVIN ELVIN NAME NAME NAME Impala Ref: PRJ30510 EN Radiant panel electric radiator 5059340986869 5059340986654 5059340986661 5059340986678 5059340986753 5059340986777 5059340986791 EN IMPORTANT - These instructions are for your safety. Please read 5059340986814 through them thoroughly prior to handling the product and retain 5059340986838...
- Page 2 EN Parts 01. x1 02. x4 03. x4 EN You will need EN Contents Safety Guarantee Installation Function & setting Care & maintenance 5059340986869_MNL_IN_V02.indd 2 5059340986869_MNL_IN_V02.indd 2 09/05/2024 2:30:17 pm 09/05/2024 2:30:17 pm...
-
Page 3: Before You Start
EN Safety • Children of less than 3 years should be kept away unless Before you start continuously supervised. • For domestic use only. • Children aged from 3 years • Never allow children or and less than 8 years persons unable to operate the shall only switch on/off the appliance safely to use this... - Page 4 SUCH AS A TIMER, • If the supply cord is damaged, it must OR CONNECTED TO be replaced by the A CIRCUIT THAT IS manufacturer, its service REGULARLY agent or similarly qualified SWITCHED ON AND persons in order to avoid a OFF BY THE UTILITY.
-
Page 5: Technical Data
Technical Data Model HD10-23ME / HD15-23ME / HD20-23ME Voltage & Frequence 220-240 V~ 50 Hz Power (Watt) 840-1000 W / 1250-1500 W / 1680-2000 W Product dimension L x H x W 540 x 450 x 120 / 690 x 450 x 120 / 840 x 450 x 120... -
Page 6: Installing The Appliance
EN Installation Installing the appliance • This appliance is for indoor use only. MINIMUM DISTANCE • Observe the minimum distances as shown in Fig. 1. • The power connection is made by ≥300mm the 2 cables via a connection box. In places such as wet bathroom, ≥250mm laundry, kitchen, install the appliance... - Page 7 IMPORTANT: THE WIRES IN THE MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE: Blue – Neutral Brown – Live The blue wire must be connected to the terminal marked with an N or coloured black. The brown wire must be connected to the terminal marked with an L or coloured red.
- Page 8 Ceiling (DRY) OUTSIDE ZONES Window ZONE recess ZONE 0.6m 0.6m 2.25m ZONE ZONE THIS PRODUCT IS SUITABLE FOR BATHROOMS ZONE 2 AND OUTSIDE ZONE; * Full details can be found in the current IET Wiring Regulations (BS7671). To hang the heater on the wall: 1.
- Page 9 EN Installation ≥300 mm ≥250 mm ≥250 mm ≥250 mm 01. x1 5059340986869_MNL_IN_V02.indd 9 5059340986869_MNL_IN_V02.indd 9 09/05/2024 2:30:18 pm 09/05/2024 2:30:18 pm...
- Page 10 03. x4 ≥570 mm 02. x4 5059340986869_MNL_IN_V02.indd 10 5059340986869_MNL_IN_V02.indd 10 09/05/2024 2:30:18 pm 09/05/2024 2:30:18 pm...
- Page 11 5059340986869_MNL_IN_V02.indd 11 5059340986869_MNL_IN_V02.indd 11 09/05/2024 2:30:19 pm 09/05/2024 2:30:19 pm...
- Page 12 EN Functions & Settings 01 LCD Display Functions of the icons on the LCD: Symbol Function Mode standby (the appliance doesn't work but with power on). Mode anti-freeze (the appliance maintains the temperature around 7 °C). Mode comfort (set the desired temperature). Mode ECO (ECO maintains the temperature that is 3.5 °C lower to comfort temperature.
-
Page 13: Control Panel
02 Control Panel Touch icon Function Standby Short press to enter setting menu: MENU 1. Time setting; 2. program modes setting; 3. Window detection function. Press for 3 seconds, activate / inactivate keyboard lock. Confirm button Under working status: shift working mode (Comfort/Eco / Program modes or Pilot wire/ Anti-freeze) Under setting status: shift options by left and right Under working status: adjust temperature... - Page 14 The interface of program mode and Pilot wire mode are as below: Program mode Pilot wire NOTE: For the program mode, mode setting and mode selection is separated. If you want to set the program mode, press MENU to enter setting menu to choose program mode setting and press OK to enter setting interface.
- Page 15 2. Program mode setting • Press MENU to enter setting interface, and to choose program mode setting . When flashes, press OK to enter setting interface. • Under program mode, you can choose from 7 pre-set 24-hour programs (P1-P7) for each day of week. NOTE: The 7 pre-set 24-hour programs (P1-P7) are programable.
- Page 16 Hour (01 is for hour 1 to hour 2, and so on, 24 is for hour 24 to hour 1) 2. After setting of 24 hours, press or OK, it will automatically save and go back to previous setting interface. •...
- Page 17 With distance control option With adaptive start control With working time limitation With black bulb sensor Contact details Kingfisher International Products Limited, 1 Paddington Square, London, W2 1GG, United Kingdom Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands 5059340986869_MNL_IN_V02.indd 17 5059340986869_MNL_IN_V02.indd 17...
- Page 18 With distance control option With adaptive start control With working time limitation With black bulb sensor Contact details Kingfisher International Products Limited, 1 Paddington Square, London, W2 1GG, United Kingdom Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands 5059340986869_MNL_IN_V02.indd 18 5059340986869_MNL_IN_V02.indd 18...
- Page 19 With distance control option With adaptive start control With working time limitation With black bulb sensor Contact details Kingfisher International Products Limited, 1 Paddington Square, London, W2 1GG, United Kingdom Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands 5059340986869_MNL_IN_V02.indd 19 5059340986869_MNL_IN_V02.indd 19...
- Page 20 Do not use water, liquids, abrasive detergents or chemicals (alcohol, petrol, etc.) for cleaning. Manufacturer: EN www.diy.com www.screwfix.com UK Manufacturer: www.screwfix.ie Kingfisher International Products Limited, To view instruction manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom visit www.kingfisher.com/products EU Manufacturer: Kingfisher International Products B.V.,...
