NightStick USB-4510 Series Instruction Manual

USB-4510 Series
Instruction Manual
Bayco Products Inc. (BPI)
640 South Sanden Blvd. • Wylie, TX 75098 • USA
1-800-233-2155 • 1-469-326-9400
www.nightstick.com
EN
WARNINGS
y NOT FOR USE IN HAZARDOUS ENVIRONMENTS
y DO NOT use in explosive atmospheres, near flammable liquids, or where
explosion proof lamps are required.
y DO NOT use in the proximity of vehicles or equipment when there is a
risk of flammable liquids coming into contact with the flashlight.
y DO NOT expose the battery to water or salt water, or allow the battery
to get wet.
y Keep out of the reach of children.
CHARGING THE LIGHT
CHARGER INPUT: 5 VDC Max
WARNING: TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE,
DO NOT ATTEMPT TO CHARGE THIS PRODUCT IN THE HAZARDOUS
ENVIRONMENT. THIS TASK MUST ONLY BE PERFORMED IN AN AREA
KNOWN TO BE NON-HAZARDOUS.
Fully charge the light before the first use, if the battery is new or has not
been used for several months. For best performance, charge the light when the
headlamp beam starts to dim.
y Use only the supplied Nightstick USB cable.
y Locate the USB port on the side of the headlamp, remove the rubber
USB port cover, and plug the USB cable into the headlamp's USB port.
y The total time to full charge varies depending on the remaining charge
in the battery pack.
y When the USB cable is connected, the charging indicator lights on the
top will glow red while the light is charging and then turn green when it is
fully charged. When the cable is disconnected, the charging indicator lights
will turn off.
OPERATION
The two switches control all functions on the headlamp. The below
instructions apply while wearing the headlamp.
WHITE FLOODLIGHT SWITCH - RIGHT SIDE
y Press and release to turn the floodlight to low-brightness.
y Press quickly a second time (within 1.5 seconds) to change the floodlight
to high-brightness.
y Press and release from any mode after it has been on for more than 1.5
seconds to turn the floodlight off.
RED/GREEN FLOODLIGHT SWITCH - LEFT SIDE
y Press and release to turn the red floodlight on.
y Press quickly a second time (within 1.5 seconds) to change the floodlight
to green.
y Press and release from any mode after it has been on for more than 1.5
seconds to turn the floodlight off.
BATTERY SHUT OFF MODE
y Press and hold both switches at the same time for 3 seconds to enable
or disable battery shut off mode.
y After three seconds the white floodlight will flash on and off 1 time to
confirm a change in the battery safe mode.
NOTE: The battery safe mode reverts to disabled when battery is fully
discharged.
MOUNTING INSTRUCTIONS
MOUNTING (USB-4510M)
y Squeeze the sides of the spring clip to open.
y For thin strap material, weave it through the retention slot on the back of
the clip for a more secure hold.
y Slide upward on a tactical vest, backpack, or accessory using a MOLLE
or PALS system and close the clip to secure it in place.
PSA MOUNTING (USB-4510B/F)
y Ensure mounting surface is clean and oil-free. Use included alcohol wipe
to clean the surface.
y Determine best location that does not interfere with brim.
y Remove adhesive backing.
y Firmly press mount into place and hold for 30-60 seconds.
IMPORTANT: WAIT 24 HOURS FOR ADHESIVE TO REACH MAXIMUM
STRENGTH.
USB-4510B / USB-4510F
2 YEAR WARRANTY
Bayco Products, Inc. warrants this product to be free from defects in
workmanship and materials to the original purchaser for 2 years from the date
of purchase, and includes the LEDs, housing, lenses, electronics, switches,
rechargeable batteries and chargers. Bulbs (other than LEDs) are covered for 90
days from the date of purchase.
We will repair or replace this product should we determine it to be defective.
This is the only warranty, expressed or implied, including any warranty of
merchantability or fitness for a particular purpose.
For a complete copy of the warranty, go to www.baycoproducts.com/bayco-
product-support/warranties. Retain your receipt for proof of purchase.
AVERTISSEMENTS
y NE PAS UTILISER AU-DESSUS D'ENDROITS DANGEREUX.
y NE PAS utiliser ce produit dans une atmosphère explosive, à proximité
de liquides inflammables, ou dans des endroits exigeant un éclairage
antidéflagrant.
y NE PAS utiliser ce produit à proximité de véhicules ou d'équipement
quand des liquides inflammables pourraient entrer en contact avec la
lampe torche.
y NE PAS exposer la batterie à l'eau ou à l'eau salée, et ne pas laisser la
batterie se mouiller.
y Ne pas laisser pas à la portée des enfants
CHARGER LA LAMPE
ENTRÉE CHARGEUR: 5 VDC Max
AVERTISSEMENT : POUR ÉVITER L'INFLAMMATION D'ATMOSPHÈRE
DANGEREUSE, NE PAS ESSAYER DE CHARGER CE PRODUIT DANS
UNE ZONE DANGEREUSE. CETTE TÂCHE DOIT ÊTRE EFFECTUÉE
UNIQUEMENT DANS UNE ZONE NON DANGEREUSE.
Charger complètement la lampe avant la première utilisation ou si la pile
est neuve ou n'a pas été utilisée pendant plusieurs mois. Pour de meilleurs
résultats, charger la lampe lorsque le faisceau de lumière commence à faiblir.
y Utiliser uniquement le cable USB Nightstick.
y Localisez le port USB sur le côté de la lampe frontale, retirez le
couvercle en caoutchouc du port USB et branchez le câble USB dans le
port USB de la lampe frontale.
USB-4510M
FR
