- Page 1 Safety and Operator Manuel For DRS2022-H8 and DRS2022-H12 Original Instructions February 2024...
- Page 2 We hope your experience with the Dragon Saw will be satisfying and a trouble-free experience. From the people who designed and make it, ACG Saws & Tools of Canada Inc. 2590 Sheffield Road, Ottawa Ontario K1B 3V7 Canada +1 (613) 749-1525 +1 (877) 749-1525 DRS2022-H8 | DRS2022-H12 2 | P a g e...
-
Page 3: Safety And Operation
• Tools shall be inspected periodically for damaged parts or missing labels. Only parts recommended by the manufacturer shall be used. • Do not discard safety instruction; give them to the operator. DRS2022-H8 | DRS2022-H12 3 | P a g e... - Page 4 • Before switching you saw back on, make sure all safety elements are installed. • Only trained and authorised personnel shall remove and refit safety components. DRS2022-H8 | DRS2022-H12 4 | P a g e...
- Page 5 • Only cut concrete, masonry, and stone. • Hold the saw correctly with both hands and proper footing. • Make sure Guide plates and rollers are in good condition. If not contact manufacture and replace them. DRS2022-H8 | DRS2022-H12 5 | P a g e...
- Page 6 Sharp Edges • Always wear protective gloves. • Avoid contact with the saw blade to prevent cutting of hands. • Cutting with these tools creates sharp edges. DRS2022-H8 | DRS2022-H12 6 | P a g e...
- Page 7 • Hose are ½” steel braided Hydraulic hose rated for constant pressure rating of 3000 PSI. • Male and Females coupler are ½” Flat face couplers rated for 3000 PSI of pressure. • Maximum oil temperature of 100ºC DRS2022-H8 | DRS2022-H12 7 | P a g e...
- Page 8 Remember to always replace the skid plate when replacing a blade as using an old skid plate could cause damage to the blade and void warranty on your saw. DRS2022-H8 | DRS2022-H12 8 | P a g e...
- Page 9 Using the side of a table, push down on the adjustable arm assembly until the tension on the blade is tight. Once proper tension is achieved, re-tighten the nuts on the blade guard and splash guard. DRS2022-H8 | DRS2022-H12 9 | P a g e...
- Page 10 • An incorrect sequence of cuts can lead to your blade jamming or pinching. • (e.g., for window openings, you start with the bottom cut, then the side cuts and finish with your top cut). DRS2022-H8 | DRS2022-H12 10 | P a g e...
- Page 11 2. Shut-off and disconnect your water feed. Blow out water from all lines. 3. Shut-off your Hydraulic Power Unit. Disconnect your hydraulic couplings. 4. Clean your ring saw with water and spay WD-40 on you guide rollers. DRS2022-H8 | DRS2022-H12 11 | P a g e...
- Page 12 The transmission and gear box need 20ml of oil each and make sur to completely drain it before adding new oil. Its good practice to spray oil like WD-40 on your Rollers to avoid rust when storing your equipment for a long period of time. DRS2022-H8 | DRS2022-H12 12 | P a g e...
-
Page 13: Maintenance And Troubleshooting
ACG Saws & Tools or authorised workshops Service Tools 1. Dragon Saw Multitool 2. Drive Roller Rod 3. Allen Key WAF ¼” 4. Allen Key WAG 5/32” 5. Wrench ½” 6. WD-40 Can DRS2022-H8 | DRS2022-H12 13 | P a g e... - Page 14 Pressure too high Check settings on drive unit. If necessary, install and pressure reducing valve or a flow divider Defective seal Replace seal Oil return incorrectly Check connector connected DRS2022-H8 | DRS2022-H12 14 | P a g e...
-
Page 15: Technical Data
Diameter ring blade Cutting depths Spindle speeds 510 mm (20") 407 mm (16 inches) 1289 rpm 406 mm (16") 300 mm (12 inches) 1611 rpm Cooling Water cooling (No dry cutting) DRS2022-H8 | DRS2022-H12 15 | P a g e... - Page 16 Maximum Value of sound pressure level 105.9 dB Acoustic power level 105.6 dB(A)* Scan the QR Code for Drawings and Parts List If you have any questions, contact us at Sales@Dragonsaw.ca DRS2022-H8 | DRS2022-H12 16 | P a g e...
-
Page 17: Warranty
Proof of purchase is mandatory. An authorization return number must be issued by the manufacturer before any tool may be shipped to us for repair or warranty. The manufacturer will repair the tool to its original designation at his discretion. DRS2022-H8 | DRS2022-H12 17 | P a g e...
