- Page 1 Safety and Operator Manual For DRS-2022H8 or H12 June 2022...
-
Page 2: Safety Procedures
SAFETY PROCEDURES WARNING! In order to safely work with the hydraulic ring saw you have to follow all the safety recommendations from the manufacturer and all the competent safety organisations governing your territory and area. It is mandatory and imperative that you read and comprehend the following instructions to prevent any injury or even death to the operator or any one else in your surrounding work area and property. -
Page 3: Operation
OPERATION The saw is designed to safely cut only concrete, masonry and stone. Visually inspect the saw for any defect or broken parts before using. NEVER operate a defective saw or blade. If damages or defects are noticed, have the saw repaired by trained and experienced personnel only before using. - Page 4 DANGER! All electrically operated tools should be grounded and hooked up to a ground fault protection system. All gasoline or petrol tools must be used in an outside environment. Never inside or in a confined area. Accumulation of fumes or gases will cause serious injury or death. Be vigilant and very attentive to the work being performed and to your work area.
-
Page 5: Technical Information
TECHNICAL INFORMATION Hydraulic Model 8 GPM or 12 GPM Weight without blade 29.8 lbs or 12.54 kg Width without the blade 10 1/4 in or 260 mm Height without the blade 19 in. or 482.6 mm Length without the blade 26 in. -
Page 6: Troubleshooting
TROUBLESHOOTING Problem Causes/Solution Saw will not Be certain that the power supply is hook up start turning Accumulation of heavy slurry preventing the saw from turning Seized blade guide roller Saw will not Not enough water to cool the blade start turning Blade turning to Check power supply... -
Page 7: Warranty
WARRANTY Limited Tool and parts Warranty. ACG Saws & Tools of Canada Inc. the manufacturer certifies that the tool is free from any material or workmanship defect and warrants the tool with a limited warranty for a period of one year from the date of the original purchase. Workmanship charges may apply. Subject to certain exceptions, our responsibility under the warranty is limited to the inspection and replacement of any parts that may be defective after being shipped at our plant or any other point designated by the manufacturer... - Page 8 BLADE REMOVAL GUIDE Step 1: Remove the blade guard and splash guard using the 9/16” wrench provided. Also remove the adjustable arm assembly by pulling it away from the saw. Step 2: Using the ½” wrench and the Dragon Saw Multitool that are provided, remove the smooth threaded drive roller by turning the drive roller clockwise (it is left hand threaded).
- Page 9 BLADE INSTALLATION GUIDE Step 1: With the blade guard, splash guard, smooth threaded drive roller and adjustable arm assembly removed, install the new skid plate. Once the new skid plate is installed place the new blade with grooved side down onto the lipped threaded drive roller.
- Page 10 NUMBERED PART IMAGES...
- Page 11 January-28-2022 ACG Saws & Tools of Canada Inc Hydraulic Dragon Saw Black Edition - 2022 ONLY Item # Part # Description Blade Guard Complete HDS001-2 Plastic Blade Guard HDS001 Spring HDS002 Upper Guard HDS003 Roller Guide Left Shield HDS008 Roller Guide Right Shield HDS009 Roller Guide Front Shield HDS010...
- Page 12 Valve Cap HDS074 Spring HDS075 Stem Block HDS076 O-Ring HDS077 Quad Seal HDS079 Quad Seal HDS080 Small Gear HDS082 Large Gear HDS083 85-2 1/2 Hose Assembly HDS085-2 86-1 8 GPM Cassapa Motor HDS086-1 86-2 12 GPM Cassapa Motor HDS086-2 Handle Bolt HDS087 Handle HDS088...
- Page 13 Oil Seal HDS320 Modified Oil Seal HDS321 Bearing & Seal kit - 2022 HDS322 Gear Box Complete HDS323 Water Valve Complete HDS324 DragonSaw Multitool HDS325 Skid plate HDS326 Front Cover Assembly HDS327 Pusher Bolt HDS328 Tear Drop HDS329 1/8 Brass Fitting...
