RADIO OPERATION
AM/FM
LED INDICATORS
1. Press RADIO !ON/OFF! to turn radio on; press again to turn radio off.
2. Momenta 1 ily press RADIO ! AM/FMI push button for desired broadcast band. Band LED, located
at the left of the dial scale area, will light to indicate band selected.
3. Use !TUNING! CONTROL to tune to desired station.
4. Adjust !LOUDNE&S! and !TONEI controls for preferred volume and tonal quality.
ANTENNAS
AM - A built-in ferrite rod antenna is provided for AM reception .
FM - The power cord acts as your FM antenna.
A wrapped power cord may be adequate for strong local FM reception, however , for best recep -
tion, the power cord should be stretched out to its full length . Changing position of the power cord
may improve reception.
AM/PM INDICATORS
·y-~• -, . ,.,
... -r .... ~~,,.. ........ _ ......
~
: ' " .....
~
?
2 1
TIME SET
1. Select !TIME! mode with DISPLAY select push button . Time disp lay has 24-hour forma t with
AM/PM display indicators.
NOTE : If LED above DISPLAY select push button lights up, display is not in TIME mode .
2. Press the TIME SET !HOUR! button for the correct AM/PM hour in the display Then, press
the
(MiNOTEj
button to set the exact lime .
6
APPLIANCE OUTLET:
The APPLIANCE OUTLET push buttons enable you to operate the appliance outlet in one of three
ways:
• _I
_A_U-TO-lautomatically turns on the outlet at a preset time.
• ! EVER ON I
I
OFF
I
can be set so the outlet is always on and ready to_activate any appliance
you may plug in; or it can be set so the outlet is always off until you switch 11 on.
The outlet is rated at 1500 watts maximum for appliances and 600 watts maximum for lamps and
N .
Products having higher operating ratings must not be used .
CAUTION : Extension cords and/or multiple p lug adapters of any type must not be used
on either the appliance outlet or the radio 's line cord.
AUTO
When the APPLIANCE OUTLET
I
AUTO
I
is placed in the "on" mode, the outlet will turn itself on (for a
fixed duration of 1 hour, 59 minute?) when the current time reaches the time you have preset into
) AUTO "ON"
I
AUTO TIME
I
EVER ON LED LED
INDICAT6R INDICATOR AUTO TIME LED INDICATOR
5
:,, i .. "~ - "'- ~-: · - ,.
~
: ' . : _ v ~ -·
"T j~ --- ~ \ -,
2 4, 7 1, 3
To preset
I
AUTO TIME
I
so APPLIANCE OUTLET
I
AUTO
I
will turn on automatically :
1. Select
I
AUTO TIME
I
with DISPLAY select push button . LED will light (NOTE: COUNTDOWN TIMER
must be in "off" mode to select AUTO TIME )
2. Press TIME SET
I
HOUR
I
and
I
MINUTE
I
buttons to desired AM or PM time.
3. Press DISPLAY select push button again to return display to current time . AUTO TIME LED will
turn off .
·4 . Pres s APPLIANCE OUTLET
I
AUTO
I
to "ON" position . AUTO "ON" LED will light.
5. Plug in appliance .
NOTE : if the appliance has an on/off switch, be sure to place it in the "on " position .
6 . The appliance outlet will automatically activate the appliance at your preselected time and
turn it off at the end of 1 hour and 59 minutes.
When the outlet turns on , the
I
EVER ON
I
LED will light in addition to the AUTO "ON" LED .
(NOTE: The COUNTDOWN TIMER is not functional while the appliance outlet is activated
by AUT O and , therefore ,_ it cannot be used for timing purposes.)
7. To turn the o utlet off prio r to aut o matic off time , press APPLIANCE OUTLE:T
I
AUTO
I
to
I
OFF
!
Both LED's will turn off. ·
I
AUT O TIME
I
programmed into memory is retained in memory until it is changed or there is a
p ow er interrupt ion. In fhe event of a power interruption , this unit has a built-in safety feature which
will shut off the APPLIANCE OUTLET
I
AUTO
I
and
I
AUT O TIME
I
must be reset.
7
