Page 1: Instruction Manual
UDIOVOX PECIALIZED PPLICATIONS, L.L.C. INSTRUCTION MANUAL 19” COLOR TELEVISION AVT-1928 The serial number is located on the rear of the set. For future reference, please copy the number here. Serial No._________________________________... - Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The exclamation point within an equilateral triangle is intended to alert the user to important operating and servicing instructions in the literature accompanying the appliance.
-
Page 3: Table Of Contents
Table of Contents Important Safeguards……………………………………………………………..2 Chapter1: Overview of Your equipment………………………………………..4 Your TV’s Front Panel……………………………………………………….4 Your TV’s Back Panel……………………………………………………….4 Your Remote Control………………………………………………………...5 Installing your remote control batteries……………………………….6 Notes……………………………………………………………………..6 Chapter 2: Connecting an Antenna or Cable to your TV…………………….7 Connecting an Antenna……………………………………………………...7 Connecting a Cable System………………………………………………...8 Connecting Other Pieces of Equipment……………………………………9 Safety Note…………………………………………………………………….9... -
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION EQUIPMENT AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE TV RECEIVER. opening should never be blocked by 1. Read all of these instructions. placing the television equipment on a 2. - Page 5 13. An outside antenna system should not be 18. When replacement parts are required, be located in the vicinity of overhead power sure the service technician has used lines or other electric light or power replacement parts specified by the circuits, where it can fall into such power manufacturer that have the same lines or circuits.
-
Page 6: Chapter1: Overview Of Your Equipment
Overview of your Equipment Your TV comes with a remote control. The section below summarizes the buttons, controls and terminals that you will use with your TV. Your TV’s Front Panel 1. POWER Use this button to turn your TV on or off. 2. -
Page 7: Your Remote Control
Your Remote Control 1. POWER Use this button to turn your TV on or off. Use these buttons to change channels on your TV, or select items in the menu system. 3. VOL Use these buttons to change your TV’s volume, to activate selections in the menu system, or to change audio and video settings. -
Page 8: Installing Your Remote Control Batteries
Installing your remote control batteries 1. Open the battery compartment on the back of the remote control. 2. Install two AAA-size batteries (not included) as shown. Make sure the “+” and “-“ terminals are oriented correctly. 3. Replace the cover. Notes Do not mix different types of batteries, or mix an old and a new battery. -
Page 9: Chapter 2: Connecting An Antenna Or Cable To Your Tv
For help in locating the antenna terminal, see “Your TV’s Back Panel” on page 4. If you purchased model AVT-1928 there is no antenna provided with your TV. Connecting an Antenna... -
Page 10: Connecting A Cable System
Chapter 2: Connecting to an Antenna or Cable to your TV- 7 Antennas with two sets of leads You might have two sets of leads from your antenna system, especially if you have one antenna for VHF signals and one antenna for UHF signals. If your antenna system has both a coaxial lead and twin 300 ohm leads, you must obtain a combiner (available at your local electronics store). -
Page 11: Connecting Other Pieces Of Equipment
If your cable system requires you to use a converter box for all channels, connect the incoming cable to the IN terminal on the converter box. Connect another cable between the OUT terminal on the converter box and the antenna terminal on the TV. If your cable system only requires you to use a converter box for some channels (i.e. -
Page 12: Chapter 3: Operating Your Tv
Operating Your TV Once you have connected your TV to an antenna or cable system, unplugged the TV in, and put batteries in the remote, you are ready to use the TV. The first thing you should do is program your TV so it memorizes all of the available channels. Turning Your TV On 1. -
Page 13: Changing Channels
Changing Channels You can change channels in three ways: 1. The CH buttons take you through all memorized channels, one by one. The Ch buttons will not access channels that have not been programmed into the TV’s memory. For more information about programming channels into memory, see the section “Programming your TV’s Channel Memory,”... -
Page 14: Erasing A Channel From Memory
Erasing a channel from memory 1. Tune to the channel you want to erase. 2. Press the ADD/ERA button on the remote control. The channel will turn from green to magenta to show it has been erased. Changing the TV’s channel memory with the menus You can also use the menu system to add/erase channels from memory: 1. -
Page 15: Adjusting The Video Settings
Adjusting Video Settings You may wish to adjust the video settings (e.g. contrast or color) to obtain the most pleasing picture. To do so follow these directions: 1. With the TV on, press the MENU button. 2. Use the CH buttons to select PICTURE. 3. -
Page 16: Returning To The Factory Settings
Returning to the factory settings If you would like to return to the original video settings, as they were calibrated at the factory, follow these steps: 1. Complete steps 1-3 in the “Adjusting Video Settings” section, on the previous page. 2. -
Page 17: Chapter 4: Using Timer Functions
Using Timer Functions Your TV has a built in clock, and you can set the TV to turn on and off at times that you select. You can also set your TV to turn off after counting down a certain amount of time. Accessing the Timer Menu 1. -
Page 18: Setting The On Timer
Setting the On Timer If you enter a time in the ON TIME setting, your TV will automatically turn on at that time. Follow these instructions to set the ON TIME: 1. Follow steps 1-3 in ”Accessing the Timer Menu” on the previous page. 2. -
Page 19: Canceling The On Timer Or Off Timer
3. Press the VOL button to set the hours (including AM/PM); press the VOL button to set the minutes. If you hold down either VOL button, the corresponding numbers will change more quickly. 4. When the setting is correct, use the CH buttons to select another timer function, or use the MENU button to exit this menu. -
Page 20: Chapter 5: Additional Features
Additional Features This section contains descriptions of the advanced features of your TV. Changing the Language of the On Screen Menus You can choose to display the on screen menus in English, Spanish, or French. To change the on screen language: 1. -
Page 21: About Captions
5. Wait 5 seconds, or press the MENU button twice to return to normal TV viewing. Your setting will remain intact until you change it. About captions Once you have chosen a caption setting, all available captions on that setting will be displayed when you watch TV. -
Page 22: Protection Features
Protection Features The following two features protect your TV from operating unnecessarily. Automatic Blue Screen If your television is tuned to a channel that is not receiving a signal (or is receiving a very weak signal), your TV will automatically display a blue screen instead of static. Automatic Power Off If your television does not receive a television signal for 15 minutes, it will automatically turn off. -
Page 23: Chapter 6: Troubleshooting
Troubleshooting Your Audiovox television is designed to give you trouble-free performance for many years. If you have a problem with your TV, try the solutions listed below. If the suggestions listed below do not solve your problem, contact your Audiovox dealer or an authorized Audiovox service center. You can also call Audiovox directly at (219) 266-1886. -
Page 24: Warranty
WARRANTY APPLIES TO AUDIOVOX VIDEO PRODUCT Audiovox Specialized Applications, LLC (the company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced (at the company’s option) without charge for parts and repair labor. - Page 25 HP375 Unlike household electronics, all of our products have been specifically designed and tested for the mobile environment and are only available through ASA. To order any of these products, please contact Audiovox Specialized Applications at www.asaelectronics.com or 800-688-3135. Accessories- 23...
- Page 26 This instrument is listed by Underwriter’s Labortories, Inc. It is designed and manufactured to meet rigid U.L. safety standards against X-radiation, fire, casualty and electrical hazards. Audiovox Specialized Applications, LLC 23319 Cooper Dr. Elkhart, IN 46514...
