CONTENT Safety instructions………………………………………………………………………..… Instructions on adjusting and testing…………………………….…….………………… Trouble shooting……………………………………………………….…………………… Method of software upgrading………………………………………….………………… Brief introduction and working principle of L20H3………………………………..…………. Wiring diagram……………………………………………………………..……………..Serial NO. of parts……………………………………………………………………….… Identification criteria for the bright spot and dark spot of the LCD screen………..…. Troubleshooting guide………………………………………………………………..……...
Attention: This service manual is only for service personnel to take reference with. Before servicing please read the following points carefully. Safety instructions 1.Instructions Be sure to switch off the power supply before replacing or welding any components or inserting / plugging in connection wire Anti static measures to be taken (throughout the entire production process!): a)Do not touch here and there by hand at will;...
breakage of screen glass or damage to driving circuit. Therefore it must be packed in a strong case before the transportation or handling. 2.12. For the storage make sure to put it in a place where the environment can be controlled so as to prevent the temperature and humidity from exceeding the limits as specified in the manual.
Page 5
Adjust TV board Check main board Check TV board Combined test for general assembly Connect to central signal source satellite signal, check if various TV functions (station skipping, modulate quantity control etc), check if the output of earphone and speaker are normal Input AV/S terminal signal, check different functions of AV/S terminals Input VGA signal and check if display is normal in...
Page 6
5. Adjustment for the TV board Connect the main board and infrared receiving board (as per wiring diagram 203-L15H30-01JL) and press the POWER key on the remote control set. Now the indication lamp of the infrared receiving board is blue or yellow. Measure N301 PIN2 of TV board to be 3.3 V, one terminal of inductor L630 to be 5 V and one terminal of inductor L632 to be 12 V 6.Adjustment of white balance (using the white balancer CA210 and K7253 signal generator specialized for LCD)
Page 7
Check if fine tuning is normal. Check if the output of earphone or loudspeaker is normal and if the picture is normal. b).Interface of AV/S Terminals Connect to access the signal of AV/S terminals separately and check if the picture or sound is normal.
separately and check if the picture and sound is normal. 8.Preset ex-works In the status of TV enter the factory menu by pushing the factory key and then perform presetting. 9.Ex-works packing Check accessories and then pack them in box. Trouble shooting Before servicing please check to find the possible causes of the troubles according to the table below.
Page 9
2.TV set: Symptoms Possible cause Unable to switch the power on Check to see if the power plug has been inserted properly into the socket. No picture and sound Check to see if the power supply of liquid crystal TV has been switched on.
Blur picture Check if the antenna cable is correctly connected. Of if it has received the right video signal. No sound Check if the “mute” audio frequency setting is selected. Check if the sound volume is set to minimum. Make sure the earphone is not connected. Check if the cable connection is loose.
Target After Download. Click FLASH pushbutton, it’s ready to run. For other settings, please refer to the Fig. Above (already defaulted by the system, normally no need to change). 4.Switch on TV set the FLASH write program begins to run; 5.After FLASH write is over, push button “cancel”...
Page 13
IC BLOCK BA7657F / BA7657S Red 1 input HD 1 input HD Sync signal detector HD 2 input Green 1 input HD output Ground Red output Blue 1 input Ground Green output Red 2 input Composite video input (Sync on Green) Syncsepa Ground Composite sync output...
back IR BOARD KEY BOARD back TO LCD PANEL TO LCD PANEL 30ps X701 CNB1 CNB2 DIGITAL BOARD ANALOG BOARD X204 HIGH VOLTAGE VCT3803 X601 TUNER1 PW1306 X614 X603 5ps X602 back or front X102 X501 X603 MSP3420 X605 X602 X203 HIGH VOLTAGE...
Serial No. of Parts 15" 17" 20" Sell area America America Europe America LCD panel Samsung Samsung Chimei 335-15012-00 335-17050-00 335-2000F-00 Back light board 667-L15H3-14 667-L17H3-14 667-L20H3-14A High frequency board 667-L15H3S-55 667-L15H3-55 667-L20H3-55 Main board 667-L15H3-01 667-L17H3-01 667-L20H3-01 adapter 302-L1510-02 302-AD16A-02 302-AD16A-02 antetype...
Troubleshooting guide No raster Does the logo appear on the screen Check whether the adapter Check whether X101 is when turning on the set ? supply 12V power to Digital Board. properly inserted. Good Check whether there is R.G.B Check U125965V. Check whether FUSE is melted.
Page 24
TV board troubleshooting No picture but have raster. Measure the waveform of R.G.B Hors, Vers at X7. Check whether N1 has Check whether X9 pin 1, pin 2 have 5V power supply. 5V power input. Measure N1 pin 33, pin 35 Replace N2 Replace N1 waveform.
Page 26
PART LIST OF EXPLODED VIEW DESCRIPTION PART# LABEL 881-63076-27 Transfer axis cover 808-10610-AF0 Screw 851-23010-14 Back cover 780-P03LH-121 Button baffle 808-60865-02 Button 667-L20H3-05 Screw 851-13010-11 Screw 851-34008-51 Speaker 384-40906-00 Remote receiver board 667-L20H3-09 LED column 706-60188-100 LOGO No number Front cover 780-P03L0J0G3 LCD panel 335-2000F-00...
Page 41
455-12310-H0 SMD RESISTOR FTR0603103JR R139 455-12175-H0 SMD RESISTOR FTR0603751JR SL20H30-39A10 SOFTWARE NA 20 Audiovox CMO 100-L20H30-40 FPE2005 100-L20H30-01 L20H3 665-D0002-473 LINE FC-50P 655-5K501-01 (5-PINS) LEAD WITH HOUSING 655-5K501-02 (5-PINS) LEAD WITH HOUSING 655-61201-116 (6-PINS) LEAD WITH HOUSING 655-8K501-02 (8-PINS) LEAD WITH HOUSING...
Page 42
ACCESSORY BOX (15L) 364-41207-00 ANT SOCKET HR-F 665-D0002-422 VIDEO LINE YELLOW WHITE RED 665-D0002-159 CONNECTION 3501 5.603.300 666-13529-00 FERRITE BEAD TY35X5X12 881-63076-27 BACK PLATE LABEL (FPE2005,AUDIOVOX) 881-63764-00 BAR CODE LABEL (FPE2005) 681-40002 CERTIFICATE LABEL 870-1D091-00 LCD HOLDER 881-61884-00 CSA WARNING LABEL 881-63765-00...
Page 43
488-10012-00 BATTERY 7#( made in china 881-80611-00 REGISTER CARD (AUDIOVOX) 881-80612-00A WRRANTY (AUDIOVOX) 604-L20H37-03 OWNER'S MANUALAUDIOVO VGA,FPE2005 302-AD16A-02 ADAPTER FSP060-1AD103! 615-10424-01 HOLDER ASS'Y (DZ-0620 SILVERY WHITE 06 ) 615-10331-00 AXLETREE ASS'Y 807-20212-0G0 HOLDER ( SILVERY WHITE 06) 808-10610-AF0 AXLETREE COVER BOARD ( GREY 05)
