Audiovox LC-37K7 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
COLOR TELEVISION
LC-37K7
(FPE3705)

Advertisement

Table of Contents
loading

Related Manuals for Audiovox LC-37K7

Summary of Contents for Audiovox LC-37K7

  • Page 1 COLOR TELEVISION LC-37K7 (FPE3705)

  • Page 2: Table Of Contents

    CONTENTS Safety instructions………………………………………………………………………..… Adjustment instruction …………………………….…….…………………………….… Trouble shooting ……………………………………………………….…………………… Method of software upgrading ………………………………………….…….…………… LC-37K7 working principle analysis……………………………….………….…………. LC-37K7 block diagram…………………………………..……………………….………… IC block diagram………………………………………………………………………..…… Main assembly……………………………………………………………………………..… Identification criteria for the bright spot and dark spot of the LCD screen………..…. Wiring diagram ……………………………………………………………..……………...

  • Page 3: Safety Instructions

    This service manual is only for service personnel to take reference with. Before Attention: servicing please read the following points carefully. Safety instructions 1. Instructions Be sure to switch off the power supply before replacing or welding any components inserting/plugging in connection wire Anti static measures to be taken (throughout the entire production process!): a) Do not touch here and there by hand at will;...
  • Page 4 would be unable to work and no way to get it repaired. 2.11 Special care must be taken in transporting or handling it. Exquisite shock vibration may lead to breakage of screen glass or damage to driving circuit. Therefore it must be packed in a strong case before the transportation or handling.

  • Page 5: Adjustment Instruction

    Alignment instruction 1 Alignment equipment PM5518 (video signal generator) K-7253 (VGA signal generator) CA210 (white balancer) 2 Alignment flow-chart The alignment flow-chart is shown as fig-1 Check DDC and FLASH To produce CPU board and analog board Check the CPU board and analog board All testing Connect with central signal source, then check each function of TV such as analog control etc., check the output of headphone and speaker...
  • Page 6 3.1 EEPROM initialization Enter the first page of factory menu, select “clear eeprom” and then press “enter”, shut down the unit after “ok” appears. 3.2 VGA/DVI channel adjustment 3.2.1 Preset VGA channel mode Input VGA signal (PATTERN 5: Final Test) of K-7253, select TIME301(640*350/70Hz), press “AUTO”...

  • Page 7: Trouble Shooting

    the value of the two levels gray-scale be the specified value. 3.4 white balance adjustment YPbPr channel input YpbPr signal of K-7253 to YPbPr-1 terminal, input TIME380(480i) PATTERN471 8 level gray-scale signal, set the value of Hor-width to 23, Ver-width to 5, S-bright to 120 and S-contrast to 140.Enter adjustment menu of white balance, adjust the third level using white balancer.
  • Page 8 Fringe in picture Check if the antenna is correctly oriented. Maybe there is electric wave reflected from hilltop or building. Picture is interfered by stripe Possibly due to interference from automobile, train, high shaped bright spots voltage transmission line, neon lamp etc. Maybe there is interference between antenna and power supply line.

  • Page 9: Method Of Software Upgrading

    darkest area of the picture Possibly the brightness grade of DVD player (broadcaster) is set too high. No picture or signal produced from the Check if the cable is disconnected. displayer if “XXX in search” appears. Check if it’s connected to the proper terminal or if the input mode is correct.
  • Page 10 FlashUpgraderNT (use under window 2000/XP/NT) FlashUpgrader (use under window 98), The following interfaces will show up after running the program: Based on the computer features, set up the serial port (COM Port). Select corresponding serial port (if it’s unable to FLASH WRITE, change to another port). Baud is selected to be 115200. Then select Reset Target After Download.

  • Page 11: Lc-37K7 Working Principle Analysis

    LC-37K7 working principle analysis Please refer to LC-37K7 BLOCK DIAGRAM in order to know the working principle of LC-37K7 brief introduction to its signal flow is shown as follows: RF signal produces composite color television signal through TUNER201, the signal together with AV1/SVHS(SVHS priority) and AV2 etc.

  • Page 12: Lc-37K7 Block Diagram

    LC-37K7 Block diagram U15 DVI DRIVER 24bit TFP403 LVDS DRIVER 24bit TUNER1 SCALER DS90C383 JAG-ASM 24bit DEINTER ITU-R656 LACER AV1-V/S-Y 8bit FLI2310 SVHS-C AV2 -V SDRAM SDRAM SDRAM AV-V OUT I IC BUS FLASH MEMORY MICRO- CONTROLER YprPb IR / KEYBOAD...

  • Page 13: Ic Block Diagram

    IC block diagram 1.MSP3420 Pins description: 2,3 PIN: SCL,SDA applied for control the operation of IC . 27,28 PIN: output left and right sound channel R/L to speaker processor. 36,37 PIN:AV OUT of sound R/L. 47,48 PIN:D4-1/D4-2/PCMCIA selected input R/L. 50,51 PIN:Input of VGA.
  • Page 14 2.VPC3230 Pins description: 4 PIN: Input U of PCMCIA. 5,73 PIN: Input Y of PCMCIA. 6 PIN: Input V of PCMCIA 31-34, 37-40 PIN: output format signal of. ITU-R656 70 PIN:Video of AV OUT 71 PIN:Input C of SVHS. 72 PIN:input Video (SVHS in priority) of Y or AV1 of SVHS. 74 PIN:input Video of AV2.
  • Page 15 3.AD9883...
  • Page 16 4.FLI2310-Simplified Internal Block Diagram...
  • Page 17 5.JAG-ASM...
  • Page 18 6. TFP403 functional block diagram 3.3 V 3.3 V 1.8 V Regulator Internal 50- 3.3 V Termination RED(0-7) QE(0-23) Channel 2 CH2(0-9) CTL3 Rx2+ QO(0-23) Latch Rx2- CTL2 ODCK GRN(0-7) Channel 1 Data Recovery CH1(0-9) Rx1+ TMDS Panel SCDT Latch CTL1 Decoder Interface...
  • Page 19 7. DS90C385 DS90C365 DS100868-1 DS100868-29 Order Number DS90C385MTD or DS90C385SLC Order Number DS90C365MTD See NS Package Number MTD56 or SLC64A See NS Package Number MTD48...

  • Page 20: Main Assembly

    Main assembly NAME MAIN COMPONENT AND it’S NO. AV processing board 667-L37K7N-40 NA01 MSP3410 (353-34100-80) NA03 M62494FP (353-62494-20) TPA3008D2 (353-30080-10) CPU board 667-L37K72-56 JAG-ASM (353-0JAG0-00) FLI2310 (353-23100-00) TFP403PZP (353-04030-10) VPC3230D (353-32300-80) MST9883B (353-98830-10) DS90C385 (353-03850-20) TSC80251G2D (353-80251-10) AT49F002NT (352-49002-70) IR board 667-L37K7-09 Keypad board 667-L37K7-05...

  • Page 21: Identification Criteria For The Bright Spot And Dark Spot Of The Lcd Screen

    Identification criteria for the bright spot and dark spot of the LCD screen Q’ty allowed Distance between two spots Category criteria 15" 20" 22" 30" 40" 15" 20" 22" 30" 40" One single ≤5 ≤2 ≤5 ≤2 ≤3 spot Bright ≥15mm 2 neighboring ≤2...

  • Page 22: Wiring Diagram

    Wiring diagram Right panel...

  • Page 23: Troubleshooting Charts

    Troubleshooting charts 1. No raster Turn-on power supply, check if the red indicator is light in the STANDBY? blue Check PIN3(5V output) of the Check the indicator in power supply board C3 turn-on condition Check if the indicator is flicker Non-change color in the sensor control normal condition?
  • Page 24 2. raster, but no picture Check if the unit Check can operation? channels have signal? Which is no VGA/DVI Replacing CPU Enter factory-menu, signal board operation CLEAR channels EEPROM, then turn YPRPB Replacing off , turn on again , it if CPU board display picture.
  • Page 25 3.no sound Check if PIN1 and PIN2 is 18V of XA12 Check if PIN2 is 12V of XA09 Check PIN5 and PIN8 Replacing NA04 output wave of NA03 Check power supply Check PIN27 PIN28 output wave of Replacing NA03 NA01 Check PIN67 wave of NA01 Replacing NA01 Replacing TUNA01...

  • Page 26: Exploded View

    E X P L O D E D V I E W...
  • Page 27 FPE3705 PART LIST OF EXPLDED VIEW DESCRIPTION PART# BACK CABINET COVER (LEFT) 808-10783-AN0 SCREW CAP 785-20023-00 BACK CABINET COVER (RIGHT) 808-10784-AN0 SPEAKER BOX BACK COVER(LEFT) 808-10778-AN0 SPEAKER BOX CONNECTION COVER 808-10780-AN0 SOCKET (SPEAKER BOX) 364-42201-00 REAR CABINET 780-Y07LI-AN1 SPEAKER BOX CONNECTION PIECE 804-20404-00 SPEAKER BOX LINE CLASP BRACKET 870-10247-00...
  • Page 28 FPE3705 DESCRIPTION PART# FRONT CABINET 780-Y07L0-GA1 SPEAKER FRONT COVER(LEFT) 615-10514-0R0A IR SENSE PCB ASSY 667-L37K7-09 EARPHONE ASSY 667-L37K7-09 POWER SWITCH 360-30042-00 COVER BOARD(USB) 808-1C790-AN0 BUTTON BOARD 667-L37K7-05 COVER BOARD(BUTTON) 808-10789-AN0 SCREEN CONNECTION BRACKET( BELOW) 870-10233-00 LG SCREEN CONNECTION PIECE(2) 870-10245-00 CONNECTION BOARD 804-2A372-00 CONNECTION BRACKET(BELOW)

  • Page 29: Part List

    PART LIST PART# DESCRIPTION LOCA.NO. SL22K90-01B10 SOFTWARE K#LCD DDC-VGA SL22K90-01C10 SOFTWARE K#LCD DDC-DVI 100-L37K70-11 FPE3705 100-L37K70-02 LC-37K7 15 485-10170-00 POWER CORD LAP-31+LASR-24 881-63071-00 GROUNDING LABEL 655-B1201-37 (12-PINS) LEAD WITH HOUSING 655-B1201-38 (12-PINS) LEAD WITH HOUSING 655-21201-87 (２-PINS) LEAD WITH HOUSING...
  • Page 30 851-34010-57 SCREW B(+)4X10G-D.Zn ( BLACK ) 851-43012-52 SCREW F(+)T3X12G-DNi 851-44012-57 SCREW F(+)4X12G-D.Zn ( BLACK ) 851-44012-57 SCREW F(+)4X12G-D.Zn ( BLACK ) 852-33008-87 SCREW B(+) M3X8-D.Zn ( BLACK ) 852-33008-87 SCREW B(+) M3X8-D.Zn ( BLACK ) 887-21074-00 PALSTIC BAG (100X230) 852-33008-87 SCREW B(+) M3X8-D.Zn ( BLACK ) 852-33008-87 SCREW B(+) M3X8-D.Zn ( BLACK )
  • Page 31 804-20404-00A SOUND BOX CONNECT PIECE 808-10780-AN0 SOUND BOX CONNECT COVER BOARD ( GREY 08) 851-34010-57 SCREW B(+)4X10G-D.Zn ( BLACK ) 851-34010-57 SCREW B(+)4X10G-D.Zn ( BLACK ) 870-10248-00 BRACKET 887-21207-P0 PE/PEARL COTTONPALSTIC BAG 1500X1000 852-34006-87 SCREW B(+) M4X6-D.Zn ( BLACK ) 852-34006-87 SCREW B(+) M4X6-D.Zn ( BLACK ) 804-2A404-00...
  • Page 32 CERTIFICATE LABEL 681-40002 CERTIFICATE LABEL 780-Y07LIHAN3 BACK CABINET V0 GREY 08SILK-SCREEN 780-Y07L1J0G1 FRONT CABINET ABS V0 SILVER WHITE 06SILK-SCREEN 886-31745-02 CARTON BOX BOTTOM COVER (LC-37K7,AUDIOVOX) 886-31744-03A CARTON BOX (FPE3705, AUDIOVOX) 604-L37K77-00 OWNER'S MANUAL(AUDIOVOX) 808-1C790-AN0 COVER BOARD (USB GREY 08) 881-80611-00...
  • Page 33 851-33010-57 SCREW B(+)3X10G-D.Zn ( BLACK ) 851-33010-57 SCREW B(+)3X10G-D.Zn ( BLACK ) 864-90044-00 SOUND ABSORBENT 868-10043-00 WASHER (14X4X1 METAL ) 868-10043-00 WASHER (14X4X1 METAL ) 868-20772-00 RUBBER WASHER 868-20772-00 RUBBER WASHER 615-20431-02 SOUND BOX ASS'Y ( RIGHT ) 364-42201-00 SOCKET WP2-9C 615-10515-0G0A SOUND BOX FRONT COVER ASS'Y RIGHT SILVERY WHITE 06 615-20523-00...
  • Page 34 462-2B410-M0V POLYESTER CAPACITOR 250VAC-0.1uF-M C605 462-2B410-M0V POLYESTER CAPACITOR 250VAC-0.1uF-M C602 462-D5510-H1 POLYESTER CAPACITOR CBB21A-400V-1uF-J C606 462-D5510-H1 POLYESTER CAPACITOR CBB21A-400V-1uF-J C607 462-D5510-H1 POLYESTER CAPACITOR CBB21A-400V-1uF-J C608 467-8E522-H0A SOLID RESISTOR 1/2W-2.2M-J R601 469-40012-00 THERMISTOR M2R014C RT601 477-20081-00 POWER FILTER LCL103B L602 477-20081-00 POWER FILTER LCL103B L601 477-40269-00...
  • Page 35 360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B 782-L37K7-050A BUTTON PCB 364-381BQ-00 8-PINS CONNECTORS 1.25T-1-8AW 667-L37K7-09 IR RECEIVE BOARD ASS'Y 667-L37K7-09\ IR RECEIVE BOARD ASS'Y (MANUAL INSERTION ) 340-10113-20 LED HFT503MPBR-1 LED1 352-17060-00 IC HRM138BB1706 (D) 364-351AY-00 5-PINS CONNECTORS TJC10-5A 464-6C722-M0 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M 667-L37K7-09* IR RECEIVE BOARD ASS'Y (SMD ) 455-12110-H0...
  • Page 36 464-6D647-M0 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M CA19 464-6D647-M0 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M CA28 464-6D647-M0 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M CA38 464-6D647-M0 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M CA40 464-6D710-M0 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M CA36 464-6D710-M0 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M CA70 464-6D710-M0 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M CA82 464-6E610-M0 ELECTROLYTIC CAPACITOR CD110-25V-10uF-M CA83 464-6E610-M0 ELECTROLYTIC CAPACITOR CD110-25V-10uF-M CA86...
  • Page 37 353-62494-20 *SMD ICM62494FP NA03 455-12000-H0 SMD RESISTOR FTR0603000XR RA47 455-12000-H0 SMD RESISTOR FTR0603000XR RA48 455-12075-H0 SMD RESISTOR FTR0603750JR RA11 455-12110-H0 SMD RESISTOR FTR0603101JR RA01 455-12110-H0 SMD RESISTOR FTR0603101JR RA02 455-12110-H0 SMD RESISTOR FTR0603101JR RA03 455-12110-H0 SMD RESISTOR FTR0603101JR RA08 455-12110-H0 SMD RESISTOR FTR0603101JR RA12 455-12110-H0...
  • Page 38 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA11 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA18 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA33 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA34 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA51 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA53 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA54 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA66 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CA67...
  • Page 39 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA37 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA39 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA45 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA68 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA69 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA117 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA118 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA119 456-3210H-11 SMD CAPACITOR 0603CG102J500BA CA120...
  • Page 40 364-11212-00 EARPHONE JACK ST-112 364-32101-00 2-PINS CONNECTORS TJC3-02A 364-33101-00 3-PINS CONNECTORS TJC3-03A 464-6C722-M0 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C207 464-6C722-M0 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C501 464-6C722-M0 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C536 364-37101-00 7-PINS CONNECTORS TJC3-07A 364-37101-00 7-PINS CONNECTORS TJC3-07A 364-49217-00 DVI SOCKET DVI34-24+5SFW 364-381AY-00 8-PINS CONNECTORS JC10-8A 364-3B101-00 102-PINS CONNECTORS TJC3-12A...
  • Page 41 * 455-12147-H0 SMD RESISTOR FTR0603471JR R234 * 455-12156-H0 SMD RESISTOR FTR0603561JR R211 * 455-12175-H0 SMD RESISTOR FTR0603751JR R230 * 455-12210-H0 SMD RESISTOR FTR0603102JR R232 * 455-12210-H0 SMD RESISTOR FTR0603102JR R233 * 455-12210-H0 SMD RESISTOR FTR0603102JR R226 * 455-12210-H0 SMD RESISTOR FTR0603102JR R225 * 455-12210-H0 SMD RESISTOR FTR0603102JR...
  • Page 42 342-08570-90 SMD TRANSISTOR BC857 AW 342-39040-00 SMD TRANSISTOR MMBT3904 342-39040-00 SMD TRANSISTOR MMBT3904 353-00120-40 SMD IC ATTINY12L-4SC 353-01390-10 *SMD IC SN74AHC139PW 353-02320-30 SMD ICMT48LC2M32B2TG-6 353-02320-30 SMD ICMT48LC2M32B2TG-6 353-02320-30 SMD ICMT48LC2M32B2TG-6 353-03730-20 SMD IC SN74AHC373PWP (D) 353-03740-10 SMD IC SN74AHC374PWP (D) 353-03830-70 SMD IC DS90C 383A 353-04030-10...
  • Page 43 454-03647-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-47uF-M C392 454-03647-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-47uF-M C524 454-03647-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-47uF-M C525 454-03647-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-47uF-M C526 454-03647-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-47uF-M C527 454-03710-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-100uF-M C105 454-03710-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-100uF-M C210 454-03710-MB SMD ELECTROLYTIC CAPACITOR CDPS-10V-100uF-M...
  • Page 44 455-10022-H9 SMD RESISTOR NCA4R220JR RP12 455-10022-H9 SMD RESISTOR NCA4R220JR RP13 455-10022-H9 SMD RESISTOR NCA4R220JR RP14 455-10022-H9 SMD RESISTOR NCA4R220JR RP15 455-10022-H9 SMD RESISTOR NCA4R220JR RP16 455-10022-H9 SMD RESISTOR NCA4R220JR RP17 455-10022-H9 SMD RESISTOR NCA4R220JR RP18 455-10022-H9 SMD RESISTOR NCA4R220JR RP19 455-10022-H9 SMD RESISTOR NCA4R220JR RP20...
  • Page 45 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR R101 455-12022-H0 SMD RESISTOR FTR0603220JR R106 455-12022-H0 SMD RESISTOR FTR0603220JR R107 455-12022-H0 SMD RESISTOR FTR0603220JR...
  • Page 46 455-12110-H0 SMD RESISTOR FTR0603101JR R111 455-12110-H0 SMD RESISTOR FTR0603101JR R119 455-12110-H0 SMD RESISTOR FTR0603101JR R144 455-12110-H0 SMD RESISTOR FTR0603101JR R150 455-12110-H0 SMD RESISTOR FTR0603101JR R151 455-12110-H0 SMD RESISTOR FTR0603101JR R152 455-12110-H0 SMD RESISTOR FTR0603101JR R171 455-12110-H0 SMD RESISTOR FTR0603101JR R175 455-12110-H0 SMD RESISTOR FTR0603101JR R176...
  • Page 47 455-12310-H0 SMD RESISTOR FTR0603103JR 455-12310-H0 SMD RESISTOR FTR0603103JR 455-12310-H0 SMD RESISTOR FTR0603103JR 455-12310-H0 SMD RESISTOR FTR0603103JR R103 455-12310-H0 SMD RESISTOR FTR0603103JR R108 455-12310-H0 SMD RESISTOR FTR0603103JR R126 455-12310-H0 SMD RESISTOR FTR0603103JR R127 455-12310-H0 SMD RESISTOR FTR0603103JR R140 455-12310-H0 SMD RESISTOR FTR0603103JR R204 455-12310-H0 SMD RESISTOR FTR0603103JR...
  • Page 48 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1...
  • Page 49 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1...
  • Page 50 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C154 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C155 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C156 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C157 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C158 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C159 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C160 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C161 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C162...
  • Page 51 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C289 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C290 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C291 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C292 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C293 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C294 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C295 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C296 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C297...
  • Page 52 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C463 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C464 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C465 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C466 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C484 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C485 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C495 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C496 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C520...
  • Page 53 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00 SMD FERRITE BEAD BG2012B300T 666-12012-00...
  • Page 54 VA01 * 455-12310-H0 SMD RESISTOR FTR0603103JR RA05 * 455-12310-H0 SMD RESISTOR FTR0603103JR RA06 SL37K70-11A10 SOFTWARE FLASH AUDIOVOX 615-10508-03 WALL MOUNT ASS'Y ( MIDDLE ) 605-L37K77-00 WALL MOUNT TIP( MIDDLE) 615-10445-00 WALL MOUNT ASS'Y (，LC-30X9 ) 789-70032-00 WALL MOUNT COMPOSE BOLT M6X10...
  • Page 55 667-L37K7-20 POWER PCB ASS'Y (37" LG) 667-L37K7-20\ POWER PCB ASS'Y (MANUAL INSERTION ) 340-00291-00 DIODE TEU2YX D501 340-00406-00 DIODE EM2A D502 340-00400-00 DIODE SARS01 D509 340-00400-00 DIODE SARS01 D512 343-34690-00 TRANSISTOR 2SK3469-01MR V501 343-34690-00 TRANSISTOR 2SK3469-01MR V502 343-10130-60 TRANSISTOR 2SA1013-0 V505 343-09660-60 TRANSISTOR 2SA966-0...
  • Page 56 467-2GB22-H0 METAL RESISTOR 2W-0.22Ω-JL R507 467-2GB39-H0 METAL RESISTOR 2W-0.39Ω-JL R526 467-4E022-H0 FUSIBLE RESISTOR 1/2W-22Ω-JL R537 467-4E022-H0 FUSIBLE RESISTOR 1/2W-22Ω-JL R540 467-4F010-H0 FUSIBLE RESISTOR 1W-10Ω-JL R530 467-8E510-H0 SOLID RESISTOR 1/2W-1MΩ-JL R516 467-8E510-H0 SOLID RESISTOR 1/2W-1MΩ-JL R517 467-8E539-H0A SOLID RESISTOR 1/2W-3.9MΩ-J R501 467-8E539-H0A SOLID RESISTOR 1/2W-3.9MΩ-J R502...
  • Page 57 340-00001-0S SMD DIODE LL4148 D513 340-00001-0S SMD DIODE LL4148 D514 340-00001-0S SMD DIODE LL4148 D515 340-00001-0S SMD DIODE LL4148 D516 340-00001-0S SMD DIODE LL4148 D521 340-00296-00 SMD DIODE SK34 D522 342-01440-10 SMD TRANSISTOR DTC144EKA V506 455-22320-H0 SMD RESISTOR RC11-1/8W-20K-J R518 455-22110-H0 SMD RESISTOR RC11-1/8W-100-J R512...
  • Page 58 SMD CAPACITOR C2012X7R1H104KT C546 456-3410K-B2 SMD CAPACITOR C2012X7R1H104KT C548 456-3410K-B2 SMD CAPACITOR C2012X7R1H104KT C557 456-3410K-B2 SMD CAPACITOR C2012X7R1H104KT C558 456-3410K-B2 SMD CAPACITOR C2012X7R1H104KT C559 782-L37K7-200C POWER PCB 353-97010-10 *SMD ICBD9701FP N506 301-UL27K6-38RC RC-U38R-0CREMOTE CONTROL UNIT (AUDIOVOX) RC353-34282-30 SMD ICM34282M1-D48GP (M)
