Summary of Contents for Chauvet DJ GEYSER MOVE
- Page 1 User Manual...
-
Page 2: Edition Notes
Edition Notes The Geyser Move User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the Geyser Move as of the release date of this edition. Trademarks Chauvet, Chauvet DJ, the Chauvet logo, and Geyser are registered trademarks or trademarks of Chauvet &... -
Page 3: Table Of Contents
Zones for DMX Control ..................DMX Charts......................Geyser WRC Configuration................Color Selection....................Motor Angle Selection ..................Geyser WRC Overview ..................5. Maintenance..................Product Maintenance ..................Fog Machine Maintenance................Storage......................6. Technical Specifications..............Contact Us....................Warranty & Returns..................Geyser Move User Manual Rev. 1... -
Page 4: Before You Begin
Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. Geyser Move User Manual Rev. 1... -
Page 5: Safety Notes
Add perfume, alcohol, gasoline or any other chemical to the fluid. ♦ Use for space-heating purposes. Keep this User Manual for future use. If the product is sold to someone else, be sure that they also receive this document. Geyser Move User Manual Rev. 1... -
Page 6: Fcc Statement Of Compliance
This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and the user. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Geyser Move User Manual Rev. 1... -
Page 7: Introduction
14 5-pin DMX in/out 15 Fuse holder 16 Power in 17 Safety loop 18 10-pin update port 19 Tank base plate Product Dimensions 8.2 in 208 mm 15.7 in 17.7 in 400 mm 450 mm Geyser Move User Manual Rev. 1... -
Page 8: Setup
3. Setup AC Power The Geyser Move has a fixed voltage power supply, and it can work with an input voltage range of either 120 VAC, 60 Hz or 230 VAC, 50 Hz, depending on the specific model. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 9: Mounting
Notes. Orientation The Geyser Move may be mounted in any position; however, make sure adequate ventilation is provided around the product. In addition, make sure the fluid tank is in an upright position. See Inverting the Tank for information on mounting in other positions. -
Page 10: Inverting The Tank
Setup Inverting the Tank To mount the Geyser Move in a position where the fluid tank would normally not be upright, it will be necessary to invert the tank orientation. 1. Remove the thumbscrew securing the fluid tank bracket, slide the bracket out and place it to the side. - Page 11 5. Insert the fluid tank bracket in the slot and secure it with the thumbscrew. Inverted Mounting Diagram Mounting clamp (x2) (such as CLP-15 from Chauvet) Hanging Safety cable bracket (x2) (such as CH-05 from Chauvet) Geyser Move User Manual Rev. 1...
-
Page 12: Operation
After connecting power, allow 5 to 6 minutes for the Geyser Move to heat up before triggering fog output. DMX Configuration The Geyser Move works with a DMX controller. Information about DMX is in the Chauvet DMX Primer, which is available from the Chauvet website chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf. Personality and Starting Address The Geyser Move uses 16 DMX channels in the DMX mode, which defines the highest recommended address to 497. -
Page 13: Zones For Dmx Control
000 009 No function Strobe 010 255 Strobe, slow to fast 000 011 No function Dimmer 012 255 0–100% 000 029 No function Motor 030 255 Motor angle, -45° to +45° Geyser Move User Manual Rev. 1... -
Page 14: Geyser Wrc Configuration
Product Overview for the location of the receiver input port. After connecting power, allow 5 to 6 minutes for the Geyser Move to heat up before triggering fog output. Color Selection To configure the color output triggered by a button on the Geyser WRC (<1>–<4>), do the following: 1. -
Page 15: Maintenance
1 through 5. Do not refill the tank with fog fluid if storing the Geyser Move. Cleaning the system prior to storage will help prevent any particles from condensing inside the pump or heater while not in use. -
Page 16: Technical Specifications
Cooling System 104 °F (40 °C) Fan-assisted convection I/O Connector Channel Range 3- and 5-pin XLR Ordering Product Name Item Code UPC Number Geyser Move (120 V) 05072303 781462226510 Geyser Move (230 V) 05072306 781462226541 Geyser Move User Manual Rev. 1... -
Page 17: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Geyser Move User Manual Rev. 1...
