Note : When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door pin
switch in order to begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1st Door L/UL
2nd Accy Lock
3rd Accy. UL
4th Passive Locks
5th Passive/Active Arm
6th Voltage Sense
7th Siren/Horn
8th Horn Chirp
9th Override Method
10th Chirp Delete From Tx
To program these selectable features;
Turn ignition on
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
Second
Press and release the valet switch
Press transmitter Lock button to change
Third
Press and release the valet switch
Press transmitter Lock button to change
Fourth
Press and release the valet switch
Press transmitter Lock button to change
Fifth
Press and release the valet switch
Press transmitter Lock button to change
Sixth
Press and release the valet switch
Press transmitter Lock button to change
SELECTABLE FEATURES
1 Chirp
2 Chirps
1 Sec.
3.5 Sec.
Auto Lock On
Auto Lock Off
Auto UL On
Auto UL Off
Passive
Active
Passive Arm
Active Arm
Voltage Sense Hardwire
Siren/Horn
Siren Only
10mS
16mS
Custom Code
Valet
On
Off
Action
o r
o r
o r
o r
o r
o r
Model APS-155CH
Installation Manual
3 Chirps
4 Chirps
1 Sec L, Dbl. U/L
Horn Only
30mS
System Response
No response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
2 chirps = auto unlock off
1 chirp = auto unlock on
2 chirps = active locks
1 chirp = passive locks
2 chirps = active arming
1 chirp = passive arming
2 chirps = hardwire
1 chirp = voltage sense
Default
1 Sec.
Auto Lock Off
Auto UL Off
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
128-6459
1 of 6
Advertisement
Table of Contents
Related Manuals for Prestige 1286459
Summary of Contents for Prestige 1286459
- Page 1 Model APS-155CH Installation Manual SELECTABLE FEATURES Note : When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver’s door pin switch in order to begin the passive arming sequence. RF Programmable Features : Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps...
- Page 2 Seventh Press and release the valet switch 1 chirp = siren and horn output Press transmitter Lock button to change 2 chirps = siren output only Press transmitter lock button to change 3 chirps = horn output only Eighth Press and release the valet switch 2 chirps = horn chirp output 16mS Press transmitter Lock button to change 3 chirps = horn chirp output 30mS...
- Page 3 Be sure to check behind the dash for adequate clearance for the body of the switch, and to confirm that the drill will not damage any existing components as it passes through the dash. You should also make certain that the back of the switch is accessible for wiring later in the installation. Shock Sensor : Select a solid mounting surface for the shock sensor on the firewall inside the passenger compartment, and mount the sensor using the two screws provided.
- Page 4 Note : This is a normally closed starter cut arrangement, and when power is removed from the security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.
- Page 5 These applications require the use of additional components which may include relays, fixed resistors, or for convenience, the AS 9159 Door Lock Interface. Refer to the AUDIOVOX Door Lock Wiring Supplement and or the Audiovox fax back service for information on your particular vehicle for properly connecting to these types of circuits.
- Page 6 128-6459 © 2003 Audiovox Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-6459 6 of 6...
