Summary of Contents for Zontes ZT155

  • Page 2 To download the latest user manual, please visit our official website: PC official website: www.zontes.com Or scan the QR code of ZONTES Mall at the bottom of this page, click on the corresponding model, and click on the "Manual" to download.
  • Page 3 Preface Safety precautions: The safety of you and others is very important. Please obey the traffic rules and drive safely. In order to help you drive safely, our company provides detailed operation instructions and other relevant information on the body label and this manual to prevent you or others from being exposed to potential dangers.

  • Page 4: Table Of Contents

    Catalog Catalog -------------------------------------- 2 Air filter cartridge ------------------------ 45 Information for Users Safe Driving Spark plugs Instructions --------------------------------- 4 Removing the spark plug ------------- 46 Driving safety measures ---------------- 4 Checking the spark plugs ------------- 46 Modifications ------------------------------- 4 Installing the spark plug --------------- 47 Familiarization with motorcycles and Engine oil driving skills -------------------------------- 4...
  • Page 5 Catalog Troubleshooting Engine ------------------------------------- 73 Fuel system check ---------------------- 66 Battery ------------------------------------- 73 Engine not working --------------------- 66 Tires ---------------------------------------- 73 Engine's power is not enough ------ 66 Maintenance during storage --------- 73 Carbon Cleaning ------------------------ 67 Methods of restarting ------------------ 75 EFI Precautions --------------------- 68 Transportation --------------------------- 76 Explanation of fault codes ------------ 69...

  • Page 6: Information For Users

    Information for Users There are all kinds of accessories on the market it can be assembled on your motorcycle, and we cannot directly control the market quality and applicability of accessories The inapplicable accessories will endanger the safety of the riding personnel. The selection of accessories and installation, therefore, must be especially careful.

  • Page 7: Speed Limits

    Information for Users Vigilance in driving in rainy weather Pay extra attention to driving on cloudy and rainy days, and keep in mind that the braking distance is twice that of sunny days. When driving, avoid road marking paint, manhole covers, and oily roads to avoid slippage. Drive with extreme caution over railroad crossings, iron fences and bridges.

  • Page 8: Driving Tips

    Driving tips ·As you drive the motorcycle for the first time, we suggest you had better look for practice on the un-public road, until you are familiar with this motorcycle control method. ·Driving with only one hand is the most dangerous, we should driving in both hands firmly in the grip and both feet on the foot.
  • Page 9 Driving tips ·The colder is the weather, the longer time the engine needs to preheat. After fully preheat, you can reduce the engine wear and tear. When the engine is in hot machine status 1.Pack up the side stand. 2.Throttle control handle is on idling position. 3.First pinch the clutch and then press the electric start button to start.

  • Page 10: Driving

    Driving Pack up the main stand, hold the clutch handle, just wait a moment, hit the hang first gear shift lever: step on the gas and slowly release the clutch handle gently, the motorcycle will start. It you want to get to the next higher gear, speed up first, and then close the throttle, hold the clutch handle at the same time, the shift lever stepped down, hanging in the second gear.
  • Page 11 Driving ( 5)If a motorcycle with a side stand is going to park in gentle slope road, you should hang gear into the low level, as far as possible to get the motorcycle started up hill side, to avoid overturned because of side racks rotation. However, when restart, you must hang the files back to the neutral position.

  • Page 12: Break-In Of The New Vehicle

    Break-in of the new vehicle The correct new running-in can prolong the service life of the motorcycle, it can also give full play to the performance of the new motorcycle. Below is a list of running in right way. recommended maximum engine speed First 500 kilometers below 5500 turns/minute Up to 1500 kilometers...

  • Page 13: Numbering Position

    Numbering position ① ③ ② The Vehicle Identification Code and the engine number are used for the registration of the motorcycle. When ordering accessories or commissioning special services, the number enables the distributor to provide you with better service. ①The vehicle identification code is engraved on the frame under the seat seat, ②The 3C nameplate is fixed at the bottom of the front riser of the frame.
  • Page 14 Numbering position ·Please pay attention to the following items and similar items. ·Any violation may cause damage to parts or vehicles, or even casualties of riders. ·When driving, the side parking frame must be stowed to prevent the vehicle from overturning when turning, causing casualties to the riders.

  • Page 15: Installation Locations Of Spare Parts

    Installation locations of spare parts ① ② ③ ④ ⑤ ⑥ ⑦ ① Clutch lever ⑤ Throttle ② Speedometer ⑥ Left sub handle switch ③ Front disc brake oil cup ⑦ Left handle switch ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑧...

  • Page 16: Handlebar Control System

    Handlebar control system 1. Clutch controller When starting the engine or shifting gears, hold the handle to separate the clutch discs to cut off the power transmission. 2. Overtaking warning lights When speeding up, press the button warning the cars in front or behind. 3.
  • Page 17 Handlebar control system 10. Red power-on button When the host is in the sleeping version, press the " " button in short time to wake up the host. After detecting the response signal of the key and the signal of the handle bar lock, the whole vehicle will "starting" up. Press the " " button in long time, the host will enter into sleep version, and the whole vehicle will be shut down.

  • Page 18: Shift Lever

    Shift lever The motorcycle is equipped with 6 gear transmission. Down pedaling or up lifting the lever can switch gears. Afterwards, the lever will return to original position so as for subsequent gear shifting. Before shifting to lower gear, please reduce the speed or increase the RPM. Before shifting to higher gear, please increase the speed or reduce the RPM.

  • Page 19: Front Footrest Position Adjustment

    Front footrest position adjustment ⑥ ⑤ ⑥ ④ ① ③ ② A. Adjusting the front left pedal position Tools: 8# hexagonal socket, 14# plum wrench, 8# open-end wrench, 10# open-end wrench 1. Use 8# hexagonal socket to remove the M10 axle position bolt ①; 2.
  • Page 20 Front footrest position adjustment 1. Remove the rear brake pump cotter pin and pin ① with a pair of sharp- nosed pliers; 2. Remove the M10×25 bolt ② with a 14# open-end wrench; 3. Remove the rear brake switch spring ③; 4.

  • Page 21: Pke Operating Instructions

    PKE operating instructions 3D antenna sensing area PKE (keyless entry system) instructions for use: The PKE system consists of PKE main body (Figure 1), low-frequency transmitting antenna (Figure 2), key (Figure 3), powerless induction antenna (Figure 4) and PKE accessories (Figure 5), five parts. PKE accessory (Figure 5) function description: ①...
  • Page 22 PKE operating instructions 2.PKE working: When the PKE is connected to the power supply for the first time (such as connecting to the battery power supply or plugging in the PKE fuse), when the key is not within the sensing range of the vehicle, the vehicle will beep 4 times, representing 1.
  • Page 23 PKE operating instructions ·After turning off the motorcycle, please check if the steering lock is locked. If the steering lock is unlocked, please put the handlebar to the left, the motorcycle will be locked automatically. ·If the handlebar is not put to the left and turn off the motorcycle, it is forbidden to push the motorcycle or let the motorcycle slide, in case to put the handlebar to the left to lock the head lock, it is dangerous.
  • Page 24 PKE operating instructions The button is detected to be stuck “START” One long and after each power-on, and the alarm is button stuck two short once within 10 seconds (only once) After the button is stuck and then turned on, and the alarm will be Fuel tank lock One long and activated once in 10 seconds.

  • Page 25: Instrumentation

    Instrumentation 11 12 20 21 22 23 1. left turn indicator light; 2. neutral gear indicator light; 3. EFI malfunction signal light; 4. water temperature warning light; 5. low fuel warning light; 6. right turn indicator light; 7. high beam indicator light; 8. ABS signal light; 9. tire pressure warning light;...
  • Page 26 Instrumentation 3 Fuel injection error signal light When electricity and flameout switch of motorcycle is on but motorcycle is not started, it is normal that the EFI fault signal light remains on. If the EFI signal light is not on, please do not start the motorcycle; When the engine is started successfully, and during operation, if the yellow EFI fault signal light turns on reporting an EFI failure, it indicates that the EFI system is abnormal.
  • Page 27 Instrumentation 9. Tire pressure warning light Tire pressure warning light: It shows whether the front and rear tire pressure is faulty. When the tire pressure warning light is on, it means that the current tire pressure is faulty (when there is a fault, the tire pressure fault code will be displayed preferentially in the clock position.
  • Page 28 Instrumentation 14. Water temperature gauge After turnning on the motorcycle , turn on the handlebar's extinguishing switch, and only after the electric spray is powered on will the water temperature status be displayed, and one bar will be displayed to represent the water temperature ≤...
  • Page 29 Instrumentation 16.Front tire pressure/rear tire pressure Viewing method: In ODO mode, short press the SET button to switch the information in the mileage display area (total mileage → average speed → fuel consumption display → cruising range mileage→maintenance information→front tire pressure→rear tire pressure→total mileage...).
  • Page 30 Instrumentation 19.ODO long odometer/20.TRIP short odometer The mileage display area has eight functions: TRIP subtotal odometer, ODO total mileage, AVG average speed, fuel consumption display, cruising mileage, warranty Maintenance information, front tire pressure, rear tire pressure. Total mileage/subtotal mileage viewing switching method: in TRIP mode, short press the MOD button to switch to ODO mode;...
  • Page 31 Instrumentation Frequency 1HZ, DUTY50%, time 5S, and display how many kilometers remaining for maintenance. 3. When the oil maintenance kilometers are reached (the first 1000km, the subsequent Every 5000km), the oil maintenance mark above the mileage display area flashes (frequency 1HZ); Clear: In ODO mode, long press the MOD button, the priority will be cleared.

  • Page 32: Instructions For Fuel, Oil, Coolant And Gear Oil

    Engine oil Use high quality SN or above level four-stroke engine oil can prolong engine life. Please choose ZONTES API SN level or higher level of "four stroke motorcycle engine oil", It is on sale in all ZONTES shops. ·The unleaded gasoline, poor quality fuel oil and engine oil can damage the system components, and it will shorten the service life of catalyst in spark plugs and muffler.
  • Page 33 Instructions for Fuel, Oil, Coolant and Gear Oil Distill water for coolant/antifreeze If you need to add water, please use the distill water. If you use other kinds of water, it would probably do harm to the cooling system. coolant/antifreeze coolant/antifreeze can prevent routing and lubricate the coolant/antifreeze pump.
  • Page 34 Instructions for Fuel, Oil, Coolant and Gear Oil ·In order to correctly check the surface level of the coolant/antifreeze, we should put the motorcycle into the cooling engine condition. ·If the main water tank is empty, please check and repair the cooling system immediately.

  • Page 35: Inspection And Maintenance Routine

    Inspection and Maintenance First Inspection The initial 1000 kilometers of maintenance is one of the most important work. During this period, all engine parts should have good running-in. In the case, maintenance and repair should put all the parts to readjust, tighten all fasteners, replace parts abrasive dust pollution of the oil.
  • Page 36 Inspection and Maintenance The importance of these tests can never be neglected. Complete all of the inspection before driving and necessary repairs. · When you do the inspection, engine running status is more dangerous for you to inspect. If your hand or clothes are moving parts involved in the motorcycle, it will cause serious damage to you.

  • Page 37: Scheduled Maintenance Sheet

    Inspection and Maintenance Scheduled Maintenance Sheet :Check (clean, lubricate, adjust or replace if necessary) : Replace : Tighten Check Regular cycle First1000 Each5000 Each10000 before Inspection Item replacement Each 15 Each 30 frist 3 driving Air filter (filter) Muffler suspension hollow buffer gluer Muffler bolt, nut Engine oil...
  • Page 38 Inspection and Maintenance Check Each5000 Each10000 cycle First1000 before Torque settings Inspection Item Each 15 Each 30 frist 3 driving Anti-wear block of rear fork lift Fuel Evaporative Pollutant Control System Internal moving Check, clean mechanism of faucet and lubricate lockr Steering Bearings Check, clean, lubricate...

  • Page 39: Fuel Tank Removal

    Inspection and Maintenance Fuel Tank Removal Figure 1 Figure 2 Figure 3 Figure 4 The steps to remove the fuel tank are: 1. unplug the tail light connector (the connector is located on the right side of the bottom of the seat) and remove the seat; use a 6# hex to remove the two M8 bolts at the end of the fuel tank (Figure 1).

  • Page 40: Fuel Tank Inspection And Repair

    Inspection and Maintenance Fuel tank inspection and repair The fuel tank is located in front of the seat, when opening the outer fuel tank cover, make sure that the engine off switch is off and the whole vehicle must be energized to open the fuel tank cover. First, snap up the fuel tank cover ①...

  • Page 41: Lubrication Points

    Inspection and Maintenance Lubricating point For safe driving, you have to keep good lubrication which can maintain the smooth operation, and prolong service life. After using in harsh conditions, after the vehicle is wet by the rain, or after washing the vehicle, it should belubricated. Lubrication points are as follows: D:Chain oil G:Grease ①...

  • Page 42: Battery

    Battery Gel battery Removing the battery The battery is located under the driver's seat , please connect the positive and negative terminals and install the battery cover for the first time. Remove the battery in the following order: a. Turn off the motorcycle's power switch. b.
  • Page 43 ·Please purchase and use our special charger to ensure the extension of the service life of the battery. There are lead-acid battery chargers for sale in Zontes shop. Users who need them can go to Zontes shop to purchase the corresponding chargers according to the batteries equipped with the model.

  • Page 44: Instructions For Using The Battery

    Instructions for using the battery 1 The start of the new storage battery Storage battery installation a. Before installing the battery, check the appearance of the battery. The outer casing should be free of scars or cracks, the battery cover should be well sealed, and there should be no leakage, and the terminals should be free of skewing, deformation, etc.
  • Page 45 Instructions for using the battery 3.3 During use or charging, the battery has a peculiar smell, severe heat, discoloration, or deformation. Please remove the battery from the car body or the charger and stop it immediately 3.4 The gel battery is standard for motorcycles, please do not use it for other purposes than the start of the motorcycle..

  • Page 46: Charger Instructions

    Trickle mode charging Battery charger · Lithium battery needs to be charged with lithium battery charger, please buy our special charger, the chargers are available in ZONTES shop, it is forbidden to use other unqualified chargers to charge the battery...

  • Page 47: Air Filter Cartridge

    Air filter cartridge The air filter is located under the seat. If the air filter is clogged with dust, it will increase intake resistance, reduce power output and increase fuel consumption. Check and clean the air filter as follows. ·If under the condition of dusty drive, you should increase the frequency of clean or replace filter.

  • Page 48: Spark Plugs

    Air filter cartridge Oil Pipe 1. As shown in Fig. 4, the oil pipe is located on top of the rear flat fork. 2. As shown in Fig. 5, put a piece of paper or a rag on the rear fork under the oil pipe, and then remove the clamp and pipe plug with a pair of sharp- nosed pliers to drain the waste oil.

  • Page 49: Checking The Spark Plugs

    Spark plugs Checking the spark plugs According to the maintenance schedule, the spark plug should be removed for inspection regularly. The condition of the spark plug can indicate the condition of the engine. The ceramic insulator around the middle electrode of the spark plug should be light brown (the ideal color when the motorcycle is running normally).

  • Page 50: Engine Oil

    Engine oil Maximum oil level marking Minimum oil level marking Whether the engine can be durable, it is very important to select the high quality oil and regular replacement of new oil. Check the oil level and oil change on a regular basis is two important tasks of maintenance project. Checking the oil level Check the oil level, according to the following steps to check oil level.
  • Page 51 Tighten the oil drain bolt with a professional tool. (Tightening torque 25±3N.m) 6. Add 1000 ml (1050 ml if the oil filter has been replaced) of "ZONTES oil (SN5W-40/1L) or new API SN motorcycle 4-stroke engine oil with viscosity SAE5W-40/10W-40/10W-50 from the engine oil filler hole.

  • Page 52: Oil Filter

    Oil filter B side Engine oil filter seal ring Engine oil filter Fine filter spring Seal ring A side Engine oil filter cover 5.Before re-installing the oil filter cover: If necessary please replace the oil filter seal ring and O-ring on the oil filter cover, align the filter cover with the screw hole and press it in parallel with the mounting hole, Hold the fine filter cover by hand and pre-tighten the 3 cap nuts ,the end face (A side) of the filter cover is attached to the end face (B side) of the mounting hole.

  • Page 53: Clutch Cable Clearance

    ·Maintain and adjust the clutch should be performed by the designated company service units. ·The adjustment and maintenance of the clutch shall be carried out by a dealer authorized by ZONTES. Adjustment progress： (1) Loose lock nut ①. (2) Turn the adjusting screw ② to adjust the clearance lasso, within the range of 0.5~1.0mm.

  • Page 54: Idling Speed

    Clutch cable clearance Idling Speed When you check the engine idle speed, it should be performed under the hot condition of the engine. engine idle speed range should be between 1500 to 1700RPM. ·If the idle speed of engine is beyond the scope of regulation, please let the designated company service units to check the motorcycle.

  • Page 55: Usb Port

    USB port Charge USB port data: Input voltage: 12V-24V; output voltage: 5V; output voltage: 2A. Characteristic: 1.Waterproof cover can prevent water and dust from getting inside to extend the usage life of the charger. 2.Intelligent IC design. It will automatically adjust the charging speed according to the battery volume and type.

  • Page 56: Drive Chain

    7. Whether the chain has reached the end of its service life. ·If it is found that there is something wrong with the drive chain or improper adjustment, please contact the authorized dealer of zontes for repair. Good tooth profile wear tooth profile A worn transmission chain often means that the sprocket and the anti-friction block of the rear flat fork are also worn.

  • Page 57: Cleaning And Lubricating The Drive Chain

    Drive chain Cleaning and lubricating the drive chain Clean and lubricate the drive chain regularly as follows. 1. Remove dirt and dust from the chain. 2. Clean the chain with chain cleaner or water and neutral detergent, and use a fine soft brush to clean the dirt and dust on the surface of the chain rollers. 3.
  • Page 58 Drive chain 1. Remove the protective rubber covers on the left and right of the rear axle. 2. Loosen (not necessary to completely unscrew) the rear axle bolts ① with a 19#, 21# spanner or socket. 3. Lower the side stand to support the motorcycle. 4.

  • Page 59: Brake System

    Brake system This motorcycle front and rear wheel assembly of the disc brake. The right brake operation is very important for safe driving. Remember to regularly check the braking system, and the inspection qualified maintenance unit to complete. ·Brake is highly significant components of personal safety; you should regularly check and adjust the brake, and regular cleaning the sediment on the brake caliper etc, to prevent obstacles to the movement of the piston.

  • Page 60: Brake Fluid

    Brake system Check the brake fluid level position in front and rear brake fluid cylinder. If the liquid level in the LOWER (low) below the mark, check the brake wear and brake fluid leakage. ·Don't wash brake cylinder directly with high pressure water. ·If swallowed into the brake fluid, it will cause harm to people, and even deadly.

  • Page 61: Rear Brake Pedal Adjustment

    Brake system ·If you just change one pair of brake piece, it can cause the brake to not be smooth. You should replace a pair of brake at the same time. ·If the location of the brake piece is wrong, please do not operate the brake handle or the brake pedal.
  • Page 62 Brake system · If the adjustment is not correct, brake piece and brake disc will be forced all the time which can damage the brake and the brake disc, when it is severe it will lead to high temperature for the rear brake, produce gas resistance, the rear wheels lose braking force.

  • Page 63: Tires

    Tires ·Do not pay attention to the following matters may be accident caused by the failure of the tire. Tires connect the motorcycle and ground, so it is very important. Observe the following rule: ·Check the tires and tire pressure condition, adjust the tire pressure before each use.

  • Page 64: Tire Condition And Specifications

    Tires Tire condition and specifications Incorrect tire status and incorrect tire size affect the performance of the motorcycle. If there is any breakage in the tire scratches, it can lead to faulty tires and make the vehicle out of control. Excessive wear of tires can make tires perforation and the vehicle out of control.

  • Page 65: Tire Removal

    Tire removal Front-wheel disassembly ① ② ③ Front-wheel axle tightening torque: 55N.m Tightening torque of front axle locking bolt: 20N.m Front caliper mounting bolt tightening torque: 25N.m Front-wheel removal 1. Support the motorcycle with the special support bracket. 2. Loosen the 2 bolts ① connecting the front caliper on the front shock absorber and remove the front caliper.
  • Page 66 If you don't know how to operate,please contact the authorized dealer of ZONTES for repair · After installation of the rear wheel, brake position is not correct will affect the braking effect and may cause an accident.

  • Page 67: Lighting & Lamps

    Lighting & Lamps Please refer to the instruction of the front part “check before driving” for the illumination and signal inspection. Front brake switch Rear brake switch Front brake switch The front brake switch locates on front brake lever. Braking lights are on when rider grab the brake lever with a slightly tight feeling.

  • Page 68: Fuses

    Fuses Fuse wire Main fuses, ECM fuses, constant power fuses, hydraulic unit motor fuses, hydraulic unit ECU fuses, light fuses, spare fuses are located in two main fuse blocks, starter fuses, ABS fuses, auxiliary fuses, and other fuses are located in the secondary fuse box.

  • Page 69: Troubleshooting

    Troubleshooting The content of the troubleshooting can help you to find the cause of the general issues. ·Improper maintenance and adjustment can damage the motorcycle and cannot determine the cause of the problem. We can't guarantee such damage. If you are not sure how to correct operation, consult the designated company service units.

  • Page 70: Carbon Cleaning

    Troubleshooting Engine short of power When engine power significantly decreased or a larger decline on original top speed, it may be the blocking of the engine fuel system make the work of engine is not normal, please immediately go to the company dealers maintenance unit for inspection.

  • Page 71: Efi Precautions

    EFI Precautions Fuel injection attention: 1.Before the installation of battery for new motorcycle, we should inspect that whether the connection for the fuel injection spare parts is fixed and reliable including the installation of oxygen sensor. Moreover, make sure to fill in the gas.
  • Page 72 EFI Precautions 1.When the engine is running, if the EFI failure indicator on the instrument is on, it indicates that there is a fault in the EFI component that needs to be eliminated. a.Turn the throttle to the maximum before energizing the motorcycle and keep it in the fully open position, then turn on the electric lock and engine switch.
  • Page 73 EFI Precautions P0134 Upstream 1 cylinder oxygen sensor circuit signal failure P0201 1 cylinder injector controlis open circuit P0261 1 cylinder injector control circuit is short circuit to ground P0262 Intake pressure sensor is short circuit to power supply P0322 Speed-Sensorless pulse signal (open circuit or short circuit) P0511 Idle speed actuator control is opencircuit...
  • Page 74 EFI Precautions ·When the engine is running, broken light is not on. When you turn off, the signal light is flashing. It means that is historical error and it has nothing to do with the whole motorcycle. After that it will disappear.

  • Page 75: Adding Electrical Components

    Adding electrical components Reserve port for modification Anti-theft plug OBD diagnostic interface...

  • Page 76: Storage Methods

    Storage Methods Storage method If you are not using motorcycle for a while, the motorcycle needs special maintenance, this requires some special materials, equipment and technology. For this reason, it is recommended that you choose the company service units to complete the maintenance work. If you want to complete the work, please click the following method: Motorcycle Thoroughly clean the motorcycle.
  • Page 77 Storage Methods 6.Make sure motorcycle lubrication is normal. 7. Inspect the motorcycle in accordance with the content of instruction for use in the inspection section before driving. 8.Restart the motorcycle in accord with the instruction. Corrosion prevention Maintain the motorcycle carefully. Corrosion prevention is very important. In doing this, your motorcycle will look like new even after many years.

  • Page 78: Inspection After Cleaning

    Inspection after cleaning Clean the motorcycle Clean the motorcycle accord with the following: 1.Use cold water to wash away dirt and mud on the surface of the motorcycle. You can use the soft sponge or soft brush to clean. You could scratch appearance parts with hard materials to clean.

  • Page 79: Transportation

    Inspection after cleaning In order to prolong the service life of the motorcycle, lubricate the motorcycle according to the instruction. ·It is very dangerous to drive a motorcycle when the brake is wet. Wet brake is unable to provide braking force such as dry brake. This can cause an accident.

  • Page 80: Cleaning The Motorcycle

    Cleaning the motorcycle c.Do not overcharge the battery. Overcharging will cause the battery to leak, bulge or even burst, which will cause varying degrees of danger. 3. Attention 3.1 This battery is a maintenance free gel battery. It is strictly forbidden to open or modify the battery without permission.
  • Page 81 Cleaning the motorcycle 1 The start of the new storage battery Storage battery installation a. Before installing the battery, check the appearance of the battery. The outer casing should be free of scars or cracks, the battery cover should be well sealed, and there should be no leakage, and the terminals should be free of skewing, deformation, etc.
  • Page 82 155C-Specification sheet Length......................... 2100mm Width........................845mm Height........................1120mm Wheel base......................1485mm Ground clearness....................142mm Seat height......................7 00mm Full load weight....................... 153kg Engine Type ..........Single-cylinder, horizontal, four-stroke, water-cooling Cylinder number ......................1 Cylinder bore ...................... 58.0mm Stroke ........................58.7mm Displacement ......................155ml Compression ratio....................12.5:1 Start-up mode ..................Electric starting Lubricating system ........Splash lubrication plus pressure lubrication Power........................
  • Page 83 125C-Specification sheet Length......................... 2100mm Width........................845mm Height........................1120mm Wheel base......................1485mm Ground clearness....................142mm Seat height......................7 00mm Full load weight....................... 153kg Engine Type ..........Single-cylinder, horizontal, four-stroke, water-cooling Cylinder number ......................1 Cylinder bore ...................... 52.0mm Stroke ........................58.7mm Displacement ......................125ml Compression ratio....................12.5:1 Start-up mode ..................Electric starting Lubricating system ........Splash lubrication plus pressure lubrication Power........................
  • Page 85 W W W. K I D E N . C N...
