V-TAC VT-91100CCT Instruction Manual

TECHNICAL DATA
MODEL
VT-91100CCT
SKU
23622
WATTS 100W
LUMENS
8300 LM
@WIDE CONE
INPUT VOLTAGE
BEAM ANGLE
LIFE SPAN
ON/OFF CYCLE
CRI
DF
SAFETY CLASS
MATERIAL
WIRE LENGHT
OPERATING TEM-
PERATURE
N.W (KGS)
0.56KGS/PC
MAX PROJECTED
30-20m
2
AREA
MAX. MOUNTING
6-4m
HEIGHT
DIMENSION
Ø235x235x32mm
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installation and keep this manual handy for future reference. If you have any another query, please contact
our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.
The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by incorrect
installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect
removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24
Hours a day would void the warranty. This product is warranted for manufacturing defects only.
WARNING
1. Please make sure to turn off the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable; when the light source
reaches its end of life the whole luminaire shall be replaced.
4. The external flexible cable or cord of this luminaire cannot be replaced; if
the cord is damaged, the luminaire shall be destroyed.
5. Proper grounding should be ensured throughout the installation.
6. Terminal block not included.
7. To be connected with waterproof cable hose.
8. Replace any cracked protective shield.
9. Minimum distance from lighted objects 1m.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
LED HIGHBAY
VT-91150CCT
23623
150W
12300 LM
AC: 220-240V, 50/60hz
90°
20,000 Hours
15,000 Times
≥80
≥0.9
Class 1
Aluminium
250mm±10mm
-20°C to +40°C
0.79KGS/PC
40-30m
2
7-5m
Ø277x277x32mm
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
