V-TAC VT-2405 Instruction Manual

Rf controller
Hide thumbs

Advertisement

Quick Links

Download this manual
TECHNICAL DATA
MODEL
SKU
OUTPUT
STATIC POWER CONSUMPTION
IP RATING
OUTPUT CURRENT
OUTPUT POWER
SUPPLY VOLTAGE
REMOTE OPERATION BAND
REMOTE OPERATION FREQUENCY 433.932 Mhz
INTRODUCTION
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before
starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer
or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.
REMOTE CONTROL SAFETY INSTRUCTIONS
•
Before using this product, make sure that all parts are configured correctly according to the
instructions in the attached instruction.
•
The product should not be used by persons under 5 years of age without supervision by a
parent or guardian.
•
Ensure that the power batteries are configured correctly and have the appropriate parame-
ters as specified by the manufacturer.
RF CONTROLLER SAFETY INSTRUCTIONS
•
Make sure that the Input voltage of this product is as prescribed by the manufacturer. Other incoming voltages can cause the
product to break down and potentially harm the environment and your health.
•
The wires must be connected correctly and in accordance with the colors of the wire and the instructions given in the circuit
diagram described in this instruction.
•
Make sure before switching on that the power elements have a power lower than that specified by the manufacturer .
•
Make sure before plugging in that the led strip voltage is suitable for configuration with this product.
•
This product is suitable for products manufactured by the company V-TAC, when connecting with products of other compa-
nies, V-TAG is not responsible for any adverse consequences for your health.
•
The initial installation of the product must be done by a specialist with the relevant qualifications and skills.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
INSTRUCTION MANUAL
RF CONTROLLER
VT-2405
3312
3 Channels(One Group RGB)
<1W
IP20
4A (Each Channel)
12V-144W, 24V-288W
DC: 12V, 24V
433.050Mhz to 434.790 Mhz
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
