V-TAC VT-9-116S-1 Instruction Manual

TECHNICAL DATA
MODEL
VT-9-116S-1
SKU
21203191
WATTS
100W
LUMENS
16000LM
INPUT VOLTAGE
BEAM ANGLE
LIFE SPAN
ON/OFF CYCLE
CRI
PF
SAFETY CLASS
MATERIAL
WIRE LENGHT
N.W (KGS)
0.79KGS/PC
MAX. MOUNTING
<5M
HEIGHT
DIMENSION
Ø250x70.1mm
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installation and keep this manual handy for future reference. If you have any another query, please contact
our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.
The warranty is valid for 5 years from the date of purchase. The warranty does not apply to damage caused by incorrect
installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect
removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24
Hours a day would void the warranty. This product is warranted for manufacturing defects only.
WARNING
1. Please make sure to turn off the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person.
4. The external flexible cable or cord of this luminaire cannot be replaced; if
the cord is damaged, the luminaire shall be destroyed.
5. Proper grounding should be ensured throughout the installation.
6. Terminal block not included.
7. To be connected with waterproof cable hose.
8. Replace any cracked protective shield.
9. Minimum distance from lighted objects 1m.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
INSTRUCTION MANUAL
LED HIGHBAY
VT-9-156S-1 VT-9-206S-1
21203211 21203231
150W 200W
24000LM 32000LM
AC: 220-240V, 50/60hz
SPHERE 360°
25,000 Hours
15,000 Times
>70
>0.9
Class 1
Aluminium
250mm
1.2KGS/PC 1.4KGS/PC
<5M <5M
Ø295x70.1mm Ø320x70.1mm
*This product contains a light source of energy effi-
ciency class<C>, where <C> shall be replaced by the
energy class of the contained light source.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
