Bticino LIGHTNOW YW4003CW Manual

Wireless switches
YW4003CW
YG4003CW
YD4003CW
Use
Surface installation with repositionable stickers (supplied) or onto a flush mounting
box. Integrated LED for low battery indication.
Powered by battery 3V type CR2032 (supplied) with an autonomy of 8 years.
- 2 modules.
Range
Designation
Connected wireless control equipped with 2 buttons for
ON/OFF and dimming control of one or more connected
devices for the lighting control.
Connected wireless control for roller shutters.
Connected wireless control for multicolour lighting.
Connected wireless control for Home/Away scenario.
Connected wireless control for Wake Up/Sleep scenario.
Colors: White Stone
Dimensions (mm)
B
A B
76 101
www.bticino.com
YW4027CW
YG4027CW
YD4027CW
Cat. Nos.
YW4003CW
YG4003CW
YD4003CW
YW4027CW
YG4027CW
YD4027CW
YW4007CW
YG4007CW
YD4007CW
YW4570CW
YG4570CW
YD4570CW
YW4574CW
YG4574CW
YD4574CW
Dark
C
C
11.3
IDP001915_01-EN
YW4003CW - YG4003CW - YD4003CW
YW4027CW - YG4027CW - YD4027CW
YW4007CW - YG4007CW - YD4007CW
YW4570CW - YG4570CW - YD4570CW
YW4574CW - YG4574CW - YD4574CW
YW4570CW
YW4007CW
YG4570CW
YG4007CW
YD4007CW YD4570CW
Technical characteristics
- Mechanical characteristics
Protection against impacts:
Protection against solid bodies/liquids: IP 20 without plate and rocker plate
- Material characteristics
Mechanism with grid: Fibreglass-reinforced (10%) PC
Mechanism functional cover: PC/ABS
Halogen-free
UV resistant
Self-extinguishing: 650°C/30 s
- Electrical characteristics
Powered by a CR2032 - 3 V lithium battery (supplied)
Battery life:
ZigBee radio technology frequency: 2.4 GHz to 2.4835 GHz
Power level:
Wireless mesh network, self-adaptive and secure (AES 128), conforming to
standard IEEE 802.15.4 (LR-WPAN)
- Climate characteristics
Usage temperature: +5°C to +45°C
Storage temperature: 0°C to +45°C
Standards and approvals
The undersigned, BTICINO, declares that the radio-electric equipment type (YW4003CW -
YG4003CW -YD4003CW - YW4027CW - YG4027CW -YD4027CW - YW4007CW - YG4007CW
-YD4007CW - YW4570CW - YG4570CW -YD4570CW - YW4574CW - YG4574CW -
YD4574CW) complies with directive 2014/53/EU. The full text of the EU declaration of
conformity is available on the following website: www.bticino.it/red
29/08/2024
YW4574CW
YG4574CW
YD4574CW
IK 02
8 years for 10 activations a day
< 100 mW
1
