Bticino LIGHTNOW YW4003DCW Manual

Wireless double control switches
Use
Surface installation with repositionable stickers (supplied) or onto a flush mounting
box. Integrated LED for low battery indication.
Powered by battery 3V type CR2032 (supplied) with an autonomy of 8 years.
- 2 modules.
Range
Designation
Double wireless light switch. Each single button can
be associated with one or more devices.
Wireless 4 scenarios control. It's equipped with 4
buttons for activating of scenarios 1,2,3 and 4.
Scenarios can be customized by the Home+ Control
app.
Colors:
White Stone
Dimensions (mm)
B
A B
76 101
www.bticino.com
YW4003DCW
YG4003DCW
YD4003DCW
Cat. Nos.
YW4003DCW
YG4003DCW
YD4003DCW
YW4575CW
YG4575CW
YD4575CW
Dark
C
C
11.3
IDP001916_01-EN
YW4003DCW - YG4003DCW - YD4003DCW
YW4575CW - YG4575CW - YD4575CW
Technical characteristics
- Mechanical characteristics
Protection against impacts:
Protection against solid bodies/liquids: IP 20 without plate and rocker plate
- Material characteristics
Mechanism with grid: Fibreglass-reinforced (10%) PC
Mechanism functional cover: PC/ABS
Halogen-free
UV resistant
Self-extinguishing: 650°C/30 s
- Electrical characteristics
Powered by a CR2032 - 3 V lithium battery (supplied)
Battery life:
ZigBee radio technology frequency: 2.4 GHz to 2.4835 GHz
Power level:
Wireless mesh network, self-adaptive and secure (AES 128), conforming to
standard IEEE 802.15.4 (LR-WPAN)
- Climate characteristics
Usage temperature: +5°C to +45°C
Storage temperature: 0°C to +45°C
Standards and approvals
The undersigned, BTICINO, declares that the radio-electric equipment type
(YW4003DCW - YG4003DCW - YD4003DCW - YW4575CW - YG4575CW -YD4575CW)
complies with directive 2014/53/EU. The full text of the EU declaration of conformity is
available on the following website: www.bticino.it/red
29/08/2024
YW4575CW
YG4575CW
YD4575CW
IK 02
8 years for 10 activations a day
< 100 mW
1
