Sylvania DVL515SL Owner's Manual

1. Connections
See CONNECTION GUIDE
2. To play DVD/CD
See
3. Remote Control Operation
See
4. Remote Control Operation for LCD TV
See
5. To set the V-CHIP SET UP
See
6. More details for DVD/CD player Operation
See owner's manual
for DVL515SL
7. More details for LCD TV Operation
See owner's manual
for DVL515SLD
Printed in China
★★★★★
1VMN21151 / E61T5UD
B
REMOTE CONTROL OPERATION
EJECT
TV POWER REPEAT A-B
SLEEP
INPUT SELECT
1 2 3
SUBTITLE
4 5 6
AUDIO
7 8 9
CH.RETURN +100 DISPLAY
0 +10
MUTE TV DVD TV SETUP
DVD SETUP
CH.
VOL.
VOL.
CH.
DISC MENU TOP MENU DVD POWER
ENTER
MODE
SEARCH
CLEAR RETURN
MODE
PAUSE PLAY SKIP
STOP ANGLE
NB139
Shaded Buttons are for
DVD/CD player
(DVL515SL) only
Please refer to the owner's
manual for DVL515SL.

QUICK GUIDE

A
on this guide
B
on this guide
C
on this guide
D
on this guide
You can operate the LCV TV (DVL515SLD) and the DVD/CD player (DVL515SL) with the supplied remote control.
• Remote control buttons printed in black are for DVD/CD Player, blue buttons are for TV and yellow buttons are for both.
• Press [TV] first to operate the LCD TV with the remote control.
• Press [DVD] first to operate the DVD/CD player with the remote control.
• Pressing [SEARCH MODE] will switch the remote control to the DVD mode automatically.
Buttons for both LCV TV (DVL515SLD)
and DVD/CD player (DVL515SL)
(Buttons printed in yellow)
TV mode
Button
(For LCD TV)
1 2 3
• To select channels
4 5 6
• To enter 4-digit access
code for the V-CHIP
7 8 9
+100
SET UP
0 +10
A-B
• To set the sleep timer
SLEEP
(Sleep timer function)
DISPLAY
• To display CH No./Audio
status
TV SETUP
• To call up the main menu
of the LCD TV
DVD SETUP
A
TO PLAY DVD/CD
• Details for playable discs, please
refer to page 5 in owner's manual
for DVL515SL.
TV POWER REPEAT A-B EJECT
2 SLEEP
INPUT SELECT
1 2 3
SUBTITLE
4 5 6
AUDIO
7 8 9
CH.RETURN +100 DISPLAY
0 +10
MUTE TV DVD TV SETUP
3
DVD SETUP
CH.
7
VOL.
VOL.
CH.
DISC MENU TOP MENU DVD POWER
7
MODE ENTER
SEARCH
CLEAR RETURN
MODE
PAUSE PLAY SKIP
6
STOP ANGLE
8
NB139
1
1
Connect the LCD TV, the DVD/CD player
and the speaker unit.
• Refer to CONNECTION GUIDE.
2
2
Turn on the LCD TV.
TV POWER
DVD mode
(For DVD/CD player)
• To select chapter, title
or track directly
• To set the starting (A)/
ending(B) points during
playback for A-B repeat
• To display the current
disc mode
• To call up the DVD setup
menu of the DVD/CD player
3 3
Select "VIDEO1".
TV INPUT SELECT
4
4 Turn on the DVD/CD player.
• The opening picture appears on the LCD
9
TV sccreen.
3
DVD POWER
5
5 Insert a disc to the DVD/CD player with
label facing to the left.
6
8
6
6
Start playback.
DVD
4
7
7 Adjust the volume of the LCD TV.
TV
VOL.
Adjust the volume of the speaker unit.
[Speaker Unit (right)]
8
8
Stop playback.
DVD STOP
9
9
Eject the disc.
EJECT
• For further details, please refer to the
owner's manual for DVL515SL.
Buttons for LCV TV (DVL515SLD) only
(Buttons printed in blue)
Button
CH.
• To select channels
• To select an item on the LCD
CH.
TV menu
CH.RETURN
• To return to previous channel
INPUT SELECT
• To select TV or external input
MUTE
• To mute sound
TV
• To activate the remote control
in TV mode
TV POWER
• To turn the LCD TV on/off
• To adjust volume
• To change the setting on the
VOL.
LCD TV menu
VOL.
:To advance to the next
VOL. on the LCD TV menu
VIDEO1
PLAY
or
VOL.
1. Turn on.
2. Adjust.
TV mode
(For LCD TV)
