Owner's Manual
Please read before using this unit.
DVD/CD Player
DVL515
Setting the Main Unit
You can install this unit horizontally or vertically.
Horizontal installation (laying position):
1)Attach the Foot to the bottom of the unit.
Foot
(supplied)
2)Place the unit as [POWER] comes on your right.
label
Vertical installation (standing position):
1) Attach the Foot to the bottom of the Stand.
Foot
(supplied)
2)Place the unit as its dent matches the catch of
the Stand. As you position the unit be sure
[POWER] is located at the top.
Catch
Stand
Front
Changing the front panel
The front panel can be
exchanged with the sup-
plied colored panel.
1)Unhook the stopper on
the bottom of the panel
to detach it.
2)Hook the catch on top
of the panel to the unit
and push the lower
part of the panel until
the stopper fits in.
Hint
Hint
• Make sure the hooks on side of the panel are also set correctly to
operate the player with the front panel buttons.
Bottom of the unit
Hint
Hint
• Insert a disc with the label
facing up.
Stand
(supplied)
Hint
Hint
• Insert a disc with its
label facing to the
left.
Stopper
Catch
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Table of Contents

Precautions
Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
■ Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . 3
Moisture Condensation Warning . . . . . . . . . . . . . . . . . . 3
Supplied Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Notice for Progressive Scan Outputs . . . . . . . . . . . . . . . 4
Symbols Used in This Manual . . . . . . . . . . . . . . . . . . . . 4
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
■ About the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unplayable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
■ Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connection to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
RF Modulator Connection . . . . . . . . . . . . . . . . . . . . . . . 6
Connection to an Audio System . . . . . . . . . . . . . . . . . . . 7
Rear Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
■ About the Remote Control . . . . . . . . . . . . . . . . . . . . . 8
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
■ Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
■ MP3/WMA Playback . . . . . . . . . . . . . . . . . . . . . . . . . . 10
■ Search Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Track Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 10
Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
■ On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
■ Marker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Repeat A-B Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 12
Random Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Programmed Playback. . . . . . . . . . . . . . . . . . . . . . . . . 12
■ Special Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Camera Angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
■ DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
LANGUAGE Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DISPLAY Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
AUDIO Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PARENTAL Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
OTHERS Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
(Except for PARENTAL Setting) . . . . . . . . . . . . . . . . . . 17
■ Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . 17
■ Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
■ Language List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
■ Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Quick Use Guide . . . . . . . . . . . . . . . . . . . . . .Back Cover
If you need additional operating assistance after
reading this owner's manual, please call
TOLL FREE : 1-800-968-3429
or visit our web site at
http://www.SylvaniaConsumerElectronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVL515 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sylvania DVL515

  • Page 1: Table Of Contents

    Owner’s Manual Please read before using this unit. DVD/CD Player DVL515 Setting the Main Unit You can install this unit horizontally or vertically. Horizontal installation (laying position): 1)Attach the Foot to the bottom of the unit. Foot (supplied) Bottom of the unit 2)Place the unit as [POWER] comes on your right.
  • Page 2: Laser Safety

    WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS 1) Read Instructions - All the safety and operating instruc- tions should be read before the product is operated. 2) Retain Instructions - The safety and operating instruc- tions should be retained for future reference. 3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.
  • Page 4: Supplied Accessory

    Supplied Accessory • Remote control • Audio/Video cables (NB071UD) (WPZ0102TM015/ with two AA WPZ0102LTE01/ batteries WPZ0102CAB01) • Detachable • Foot Replacement (1VM421328) Panel (blue:1VM321211) (pink:1VM320996) Installation Location For safety and optimum performance of this unit: • Do not place anything directly on top of the unit. Do not place the unit directly on top of the TV.
  • Page 5: About The Discs

    About the Discs Playable Discs Playable Mark (logo) discs DVD-Video * 1, 2, 4, 6, 10 DVD-RW DVD-R * 1, 3, 4, 5, 6, 7, 9, 10 DVD+RW DVD+R * 1, 3, 4, 5, 6, 8, 9, 10 Audio CD * 4, 6, 10 CD-RW CD-R...
  • Page 6: Connections

    Connections If your TV has AUDIO/VIDEO input jacks, see the following instructions. Connection to a TV Basic Audio AUDIO IN (INPUT) Audio cable (supplied) This unit (OUTPUT) (Analog) AUDIO OUT Hint Hint • Connect this unit directly to the TV. If the Audio/Video cables are connected to a VCR, pictures may be distorted due to the copy protection system.
  • Page 7: Connection To An Audio System

    Connection to an Audio System Method 1 Stereo system Analog audio input jacks AUDIO Audio cable (supplied) This unit (Analog) AUDIO OUT Setting Connection Connecting to Stereo System. * To complete these settings, refer to pages 14-15. Hint Hint • Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers.
  • Page 8: About The Remote Control

    About the Remote Control Remote Control POWER EJECT SEARCH DISPLAY MODE AUDIO SUBTITLE ANGLE REPEAT CLEAR SKIP PAUSE SLOW PLAY STOP SETUP TOP MENU MENU MODE ENTER ZOOM RETURN Installing the Batteries for the Remote Control Install two AA batteries (supplied) matching the polarity indicated inside battery compartment of the remote control.
  • Page 9: Functions

    Operations described after this section are mainly based on the remote control use. Some operations can be carried out on main unit. Playback Before: Turn on the TV, amplifier and any other equipments which are connected to this unit. Make sure the TV and audio receiver (commercially available) are set to the correct channel.
  • Page 10: Mp3/Wma Playback

    MP3/WMA Playback MP3/WMA is a method of compressing files. You can copy MP3/WMA files on CD-R/RWs from the computer and play the files on this unit. Insert an MP3/WMA-format disc, then hit [MENU] to call up the file list on the TV screen. MENU FILE LIST DISC NAME...
  • Page 11: On-Screen Display

    On-Screen Display You can check the information about the current disc by hitting [DISPLAY] on the remote control. Angle icon, appears only when DVD-V DVD-V available on the DVD Current playback status 11/16 0:00:00 - 0:03:30 Remaining time of the current chapter Elapsed time of the current chapter CH(Chapter): Current chapter number / Total chap-...
  • Page 12: Repeat / Random / Programmed Playback

    Repeat / Random / Programmed Playback Repeat Playback DVD-V DVD-V Repeat function is available only during playback. PLAY REPEAT Each time you hit [REPEAT], repeat function changes as example below. DVD-V DVD-V (current chapter repeat) CHAPTER TITLE (current title repeat) (repeat off) (current track repeat) TRACK...
  • Page 13: Special Settings

    Special Settings Subtitle Language DVD-V DVD-V This unit allows you to select a subtitle language (if available) during DVD play- back. PLAY 1.ENG/6 SUB TITLE Each time you hit [SUBTITLE], subtitle language changes as example below. (English subtitles) (French subtitles) (no subtitles) To set subtitle ON/OFF PLAY...
  • Page 14: Dvd Setup

    DVD Setup UICK SETUP Men UICK SETUP Men You can select the “PLAYER MENU”, “TV ASPECT” or “DOLBY DIGITAL” from the QUICK SETUP menu quickly. SETUP STOP <SETUP MENU> Confirm that “QUICK” is selected. QUICK SETUP PLAYER MENU ENGLISH TV ASPECT 4:3 LETTER BOX DOLBY DIGITAL BITSTREAM...
  • Page 15: Display Setting

    DISPLAY Setting You can change the display functions. Follow steps 1) to 3) in the “CUSTOM Menu” section on page 14. Select the desired item. TV ASPECT: (Default: 4:3 LETTER BOX) See Hint to the right. DISPLAY menu DISPLAY TV ASPECT 4:3 LETTER BOX STILL MODE: STILL MODE...
  • Page 16: Parental Setting

    PARENTAL Setting Parental Control limits the disc viewing that exceed your settings. (An incorrect password will not play.) This feature prevents your children from viewing inappropriate materials. arental vels arental vels Parental Level allows you to set the rating levels of your DVD discs. Playback will stop if the ratings exceed the levels you set. Follow steps 1) to 3) in the “CUSTOM Menu”...
  • Page 17: Reset To The Default Setting (Except For Parental Setting)

    Reset to the Default Setting (Except for PARENTAL Setting) SETUP STOP <SETUP MENU> QUICK SETUP PLAYER MENU ENGLISH TV ASPECT 4:3 LETTER BOX DOLBY DIGITAL BITSTREAM Troubleshooting Guide If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit consulting the fol- lowing checklist.
  • Page 18: Specifications

    13. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.) LIMITED WARRANTY FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows:...
  • Page 19: Español

    Conexiones Si su televisor tiene entradas de AUDIO/VIDEO vea la sección “Connection to a TV” en la página 6 en el Manual de Manejo. En caso contrario, vea la sección “RF Modulator Connection” en la página 6 en el Manual de Manejo. Instalación de las pilas en el control remoto Para cambiar el idioma...
  • Page 20: Remote Control

    Connections If your TV has AUDIO/VIDEO input jacks, see the section “Connection to a TV” on page 6 of the Owner’s Manual. If not, see the section “RF Modulator Connection” on page 6 of the Owner’s Manual. Installing the Batteries for the Remote Control To Change the On- Screen Language...
