LAZBOY High Leg Swivel Occasional Chair Unpacking & Assembly Instructions

Unpacking & Assembly Instructions
High Leg Swivel Occasional Chair
Unpacking & Assembly Instructions
– Risk of serious injury or death:
DANGER

To prevent suffocation, keep plastic bags away
from children.
Tools Required:
Utility Knife
Power Driver
T30 Bit
1/2 inch Socket Wrench
Torque Wrench
– Risk of injury:
CAUTION

Always wear safety goggles or glasses when
unpacking and assembling furniture.
CAUTION – Risk of product damage:

Do not drop the unit. Dropping the unit may damage
the frame.
Please read through all instructions prior to
unpacking and assembling the chair.
Remove Chair from Carton:
Always open and remove high leg swivel chairs
from the BOTTOM of the carton, and not the
top of the carton, to reduce the chance for
damage.
1. Carefully turn boxed chair onto its side,
with the print side up as shown, to gain
access to the bottom of the carton.
2. Use a utility knife to cut the tape securing
the bottom flaps and break the seal. Cut as
indicated by green arrows and lines.
3. Open bottom of carton by turning the top
flap up and the bottom flap down. Remove
honeycomb from bottom of carton.
4. Slowly pull the chair out of the carton, until
it reaches the edge of the bottom corrugated
flap, and rotate chair to its upright position.
Move carton away from chair.
5. Remove plastic bag from chair body.
Remove the showwood leg and fastener
bag assembly from the seat and carefully
unpack. Recycle all packaging materials
appropriately.
1 of 3
WI300003
Revision 02.10/2023
