LAZBOY Luca Ottoman Assembly Instructions

©2006 La-Z-Boy Incorporated
Read the enclosed Safety Instructions before beginning assembly.
Assembly Instructions
1. Place the ottoman top, upholster y side down, on a smooth, clean surface
to prevent damage.
2. Position the four legs in the corners of the ottoman as shown.
3. Add a flat washer to each 2
4. Insert the 2
corner blocks. Hand start the bolts into the threaded inserts, two per leg, but
do not tighten.These bolts must be loose to attach the shelf.
5. Slide the bottom shelf into the notches on the legs, with the diagonal holes
in the corners facing up.
6. Use the wrench provided to tighten the 2
7. Insert the 1
leg. Use a #2 Phillips head screwdriver (not provided) to secure the bottom shelf
to the legs.
8. Turn the ottoman to the upright position.
F
IGURE
93000504 11/06
Luca Ottoman Assembly Instructions:
1 ⁄ " bolt.
4
1
⁄ " bolts with the flat washers through the holes in the diagonal
4
1 ⁄ " bolts to secure the legs.
4
1 ⁄ " wood screws through the diagonal holes in the bottom shelf, one per
2
2 1 ⁄ '' Bolts with Flat
1
4
Washers (Qty. 8)
Save These Instructions
F 2
IGURE 1 1 ⁄ '' Wood
2
Screw (Qty. 4)
