elmeasure IOT30 Quick Start Manual

Quick Start Guide
IOT30/IOT10
True RMS measurement
Simultaneous sampling of Voltage and Current
Star and Delta phase programmable wiring connections.
Programmable CT ratio.
Self auxiliary.
User programmable password protection.
Energy resetting at 99999999 KVAh*MF
Energy import and Export, number of interruptions available.
Individual phase energy and Load hours through communication.
CO2 emission.
Phase angle measurement.
Last and present minute values-VLL and Amps
Load efficiency for selected parameter-W/A
Dynamic Communication-User Selectable address with selectable parameters.
2. WI-FI INTERFACE SPECIFICATION
Wi-FiInterface : 802.11 b/g/n
Frequency: 2.4 GHz ~ 2.5GHz
Security: WPA/WPA2, WPA-PSK/WPA2-PSK
Encryp on: WEP/TKIP/AES
Network Protocol: IPv4,TCP
Receive Sensi vity: 83 dBm typical
Communica on protocol: Modbus TCP server, Modbus RTU over TCP, MQTT (RAW format - up to 8
blocks and JSON format – 1 standard block)
3. WI-FI INTERFACE SETTING
Power up the meter and go to the wifi access page. Showing SSID: ELM_meter sl no and connect the
meter sl no by using with Elmeasure password.
A er connected the MUT, go to the webpage with AP mode IP (192.168.4.1/index.html).
Click on scan bu on in the webpage, it will show nearby Wi-Fi routers. Select primary and Secondary
SSID in the webpage.
Enter primary SSID with password and secondary SSID with password. Primary connec on can either
be configured to sta c or DHCP IP secondary connec on can be configured only DHCP IP.
If required to assign sta c IP, enter the IP within the router series, enter default gateway, DNS of that
router. Enter the Subnet mask within the router range. Then click on submit.
Once a er all the connec on, open the webpage with assigned IP address by connec ng your device
to the same network.
The system should have web browser. Refer the Wi-Fi user manual for WiFi configura ons like MQTT,
MODBUS TCP/IP, MODBUS RTU etc.
3. CONNECTION / WIRING DIAGRAM
L1 L2 L3 N
IOT10 wiring Connec on
L1
N
L1 L2 L3 N
N
