- Page 1 FusionCharge SmartLogger3000 Quick Guide Issue: 01 Part Number: 31500KCS Date: 2024-11-10 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 • Operators shall understand the composition and working principles of the charging system and be familiar with relevant national or regional standards. Copyright © Huawei Technologies Co., Ltd. 2024. All rights reserved.
- Page 3 Overview (1) LED indicators (RUN, ALM, 4G) (2) SIM card slot (SIM) (3) Mounting ear (4) Guide rail clamp (5) MBUS port (MBUS) (6) GE port (WAN) (7) SFP ports (SFP1, SFP2) (8) 4G antenna port (4G) (9) RST button (RST) (10) USB port (USB) (11) GE port (LAN) (12) DI ports (DI)
-
Page 4: Device Installation
Device Installation Installing the SmartLogger Behind the Main Control Front Door of the Power Unit Electrical Connections • Connect cables in accordance with the installation laws and regulations of the country or region where the project is located. • Before connecting cables to ports, leave enough slack to reduce the tension on the cables and prevent poor cable connections. - Page 5 Connecting the PE Cable To enhance the corrosion resistance of the PE terminal, apply silicone grease or paint on it after connecting the PE cable. Connecting the RS485 Communications Cable • The recommended RS485 communication distance is less than or equal to 1000 m. •...
- Page 6 Connecting the Output Power Cables Busbar of the power unit...
- Page 7 Connecting the Ethernet Cable • The SmartLogger can connect to an Ethernet switch, router, or PC over a WAN port. • The SmartLogger can connect to a SmartModule or PC over a LAN port. • If the delivered Ethernet cable is too short, you are advised to prepare one of Cat 5e or higher specifications and shielded RJ45 connectors.
-
Page 8: Check Before Power-On
Check Before Power-On Criterion The SmartLogger is installed correctly and securely. All cables are connected securely. Routing of power cables and signal cables meets the requirements for routing strong- current and weak-current cables and complies with the cable routing plan. Cables are bound neatly, and cable ties are secured evenly and properly in the same direction. -
Page 9: Powering On The System
Powering On the System 1. Connect to the power supply. Check that the cable between the DC power supply and the SmartLogger is correctly connected. Then, turn on the upstream power switch of the DC power supply. 2. Observe the LED indicators to check the running status of the SmartLogger. Indicator Status Meaning... - Page 10 WebUI Deployment The WebUI screenshots are for reference only. 1. Set the IP address for the PC in the same network segment as the SmartLogger IP address. IP Settings SmartLogger Default Value Example of PC Settings Port IP address 192.168.8.10 192.168.8.11 LAN port Subnet mask...
- Page 11 5. On the Deployment Wizard page, set parameters as prompted. For details, see Help on the page. During parameter settings, click Previous, Next, or Skip as required. 6. After the parameters are configured, click Finish. FAQs The SmartLogger Cannot Find Devices 1.
- Page 12 RST Button Operation Function When WLAN is set to OFF in idle state, hold down the RST button for 1s to 3s to power on the WLAN module. The alarm/maintenance indicator (ALM) Hold down the then blinks green fast for 2 minutes (other indicators are off) and the button for 1s to SmartLogger waits for connecting to the app.
- Page 13 Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China e.huawei.com...
