- Page 1 P Model Moulded Case Circuit Breaker SMART Electronic Trip Unit from 160A up to 630A USER MANUAL Version 1.8.0 1300 NHP NHP nhp.com.au NHP Electrical Engineering Products 0800 NHP NHP nhpnz.co.nz...
-
Page 2: Using This Manual
Appropriate use of NHP / Terasaki products NHP / Terasaki products are intended to be used only for the applications described in the catalogue and technical documentation, which is dedicated to them. If products and components from other manufacturers are used, they must be recommended or approved by NHP or Terasaki. -
Page 3: Summary Of Changes
Summary of Changes This section highlights the details of changes made since the previous issue of this document. The versioning convention used to track changes in this document follows the structure Vx.y.z where: x: Major revision, where extensive changes are made which is generally incompatible with the previous version. Such changes may include new products and/or features, or removal of information which is no longer relevant or applicable to the previous version y: Minor revision, where changes made do not change the overall scope of the previous version, but may include additional information which complements or corrects the previous version, or provides additional clarity on an existing topic. -
Page 4: Table Of Contents
Table of Contents Using this manual Protection Settings Safety Precautions Trip Curve Summary of Changes Long Time Delay Protection (LTD) Table of Contents Equation Introduction Adjusting I (Current) Who Should Use This Manual? Adjusting t (Time Delay) Additional resources Thermal memory / Hot–Cold start mode Terminology and Abbreviations Short Time Delay Protection (STD) Product Information... - Page 5 Table of Contents Alarms Annex A – Dimensions Alarm Types P160 Dimensions Alarm Indication P160 with Rear Connect Priority Level P160 with HB Handle System Alarms P160 with HP Handle PTA (Pre-Trip Alarm) P160 with HS Handle Pre-Trip Alarm Configurable Settings P250 Dimensions Trip Alarms P250 with Rear Connect...
-
Page 6: Introduction
This manual aims to provide users, electricians, panel builders and maintenance personnel, with the technical information required for commissioning and operation of the NHP / Terasaki TemBreak PRO P_SE MCCB. Users of this document must have at minimum a basic understanding of electrical circuit protection topics including (but not limited to):... - Page 7 Information on installing and mounting the HS and HP external mount handles. Instructions TemBreak-PRO-HS-External-Handle-For-P160-P250- P400-P630-User-Manual TemBreak-PRO-HP-External-Handle-Installation-For-P160- P250-User-Manual TemBreak-PRO-HP-External-Handle-Installation-For-P400- P630-User-Manual NHP/Terasaki HB Direct Mount Handle Installation Information on installing and mounting the HB direct mount handles. Instructions TemBreak-PRO-HB-External-Handle-Installation-For-P160- P250-User-Manual TemBreak-PRO-HB-External-Handle-Installation-For-P400- P630-User-Manual NHP/Terasaki Motor Operator MCCB Installation Information on installing, mounting, and wiring to a MCCB motor operator.
-
Page 8: Terminology And Abbreviations
Introduction Terminology and Abbreviations Abbreviation Description Abbreviation Description Maintenance Interface Port: Plug for temporary Auxiliary Communications port: Plug for Smart auxiliary / connection to Trip Unit testing, servicing, and alarm contact block maintenance tools Alarm: An auxiliary contact indicating trip status Neutral ASCII American Standard Code for Information Interchange... -
Page 9: Product Information
Product Information The TemBreak PRO P model SMART Electronic MCCB with Trip Unit type P_SE, in addition to protecting against overloads and short circuits, offers flexibility via provide fully adjustable LSIG (long time, short time, instantaneous, ground fault) protection settings via the embedded OLED display as well as a host of other standard or optional features. -
Page 10: Part Number Break Down
Product Information Part Number Break Down 160 F 2 4 160 BE G a) Model Type d) Pole Pitch Size (mm) Basic applications (160…250 A) Mid to advanced applications (160…630 A) High current, high kA applications e) No. of Poles (160…1600 A) Earth Leakage applications (125…250 A) -
Page 11: Available Mccbs In The Tembreak Pro Range
Product Information Available MCCBs in the TemBreak PRO range: Rating Frame Size Short Circuit Break Capacity 1000 1250 1600 2000 2500 3200 (kA) A160E – TF A160E – FF A250E – TM P400E-TM P630E – TM B160E – FF A160F – TF A250F –... -
Page 12: Label Identification
Product Information Label Identification The label on the MCCB features information to aid in product identification. Description Notes Circuit Break Identifier Identifies the model type, ampere frame, and I rating. Trip Unit type The Trip Unit type is indicated by the colour of the label. White label –... -
Page 13: P160_Se And P250_Se Information
Product Information P160_SE and P250_SE Information Frame / Model Attribute Unit Condition P160F P160N P160H P250F P250N P250H Number of Poles 3, 4 3, 4 3, 4 3, 4 3, 4 3, 4 Nominal current ratings @ 50°C 40 A 40 A 40 A 40 A... -
Page 14: P400_Se Information
Product Information P400_SE Information Frame / Model Attribute Unit Condition P400F P400N P400H P400S Number of Poles 3, 4 3, 4 3, 4 3, 4 Nominal current ratings @ 50°C 250 A 250 A 250 A 250 A Trip Unit ratings 400 A 400 A 400 A... -
Page 15: P630_Se Information
Product Information P630_SE Information Frame / Model Attribute Unit Condition P630F P630N P630H P630S Number of Poles 3, 4 3, 4 3, 4 3, 4 Nominal current ratings @ 50°C 630A 630A 630A 630A Trip Unit ratings Electrical characteristics Rated maximum operational voltage AC 50/60 Hz ─... -
Page 16: Internal Accessories
Internal Accessories Internal accessories include Auxiliary and Alarm contacts, Shunt Trip and Undervoltage Trip (UVT) modules, which may be installed under the front cover of the MCCB in various combinations to provide additional functionality and connection with external control circuits. For information regarding installation of the internal accessories, see Internal Accessory Mounting Locations Auxiliary &... -
Page 17: Smart Auxiliary Ax / Al Status Indicator
Internal Accessories SMART Auxiliary AX / AL Status Indicator The SMART auxiliary is dedicated to TemBreak PRO SMART MCCB range. It allows the SMART Trip Unit to log and count the number of opening / closing cycles, counting the number of electromechanical fault trips and indicate the actual mechanical OPEN CLOSED TRIP status of the breaker’s main contacts. The auxiliary mounts inside the MCCB and is connected to the MCCBs Trip Unit via the “ACP”... -
Page 18: Shunt Trip
Internal Accessories Shunt Trip A shunt (normally de-energized) can be installed to trip the MCCB by applying voltage to the shunt coil. Part Number Rated voltage Connection Type Conductors AC (V) DC (V) Minimum Maximum T2SH00LA10T ─ Cage Clamp T2SH00LA20T 200…240 ─... -
Page 19: Under Voltage Trips
Internal Accessories Under Voltage Trips A UVT (normally energized) can be installed to trip the MCCB removing voltage from the UVT coil. Part Number Rated voltage Compatible MCCB Connection Type Notes Conductors AC (V) DC (V) Minimum Maximum T2UV00LA10NT 100…120 ─... -
Page 20: P_Se Only Mccb Accessories
P_SE Only MCCB Accessories Notice: The following list of accessories are unique to the P_SE model MCCB. For other accessories in the TemBreak PRO series, refer to the TemBreak PRO technical catalogues, respective user manuals, and installation instructions. TemView PRO (TVP) The TemView PRO (TVP) is an optional backlit LED external display which permits reading and writing data of the P_SE MCCB Trip Unit Trip Unit, including protection settings, energy measurements, alarms, and event logs. -
Page 21: Temcom Pro (Tpcm)
P_SE Only MCCB Accessories TemCom PRO (TPCM) The TemCom PRO communications module (TPCM) communicates directly with the TemBreak PRO Smart Energy MCCB Trip Unit via CIP connection cable, enabling the MCCB to operate as a slave device on a Modbus RTU network via RS-485. The TPCM polls the MCCB at regular intervals, making data accessible within Modbus holding registers. -
Page 22: Connection Cables
P_SE Only MCCB Accessories Connection Cables CIP-RJ9 cable The physical connection between the TVP or TPCM and the P_SE MCCB is via the CIP adapter cable, which provides both the proprietary communications link and auxiliary power supply to the Trip Unit. The CIP adapter cable is comprised on one end a CIP connector which plugs into the CIP socket on the MCCB, and the other end either RJ9 plug for connection to the TVP or TPCM. -
Page 23: Plugs & Ports
Plugs & Ports The P_SE circuit breaker is equipped with specific connectors for connecting interfacing devices and accessories. Port Description Used to connect the PTA output contact to send the pre-trip alarm over a local signalling circuit. Located on the outside left-hand side of the MCCB. The OAC port is an output contact used to send the optional alarm over a local signalling circuit. -
Page 24: Installation
Installation Precautions WARNING: To prevent electrical shock and damage to equipment, disconnect and isolate power source upstream of the MCCB before installing or servicing the MCCB including its connected accessories. Notice: To ensure correct performance, and integrity of equipment, the installation instructions and recommendations provided herein shall be respected. -
Page 25: Clearances
Interpole barriers or terminal covers may be used to achieve creepage and clearance requirements. Conductors must not impede the flow of ionised gas and allow it to clear and disperse safety. Interpole barriers are supplied as standard with Terasaki MCCBs for the line side only. 2 barriers with 3P MCCBs and 3 with 4P MCCBs. - Page 26 Installation Insulating Distance When earth metal is installed within proximity of the breakers, the correct insulating distance must be maintained, refer to Minimum Clearance for further details. This distance is necessary to allow the exhausted arc gases to disperse. This could include the mounting plate or side panel within a switchboard. Minimum Clearance Below illustrates the minimum clearance that must be maintained.
-
Page 27: Internal Accessory Mounting Locations
Installation Internal Accessory Mounting Locations P160, P250 and P400/630 frame sizes have different internal mounting locations for auxiliary contacts, alarm contacts, shunts and, UVTs. Left-side and right-side mounting locations are independent and accept unique combinations. For example, shunts and UVTs may only be mounted on the right side, whereas auxiliary and alarm contacts may be mounted on either left or right side. -
Page 28: P250 Internal Accessories Combination
Installation P250 internal accessories combination Legend TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 29: P400/630 Internal Accessories Combination
Installation P400/630 internal accessories combination Legend Notice: Only 2 internal accessories can be mounted on the right-hand side of a P400 and P630 MCCB. Under no circumstances can 3 or more be installed. Examples: 2 AUX 1 Alarm and 1 AUX 1 Shunt and 1 AUX 1 UVT and 1 AUX TemBreak... -
Page 30: Alarm, Shunt & Uvt Installation
Installation Alarm, Shunt & UVT Installation The alarm, shunt and UVT have a trip bar that needs to interact with the MCCBs trip mechanism. As such they must be installed in a specific way. Refer to the supplied Installation Instructions for the respective accessories for further detail. Standard Alarm &... -
Page 31: Shunt & Uvt Installation
Installation Shunt & UVT installation Action Note Switch the Smart MCCB to the Tripped Position. Open the front cover of the MCCB. Locate the shunt or UVT’s trip bar into the MCCB trip mechanism slot. The shunt or UVT will need to be rolled into place, follow the images to the right. -
Page 32: Smart Auxiliary Installation
Installation SMART Auxiliary Installation Notice: Install auxiliary units last, to ensure the other accessories can be installed correctly. The method for installing standard and SMART Auxiliary modules are similar to the Alarm contact modules and clip straight in. Refer to the supplied Installation Instructions for the respective accessories for further detail. -
Page 33: Protection Settings
Protection Settings Trip Curve The TemBreak PRO P_SE electronic Trip Unit protects against overcurrent and short circuit faults for many types of electrical distribution systems. The SE Trip Unit has protective characteristics according to the requirements of the standard AS/NZS IEC 60947.2. Depending on the protection type, adjusting protection parameters can be made using one or combination of the below methods: P_SE Trip Unit rotary switches and embedded display TPCM... -
Page 34: Long Time Delay Protection (Ltd)
Protection Settings Long Time Delay Protection (LTD) The Long Time Delay protection protects against current overloads or surges in power distribution or motor control applications. Long Time Delay protection is an inverse-time protection which includes a thermal image function. Long Time Delay Settings Description Long Time Delay protection threshold (current rating) Long Time Delay (time delay) -
Page 35: Adjusting I R (Current)
Protection Settings Adjusting I (Current) The LTD protection trip range is: 1.05...1.20 x I according to standard AS/NZS IEC 60947.2. As above the trip threshold tolerance I for the long-time delay protection is therefore +5% to +20%. The I trip threshold is firstly set using the I max scale dial on the front of the MCCB, then, if necessary, from the embedded screen display to further adjust in fine increments of 1A. -
Page 36: Adjusting T R (Time Delay)
Protection Settings Adjusting t (Time Delay) The t time delay defines the trip time of the long-time delay protection for a current of 6 x I Adjustments to t parameter can be made using: P_SE Trip Unit embedded display TPCM Adjustment Range (seconds) Default Notice: For the following MCCBs the setting of I... -
Page 37: Thermal Memory / Hot-Cold Start Mode
Protection Settings Thermal memory / Hot–Cold start mode TemBreak PRO electronic Trip Units have a thermal imaging function, which models the active heating and cooling of electrical conductors as current passes through them. The thermal imaging function calculates a thermal value (θ) for the conductors, which trips the MCCB when its thermal threshold (θ trip is reached. -
Page 38: Short Time Delay Protection (Std)
Protection Settings Short Time Delay Protection (STD) The short time delay protection is designed to protect against low level short-circuit conditions. Short Time Delay Protection Settings Description (x I ) / OFF Short Time Delay protection threshold / Disable (ms) Short Time Delay I²t (ON / OFF) Inverse I²t time... -
Page 39: Adjusting I Sd (Current)
Protection Settings Adjusting I (Current) The l trip threshold tolerance for STD protection is ±10%. Depending on the MCCB ampere frame size, adjustments to I parameter can be made using one or a combination of the below methods: P_SE Trip Unit rotary dials and embedded display TPCM P160 and P250 On P160 / P250 ampere frame sizes, there are no I... - Page 40 Protection Settings P400 and P630 Similarly to the LTD parameter settings, on P400 / P630 ampere frame sizes, the I settings are split into maximum and fine adjustment settings. The I threshold is firstly set using the I max adjustment dial on the front of the MCCB, then, if necessary, further adjust in fine increments of 0.5 x I using the embedded screen display or one of the methods below.
-
Page 41: Adjusting T Sd (Time Delay)
Protection Settings Adjusting t (Time Delay) Depending on the MCCB ampere frame size, adjustments to t parameter can be made using one or a combination of the below methods: P_SE Trip Unit embedded display TPCM Time Delay Adjustment Settings (ms) Default 100ms The trip time tolerance for short time delay protection is as follows:... -
Page 42: Default
Protection Settings t function for STD When enabled, the I²t function for STD may be used to improve selectivity with downstream devices by overlaying a supplementary I t = K curve within the STD tripping section, starting from the I threshold setting up to the I threshold setting. - Page 43 Protection Settings The below graphic illustrates the difference between I t enabled and disabled with a I t curve based on I = 630A for reference. Settings Full curve Full curve t ONLY with I t disabled with I t enabled base on I =630A 630A...
- Page 44 Protection Settings The I t curve is based on the setting of I The below time current graph illustrates the effect of the I t curves calculated for different I settings. Settings t ONLY Full curve base on I =630A with I t enabled 630A...
-
Page 45: Thermal Self-Protection
Protection Settings Thermal Self-Protection Thermal Self-Protection Thermal self-protection is enabled automatically where STD is disabled. This is to ensure that the continuation of the LTD curve does not intersect with the Critical Area of the MCCB, which could create overheating stresses in the MCCB and cause irreparable damage and/or undesirable operation or failure of the trip-unit. -
Page 46: Thermal Self-Protection I 2 T Equation
Protection Settings Thermal Self-Protection Thermal Self-Protection I t Equation Thermal Self-Protection I t Equation �� = �� �� Where the k constant is derived from Where I is the maximum setting I can be set to, not adjustable. Refer to Instantaneous Protection (INST) ��... -
Page 47: Instantaneous Protection (Inst)
Protection Settings Instantaneous Protection (INST) Instantaneous protection is designed to protect against high current short circuits. This protection is independent of time and is set as a multiple of the rated current I Instantaneous Protection Settings Description (x I Instantaneous protection threshold Adjusting I (Current) Adjustments to I... -
Page 48: Tolerances
Protection Settings Tolerances Instantaneous protection is provided by the trip unit up to the Ii settings. For current values greater than Ii, protection is instead offered through a Pressure Trip mechanism. The tolerances outlined below pertain to the Trip Unit and are not indicative of the circuit breaker's performance when the Pressure Trip mechanism overrides the Trip Unit's calculations. -
Page 49: Ground/Earth Fault Protection (Gf)
Protection Settings Ground/Earth Fault Protection (GF) Ground Fault protection is protection against high strength insulation / earth faults. Ground fault is available with 3P and 4P P_SE MCCBs as standard. Ground Fault Protection Settings Description (x I Ground fault current trip threshold (ms) Ground fault time delay I²t... -
Page 50: Adjusting T G (Time Delay)
Protection Settings Adjusting t (Time Delay) The trip time tolerance for ground protection is: For t = 50 ms: ±30 ms For t ≥ 100 ms: -20 ms / +50 ms Adjustments to t time delay can be made using one or a combination of the below methods: P_SE Trip Unit embedded display TPCM Time Delay Adjustment Range (ms) - Page 51 Protection Settings GF I t Equation Ground Fault I t Equation �� = �� �� Where the k constant is derived from �� = (1 × �� × �� �� �� The trip time tolerance for ground fault I t protection is the same as the standard tolerance for ground fault protection: For I = ±10%.
-
Page 52: Neutral Protection (Np)
Protection Settings Neutral Protection (NP) Neutral protection is available with 4P P_SE MCCBs as standard. It is particularly useful when the cross-section of the neutral conductor is reduced in relation to the phase conductors. Neutral protection is based off the standard LTD and STD protection parameter of the main phases. The I and I parameters for the Neutral pole are adjusted according to the set Neutral Coefficient percentage. -
Page 53: Zone Selective Interlocking Function (Zsi)
Protection Settings Zone Selective Interlocking Function (ZSI) WARNING: The ZSI function is supplementary to time selectivity (t and t time delay). Under no circumstances shall it be used to replace normal STD and/or GF protection. Zone interlocking is a high-speed signalling method applied between multiple combinations of MCCBs and ACBs to improve the level of protection in a low voltage power distribution system. -
Page 54: Setting The Zsi Function
Protection Settings Zone Selective Interlocking Function (ZSI) Setting the ZSI function The P250SE / P400SE / P630SE MCCB must activate the ZSI protection to acknowledge selectivity per zone and respond according to any signals received on ZSI Changes to the settings of each of the ZSI functions can be made using one or a combination of the below methods: P_SE Trip Unit embedded display TPCM P_SE Trip Unit embedded... -
Page 55: Zsi Example A
Protection Settings Zone Selective Interlocking Function (ZSI) ZSI example A Tier 1 Tier 2 Tier 3 Fault example a): A short circuit or ground fault occurs downstream of MCCB Q3. All upstream MCCBs Q1, Q2 and Q3 detect the fault at the same time. The ZSI signalling cable between the circuit breakers produces a signal from Q3, which informs Q2 that the downstream circuit breaker has detected the fault. -
Page 56: Zone Interlocking With Tempower 2 Acbs
Protection Settings Zone Selective Interlocking Function (ZSI) Zone Interlocking with TemPower 2 ACBs With TemPower 2 ACBs ZSI is available as a custom feature and is designed differently to P_SE ZSI. With these differences it is still possible to zone interlock TemPower 2 with TemBreak PRO P_SE, there are just a few considerations that need to be respected. - Page 57 Protection Settings Zone Selective Interlocking Function (ZSI) Zone Interlocking with TemPower 2 ACBs Wiring Requirements There is no limit to the number of interconnected upstream and downstream circuit breakers using the ZSI signalling interface; however, the reliability of the ZSI signal is dependent on the total impedance of the interconnecting cables. Therefore, the total impedance of the ZSI signalling cables and intermediate wiring and terminations must be considered.
- Page 58 Protection Settings Zone Selective Interlocking Function (ZSI) Zone Interlocking with TemPower 2 ACBs Power Requirements For continuous ZSI operation, 24VDC should be supplied to the P_SE Trip Unit externally. While ZSI signalling can work without external 24VDC supply via the CIP port on P_SE MCCB’s, it relies on the MCCB contacts being closed and conducting sufficient current to provide the minimum requirements for self- power.
-
Page 59: Measurement And Settings
Measurement and Settings Overview of Measurements The P_SE Trip Unit measures and makes visible detailed real-time and historic measurements. Visibility of each measurement type is dependent on the interface used to interrogate the Trip Unit and can be made using one or a combination of the below methods: P_SE Trip Unit embedded display TPCM P_SE Trip Unit... - Page 60 Measurement and Settings P_SE Trip Unit TPCM Measurements Embedded Display Power Designator / Description ✓ ✓ ✓ Active ✓ ✓ ✓ Reactive ✓ ✓ Apparent ─ Max. of each P ✓ ✓ ✓ Max. of each Q Maximum since last reset ✓...
-
Page 61: Accuracy Of Measurements
Measurement and Settings Accuracy of Measurements The measurement accuracies of the P_SE Trip Unit complies with the requirements of standard IEC 61557-12 Edition 1: Class 0.2 for measuring frequency, Class 0.5 for measuring voltages, Class 1 for measuring current, Class 2 for measuring active energy / power. The accuracy of each measurement is defined, in accordance with IEC 61557-12 Ed 1, for a supply within the rated ambient temperature range of the MCCB (-25°C...+70°C). -
Page 62: Real-Time And Min./Max. Measurements
Measurement and Settings Real-Time and Min./Max. Measurements The P_SE Trip Unit records historical maximum and minimum measurement values alongside real-time measurements. Some historical values may be manually reset, include User and Trip Unit timestamps, and/or are unique to MCCB’s with Neutral reference (3Ph+N) or without (3Ph) depending on system topology. - Page 63 Measurement and Settings Measurement Value Designator / Description Minimum Real-time Maximum 3Ph 3Ph+N Power Value Timestamp Value Value Timestamp ✓ ✓ ✓ ✓ ─ ─ ─ ✓ ✓ ✓ ✓ Active power ─ ─ ─ ✓ ✓ ✓ ✓ ─ ─...
-
Page 64: Current And Voltage Imbalances
Measurement and Settings Current and Voltage Imbalances The P_SE Trip Unit calculates in real-time (every second) current and voltage imbalances as expressed as a % in relation to the arithmetic mean (average value) Current imbalance I is expressed as a % in relation to the arithmetic mean RMS current I p Unb ×... -
Page 65: System Phase Sequence
Measurement and Settings System Phase Sequence This parameter is used to configure the sequence of phases for the network supplying the P_SE MCCB. Changes to the system phase sequence setting can be made using one or a combination of the below methods: P_SE Trip Unit embedded display TPCM P_SE Trip Unit embedded display... -
Page 66: Power Related Measurements
Measurement and Settings Power Related Measurements The P_SE Trip Unit calculates the electrical power related parameters in real-time by taking discrete instantaneous measurements of voltage and current at regular sample intervals, with the available data refreshed once every second: Active power (P) Reactive power (Q) Apparent power (S) Power Factor (PF) - Page 67 Measurement and Settings Power flow direction and quadrant The P_SE MCCB power supply can be fed in either forward or reverse direction to allow for varied applications and physical installation requirements. Power measurement values are denoted by positive or negative in accordance with the power sign polarity. To ensure accuracy of measurements and other calculated values (such as energy and quadrant), the P_SE Trip Unit must be configured with the correct power flow direction, which reflects the physical direction of supply.
- Page 68 Measurement and Settings Reactive and apparent power calculation convention Total reactive (Q ) and apparent (S ) power for a 3-phase-3-wire system are calculated in the P_SE Trip Unit using either Arithmetic or Vector convention, which is selectable during configuration. Changes to the reactive and apparent power calculation convention can be made using one or a combination of the below methods: TPCM TVP setting...
-
Page 69: Power Factor (Pf And Cosφ)
Measurement and Settings Power factor (PF and cosφ) The P_SE Trip Unit calculates in real-time (every second) the total three-phase power factor (PF ) from the ratio of total active power (P ) to total apparent power (S ) in both MCCB system topology (3Ph or 3Ph+N). It also calculates the power factors per phase from the ratios of total active power per phase to apparent power per phase in MCCB variants with Neutral reference: where p = phase: 1, 2, 3 In the case of purely sinusoidal current (with no harmonic content), the overall power factor (PF) contains only the power factor of the fundamental... - Page 70 Measurement and Settings Power factor sign convention Power factor values (both PF and cosφ) are represented by the P_SE Trip Unit as having either a positive (+) or negative (-) sign depending on the sign convention setting. The two sign conventions are dependent on either IEC or IEEE standards. Changes to the power factor sign convention can be made using one or a combination of the below methods: TPCM TVP setting...
-
Page 71: Total Harmonic Distortion (Thd)
Measurement and Settings Total Harmonic Distortion (THD) The P_SE Trip Unit calculates the total harmonic distortion levels from the real-time current and voltage measurements (every second). These calculations are performed up to the 31st harmonic. The total harmonic distortion levels may be used to indicate load or power supply quality according to the purity of the current and/or voltage waveform, where low level of wave distortion is ideal. -
Page 72: Demand Values (Averaged Values Over An Interval)
Measurement and Settings Demand Values (averaged values over an interval) The P_SE Trip Unit calculates the averaged current and power values by integration over a specified time interval. These are the Demand values or the averaged values over an interval. Demand values are useful in order to create a load profile for the loads supplied by the P_SE MCCB. Demand values are distinct and not to be confused with other instantaneous average measurements (e.g. -
Page 73: Demand Mode
Measurement and Settings Demand mode There are 3 types of time window intervals which are configurable in the Trip Unit: Fixed window Sliding window Synchronised window (Sync. Bus) Changes to the Demand interval type and time can be made using one or a combination of the below methods: TPCM TVP setting TPCM setting... - Page 74 Measurement and Settings Synchronised window This mode is only compatible with the use of the TPCM, whereby a synchronisation pulse is generated via write Command ID: 132 “Trigger signal of Bus synchronisation Demand mode”. The time interval for the calculation of the demand value is determined by the time between synchronisation pulses. When the first synchronisation pulse is received, the start of the time interval is initialised.
-
Page 75: Energy Measurements
Measurement and Settings Energy Measurements The P_SE Trip Unit provides various energy readings by integrating the instantaneous power over a network period and storing the totalised energy in several counters and incremented once every second. Active and reactive energy counters provide separate and combined values for produced and consumed energy (i.e. energy flowing through the MCCB in either direction). -
Page 76: Alarms
Alarms Alarm Types The P_SE Trip Unit provides alarming for various types of events based on system status and live monitoring of parameters. There are four types of alarms based on functionality and configurability: System alarm: Correspond to predefined events internal to the Trip Unit. Pre-Trip alarm (PTA): Provides a warning about the imminent trip risk due to a current overload. -
Page 77: Priority Level
Alarms Priority Level Each trip and custom alarm is associated with it a priority level, which determines how each alarm is displayed and logged. Notice: Custom alarms are only visible using the TVP or TPCM, however, the P_SE Trip Unit will still monitor and log any prior configured alarms without either TVP or TPCM connected. -
Page 78: System Alarms
Alarms System Alarms System alarms are produced as a result of at least one of the following pre-defined events, which are not user configurable: Internal Trip Unit error Trip Unit temperature alarm Disconnection of neutral Internal Trip Unit error: The P_SE Trip Unit constantly monitors its protection function. In the event of an operating fault concerning the electronics of the Trip Unit, the Internal Trip Unit error alarm is activated and the Trip Unit Status LED flashes orange. -
Page 79: Pta (Pre-Trip Alarm)
Alarms PTA (Pre-Trip Alarm) The Pre-Trip Alarm permits monitoring and early warning of overload conditions prior to an actual LTD trip. The PTA setting is defined by two parameters which define the Pre-trip warning and Pre-trip Alarm zones and thus the behaviour of the PTA contact and status LED: PTA current threshold I : Threshold expressed as a percentage of I and is adjustable from 60…95%... -
Page 80: Pre-Trip Alarm Configurable Settings
Alarms Pre-Trip Alarm Configurable Settings The trip threshold and time delay for the PTA overload pre-alarm can be adjusted. The parameters are defined in relation to the long-time delay l and t parameters. Changes to the PTA I current threshold and t time delay can be made using one or a combination of the below methods: P_SE Trip Unit embedded display TPCM... -
Page 81: Trip Alarms
Alarms Trip Alarms The trip alarms indicate a trip type and provide information about the trip event values. The possible trips alarms are: Trip related to LTD protection Trip related to STD protection Trip related to INST protection Trip related to GF protection Trip related to Trip Unit testing, servicing, and maintenance tools The following information is provided in the case of the message for a trip alarm: Trip cause... -
Page 82: Custom Alarms
Alarms Custom Alarms Custom alarms make it possible to produce alarms based specific events and measurements made by the P_SE Trip Unit. They are only available to be configured and displayed using the TVP and/or TPCM in conjunction with the P_SE MCCB. Up to 12 custom alarms may be individually configured for a single P_SE Trip Unit, with each used to monitor a single event of measurement. -
Page 83: Positive Activation
Alarms Positive activation In the case of a positive activation, the alarm is activated when the monitored value increases towards the pick-up threshold. This occurs when the pick-up threshold is set to a higher value than the drop-out threshold. Symbol Description Pick-up threshold Drop-out threshold... -
Page 84: Equivalent Value Activation
Alarms Equivalent value activation For the equal value activation, the alarm is activated when the value measured is equal to the configured value. The activation threshold is the same as the activation value. Symbol Description Pick-up value Pick-up time delay Drop-out time delay TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual –... -
Page 85: Time Delays
Alarms Time delays Custom alarms are activated once the pick-up threshold has been reached and the configured pick-up time delay has elapsed. Likewise, custom alarms are deactivated after the drop-out threshold is reached and the drop-out time delay has elapsed. Both pick-up and drop-out time delays are independently configurable, from a minimum 1 second to maximum 3000 seconds. -
Page 86: Custom Alarms List
Alarms Custom alarms list Pick-up or Drop-out threshold value Pick-up or Drop-out time delay value Name 3Ph+N Unit Min. value Max. value Unit Min. value Max. value ✓ ✓ No assignment ─ ─ ─ ─ ─ ─ ─ ─ ✓ ✓... - Page 87 Alarms Pick-up or Drop-out threshold value Pick-up or Drop-out time delay value Name 3Ph+N Unit Min. value Max. value Unit Min. value Max. value ✓ Over Direct Active power [P 1000 3000 ─ ✓ Over Direct Active power [P 1000 3000 ─...
- Page 88 Alarms Pick-up or Drop-out threshold value Pick-up or Drop-out time delay value Name 3Ph+N Unit Min. value Max. value Unit Min. value Max. value ✓ ✓ Over THD Current [THDI ─ 0.1% 1000% 3000 ✓ ✓ Over THD Current [THDI ─...
-
Page 89: Oac (Optional Alarm Contact)
Alarms OAC (Optional Alarm Contact) The OAC is an optional alarm which can be assigned with one of several types of alarms. When the assigned alarm is activated, the alarm will display on the P_SE embedded display. The OAC also has a physical contact which closes with the activation of the OAC alarm. Refer to the Optional Alarms List the list of available OAC alarm assignments. -
Page 90: Date & Time
Date & Time There are two types of Date & Time accessible from the Trip Unit of the MCCB and which are used as timestamp of trips, alarms, and events, and which are affected by the presence of supply or control power to the Trip Unit. Trip Unit Time: Non-resettable time which is the absolute operating time of the Trip Unit seconds. -
Page 91: History
History The P_SE Trip Unit has an internal memory to enable the following logs to be stored: Trip alarm log (up to 10 most recent events) Custom alarm log (up to 40 most recent events) Log of changes to the protection settings (up to 5 most recent events per protection parameter) These logs are updated internal to the Trip Unit after each event. -
Page 92: Protection Setting Changes Log
History Protection Setting Changes Log Changes to the protection settings are logged for the 5 most recent changes for each setting type are accessible using one or a combination of the below methods: TPCM Each protection setting changes log is stored with the following information with respect to the protection setting type: Previous setting type Timestamp of change Notes... -
Page 93: Write Protection
Write Protection WARNING: Changes and adjustments to protection settings and levels (either local or remotely) should only be performed by qualified personnel. Failure to comply may result in malfunction or damage of protective equipment, serious injury or death. Modifications made remotely over communications to the MCCB configuration settings may be dangerous for personnel near the circuit breaker or may cause damage to the equipment if the protection parameters are modified. -
Page 94: Password Management
Write Protection Password Management Changes to certain configuration settings are protected by varying security access levels. A password corresponding to the required security level must be used when writing data to the TPCM. Refer to the TemCom PRO User Manual for more information on remote writing and reading of data over Modbus communications. Security access levels and their default passwords are as follows: Security Access Level Classification... -
Page 95: Trip Unit Power Supply
Trip Unit Power Supply The P_SE Trip Unit requires auxiliary power supply to operate and provide measurement, alarm, and configured protection functions. Auxiliary power to the Trip Unit is self-powered whilst sufficient current is flowing through the MCCB, but can also be supplied via external 24V dc power supply for uninterrupted functionality. -
Page 96: External 24V Dc Supply Instructions - Cip Adapter Cable
Trip Unit Power Supply External 24V dc supply instructions – CIP adapter cable Below are the steps for direct connection of power supply to the Trip Unit with via CIP adapter cable: TPPHQTT140H (P160 / P250), or TPPHQTT160H (P400 / P630). WARNING: Local wiring rules shall be respected (e.g. - Page 97 Trip Unit Power Supply Action Note / Illustration Insert the CIP connector for the CIP adapter in one of the connectors marked CIP inside the circuit breaker on the left-hand side. Route the cable for the CIP adapter along the left-hand side cable channel of the circuit breaker provided for this purpose.
-
Page 98: Navigation
Navigation P_SE Trip Unit Overview P160 / P250 Operation key MIP Port SMART Trip Unit Joystick Embedded Display P400 / P630 Coarse Setting Dial Coarse Setting Dial LED Indication Unlock Button TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 99: Principles Of Navigation
Navigation Principles of Navigation The menu navigation and selection is performed using the joystick on the left side Trip Unit display. Button Action Description Navigation between main menus: Navigation within a submenu Selection / Entering / validation of a setting, by pressing the joystick Locking / Release Button By default, changing P_SE Trip Unit protection settings are protected via a locking function. -
Page 100: Navigation Menus
Navigation Navigation Menus The embedded display provides access to P_SE Trip Unit settings and measurement viewing and status via 4 main menus: Protection Measurement Configuration Information Protection Setting Menu The protection menu consists of sub-menus to view and edit each Trip Unit protection setting. Refer to the Protection Settings section for more details on each of the available protection setting parameters and their adjustments via the P_SE... -
Page 101: Measurement Menu
Navigation Measurement Menu The measurement menu is where you can view measurements and set favourites for screen saver. Refer to the Measurements and Settings section for more details on the measurements available on the P_SE Embedded display Pressing the joystick down on the Measurements menu allows scrolling through and viewing of the following parameters and options. Measurement Designator / Description Notes... -
Page 102: Setup Menu
Navigation Setup Menu The Setup menu consists of sub-menus to view and change Trip Unit embedded display settings for: Date & Time Display Orientation and Brightness Standby mode. Reset the maximum measurement values. Return to factory settings. Permission to remotely write data Pressing the joystick down on the Setup menu allows scrolling through and viewing of the following parameters and options Parameter Symbol... -
Page 103: Information Menu
Navigation Information Menu Pressing the joystick down on the Information menu allows scrolling through and viewing of the following parameters and options: Parameter Symbol Description Trip History Information on the last trip cause – Refer to Last Trip section for more information Number of operating cycles opening / closing Number of electromechanical fault trips Notice: AX and AL cycle counters are only available when the SMART Auxiliary accessory is installed in the... -
Page 104: Sleep / Standby
Navigation Sleep / Standby After 30 seconds of inactivity (no movement of the joystick), the embedded display will enter Standby mode, whereby it will automatically scroll through a loop of favourited measurements every 3 seconds. Refer Setting Favourites section for information on how to set favourite measurements to be displayed in Standby mode. If Sleep mode is activated from the information menu, the display switches off after 5 minutes of inactivity. -
Page 105: Commissioning
Commissioning Starting the P_SE MCCB for the First Time WARNING: Before applying power to the MCCB for the first time, an initial inspection must be performed. At first start-up, before being able to access the various menus, the embedded display will prompt the user to set the orientation, brightness and Standby mode. -
Page 106: Ltd Protection Adjustments (I R , T R )
Commissioning LTD Protection Adjustments (I WARNING: Risk of nuisance tripping. Only qualified personnel are to set the protection levels. Failure to respect these instructions may cause death, serious injuries or equipment damage. After having set the display, the I max setpoint and I current should be set as follows: Action Note / Illustration... - Page 107 Commissioning Action Note / Illustration At this stage it is possible to modify the other protection settings. To do this, it is important to remain in Unlocked mode, unsure only press the left arrow once. Pressing more than once will lock the display, the display Note: would need to be unlocked to proceed.
-
Page 108: Navigation And Settings After The First Setup
Commissioning Navigation and Settings After the First Setup After setting the max I setpoint (I dial), it is necessary to: Set the other protection parameters for the circuit breaker Set the Trip Unit clock Below uses I as an example for setting all other protection settings. Refer to Protection Settings section for more information in additional settings. - Page 109 Commissioning Action Note / Illustration Move the navigation joystick upwards or downwards to select the desired value or method. Press the centre of the joystick to confirm the new setting At this stage it is possible to modify other settings of the current menu.
-
Page 110: Accessing Measurements
Commissioning Accessing Measurements Refer to the Measurements and Settings section for more details on the measurements available on the P_SE Embedded display Action Note / Illustration Move the joystick to the right to select the Measurements menu. Then press the joystick to access the Measurements menu. Move the navigation joystick downwards or upwards to view the available measurements. -
Page 111: Setting Favourites
Commissioning Setting Favourites Default Display Favourites are deactivated by default. To manage favourites, proceed as follows: Action Note / Illustration Move the joystick to the right to select the Measurements menu. Then press the joystick to access the Measurements menu. Move the navigation joystick downwards to select the view to be set as the favourite. -
Page 112: Accessing Setup Settings
Commissioning Accessing Setup Settings Default Display Favourites are deactivated by default. To manage favourites, proceed as follows: Action Note / Illustration Move the joystick to the right to select the Setup menu. Then press the joystick in to access the Setup menu. Move the navigation joystick upwards or downwards to view the available settings. - Page 113 Commissioning Settings Icon Available Settings Default Unlock Required Time Hours / Minutes AM / PM Day / Month / Year Date Values D / M / Y Year / Month / Day Display Orientation ← / ↑ / → / ↓ ↑...
-
Page 114: Troubleshooting
Troubleshooting Troubleshooting In the event of a problem when using the TemBreak PRO system, this section provides advice on how to resolve issues. Problem description Possible cause Remedial advice Ready LED OFF Insufficient or no power to the Trip Verify power supply requirements. Refer to Trip Unit Power Supply section. - Page 115 Problem description Possible cause Remedial advice Trip Unit over temperature alarm Excessive ambient temperature. Verify ambient temperature surrounding the MCCB do not exceed the maximum rated (Internal Trip Unit temperature > ambient temperature range (-25°C...+70°C) 105°C) Loose terminal screw or conductor Verify and correct any loose connections to load and line terminals.
-
Page 116: Annex A - Dimensions
Annex A – Dimensions P160 Dimensions TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 117: P160 With Rear Connect
P160 with Rear Connect TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 118: P160 With Hb Handle
Annex A – Dimensions P160 with HB Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 119: P160 With Hp Handle
Annex A – Dimensions P160 with HP Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 120: P160 With Hs Handle
Annex A – Dimensions P160 with HS Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 121: P250 Dimensions
Annex A – Dimensions P250 Dimensions TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 122: P250 With Rear Connect
Annex A – Dimensions P250 with Rear Connect TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 123: P250 With Hb Handle
Annex A – Dimensions P250 with HB Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 124: P250 With Hp Handle
Annex A – Dimensions P250 with HP Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 125: P250 With Hs Handle
Annex A – Dimensions P250 with HS Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 126: P400 Dimensions
Annex A – Dimensions P400 Dimensions TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 127: P400 With Rear Connect
Annex A – Dimensions P400 with Rear Connect TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 128: P630 Dimensions
Annex A – Dimensions P630 Dimensions TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 129: P630 With Rear Connect
Annex A – Dimensions P630 With Rear Connect TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 130: P400 / P630 With Hb Handle
Annex A – Dimensions P400 / P630 with HB Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 131: P400 / P630 With Hp Handle
Annex A – Dimensions P400 / P630 with HP Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 132: P400 / P630 With Hs Handle
Annex A – Dimensions P400 / P630 with HS Handle TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 133: Annex B - Trip Curves
Annex B – Trip Curves Notice: The below trip curve is representative only. The P_SE Trip Unit features fully configurable protection settings with fine adjustment to pick-up current and time delay for the various respective trip curves, which can change depending on the application. To aide in selectivity studies, a trip curve based on the actual settings used can be generated using the software package TemCurve. -
Page 134: Annex C - I 2 T Let-Through Curves
Annex C – I t Let-Through Curves P160_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 135: P250_Se
Annex C – I t Let-Through Curves P250_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 136: P400_Se
Annex C – I t Let-Through Curves P400_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 137: P630_Se
Annex C – I t Let-Through Curves P630_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 138: Annex D - Peak Let Through Curves
Annex D – Peak Let Through Curves P160_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 139: P250_Se
Annex D – Peak Let Through Curves P250_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 140: P400_Se
Annex D – Peak Let Through Curves P400_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 141: P630_Se
Annex D – Peak Let Through Curves P630_SE TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 142: Annex E - Watts Loss
Annex E – Watts Loss Impedance Watts Loss Rating Impedance per pole Watts Loss per pole Pole Watts Loss per product Frame In (A) (mΩ) Based from Impedance (W) numbers Based from Impedance (W) 0.35 P160_SE 0.35 3/4P 10.5 0.35 0.24 0.24 P250_SE... -
Page 143: Annex F - Rated Temperature Tables
Annex F – Rated Temperature Tables Maximum setting of the Ir at the nominated current at the specified ambient. Values in bold are the maximum value for I , different combinations of I and I can be set if the combined settings are not greater than the I value advised. -
Page 144: Annex G - Wiring Diagrams & Terminal Designations
Annex G – Wiring Diagrams & Terminal Designations Internal Accessories Accessory Terminal Designations Notes MCCB Status “Closed” MCCB Status “Open” MCCB Status “TRIP” Auxiliary 11/AXc-14/AXa “Closed” 11/AXc-14/AXa “Open” 11/AXc-14/AXa “Open” 11/AXc-12/AXb “Open” 11/AXc-12/AXb “Closed” 11/AXc-12/AXb “Closed” MCCB Status “Closed” MCCB Status “Open” MCCB Status “TRIP”... -
Page 145: Zsi Wiring
Annex G – Wiring Diagrams & Terminal Designations ZSI Wiring ACBs Upstream TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... -
Page 146: Mccbs Upstream
Annex G – Wiring Diagrams & Terminal Designations ZSI Wiring MCCBs Upstream TemBreak P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual – V1.8.0... - Page 147 P-Model-MCCB-Smart-Electronic-160A-to-630A-User-Manual Version 1.8.0 Published 21st January 2025 1300 NHP NHP nhp.com.au NHP Electrical Engineering Products 0800 NHP NHP nhpnz.co.nz...
Need help?
Do you have a question about the NHP TemBreakPRO P Series and is the answer not in the manual?
Questions and answers
