Installing On The Wall; Installing The Wall Mount Plate - LG 24HR513C-B.AEU Owner's Manual

Installing on the Wall

This monitor meets the specifications for the wall mount plate or other compatible devices.
Install the monitor at least 100 mm away from the wall on each side of the monitor to ensure sufficient
ventilation. Detailed installation instructions can be obtained from your local dealer. Please refer to the manual
to install and set up a tilting wall mounting bracket.
: 100 mm

Installing the Wall Mount Plate

This monitor meets the specifications for the wall mount plate or other compatible devices.
To install the monitor to a wall, attach a wall mount plate (optional) to the back of the monitor.
Make sure that the wall mount plate (optional) is securely fixed to the monitor and to the wall.
Wall Mount (mm)
Standard screw
Required screws
Wall Mount Plate (Optional)
100 x 100
M4 x L10
4
LSW149
21
