Summary of Contents for GATEXPERT PK600GL
- Page 1 Roller Wheel Swing Gate Opener User Manual PK600GL Website: www.gatexpert.com E-mail: sales@gatexpert.com 20241123...
-
Page 2: Warranty
All personal information you provided will be only used for warranty service and kept strictly confidential. Refer to this list when contacting GATEXPERT for technical service or assistance with your automatic gate opener. Order Number Product Model... -
Page 3: Table Of Contents
Instructions for PK600GL CONTENTS Safety Instruction..........................1 Packing List............................2 Technical Parameters........................3 Installation ............................4 Before You Start..........................4 Installation Diagram.......................4 Cable .............................5 Dimension of Gate Opener ....................5 Tools Needed for Standard Installation...................6 Cable List............................6 Installation Steps..........................7 Standard Wiring Diagram......................7 Checking Before Start........................7 Installation of Control Box......................8 Installation of Gate Opener......................9... -
Page 4: Safety Instruction
Instructions for PK600GL Dear Users, Thank you for choosing this product. Please read the manual carefully before assembling and using it. If you send this product to a third party, please include the manual. 1. Safety Instruction Read the Manual: Please read this manual carefully before installation, as it contains important ... -
Page 5: Parts List
Instructions for PK600GL 2. Parts List Parts List (standard configuration) Picture Name Quantity Gate Opener Control Box Remote Control Manual release key Iron blocker L Iron blocker R Expansion Bolt Ф8x12mm Corrugated Pipe Ф16x500mm Rubber Case Ф18mm... -
Page 6: Technical Specifications
Instructions for PK600GL 3.Technical Specifications Model PK600GL Power Supply 220V/50Hz; 110V/60Hz Motor Power 40W×2 Gate Moving Speed 15S/90° Max.single-leaf weight 600kg Max.single-leaf length Remote control distance ≥30m Remote control mode Single/Four button mode Working noise ≤58dB Duty cycle S2 30Min... -
Page 7: Installation
Control Box Cable (RVV) Figure 1 PK600GL Roller Wheel Swing Gate Automation Kit is suitable for powering the opening and closing motion of swing gates up to 600kg in weight, up to a length of 4m. Ensure that the swing gate is correctly installed and can be moved smoothly by hand before ... -
Page 8: Dimension Of Gate Opener
Instructions for PK600GL 4.1.2 Dimension of Gate Opener Figure 2 5.Tools Needed for Standard Installation Electric Drill Hatching Pen Pliers Puncher Pin Wrench Allen Wrench Phillips Screwdriver Hammer... -
Page 9: Cable List
Instructions for PK600GL Clamp Adjustable Wrench Slotted Tape Screwdriver Note: the cables must be suitable for outdoor use. 6.Cable List Cable Application Cable Material Max. Length 3×2.5mm² (＞30m) Cable of 220V control box’s power supply Unlimited 3×1.5mm² (<30m) Cable of gate opener’s power supply 2×1.5mm²... -
Page 10: Installation Steps
Instructions for PK600GL 7.Installation Steps 7.1 Standard Wiring Diagram Figure 3 Gate Cable with a sectional area no less than 1mm² Control Box connects with 220V power supply PVC pipe to protect wires 220Vpower supply Motor 1 Motor 2 Note Use pipes with good strength and toughness to lay power cable. -
Page 11: Installation Of Control Box
Instructions for PK600GL and ground ≥25mm (at the position of closed gate). The lower area of ground and other ground needs to be gradient. ① Gate ② Iron blocker ③ ≥25mm When h≤90mm, the gate opener can be operated properly. -
Page 12: Installation Of Gate Opener
Instructions for PK600GL The position and the height of control box need to be appropriated. It should be open environment, keep out of rain and sun or reach of children. Figure 5 7.4 Installation of Gate Opener The position of gate opener: choose the best installation position during the opening and closing of two gates. -
Page 13: Installation Of Mounting Plate
Instructions for PK600GL 7.5 Installation of Mounting Plate The Height of Mounting Plate of Gate Openers Method 1: move the gate to the lowest point of travel range, then place the gate opener vertically against the inner side of the gate. Use a measuring tape to draw a line from the lowest point of ground up to 140 mm, fix the mounting plate. -
Page 14: Installation Of Closing Limit Switch (Iron Blocker)
Instructions for PK600GL Manually Electronically open close Figure 8 Manually Open -- insert manual release key to the lock, counter-clockwise rotate 2-3 rounds until the gear fully released to manual mode. Manually Close -- under manual mode, move the gate to 40mm in front of the iron blocker, then use manual release key, clockwise rotate 2-3 rounds until gear get fully lock again, then move the gate to fully closed position to make hatch hock lock iron blocker to manually close the gate. - Page 15 Instructions for PK600GL Iron blocker L Iron blocker R Figure 9 Note When one of the gates closes first and it has gate edge strip, it should be installed the iron blocker of the gate with edge strip first, then install the iron blocker of the gate without edge strip.
-
Page 16: Installation Of Opening Limit Switch (Iron Blocker)
Instructions for PK600GL 7.9 Installation of Opening Limit Switch (Iron blocker) Gate opens inwards Gate opens outwards Figure 10 Use manual release key to switch gate opener to manual mode, move the gate to fully opening or determined position, then move the gate back for 20mm. Align the iron blocker with latch hock, draw a line to mark it, then close the gates. -
Page 17: Operation And Debugging
Instructions for PK600GL 7.10 Operation and Debugging Before operation, please check the wiring connecting and power supply. Move the gate to the middle of travel, close the clutch of gate openers (electronic mode), plug in power supply, the gate openers operate normally. -
Page 18: Wiring And Debugging
Instructions for PK600GL 8. Wiring and Debugging 8.1 Wiring Instruction Figure 11... -
Page 19: Control Board Drawing And Instruction
Instructions for PK600GL 8.2 Control Board Drawing and Instruction Figure 12 Terminal Description 1. AC24VIN 24VAC Power Supply Input 2. +SOLAR- Solar Power Input 3. +BATT- 24V Battery Input 4. FORCE Obstacle Sensitivity 5. SLOW DOWN Slow Stop Distance 6. SPEED Gate Moving Speed 7. -
Page 20: Photo Sensor Wiring Instruction
Instructions for PK600GL Photo Sensor Wiring Instruction Figure 13 WIFI Module Wiring Instruction Figure 14... -
Page 21: Enable And Disable Buzzer
Instructions for PK600GL Enable and Disable Buzzer Jumper to ON: Enable the buzzer Jumper to OFF: Disable the buzzer Zoom in the buzzer jumper Figure 15 Battery Charging Function Insert the jumper to enable battery charging function Remove the jumper to disable battery charging function... -
Page 22: Travel Setting (Very Important)
Instructions for PK600GL no input under opening state under closing state manual mode travel setting 8.4 Travel Setting (VERY IMPORTANT) During the initial installation of gate openers, it is necessary to set the travel limits for both the open and closed positions. -
Page 23: Learning Remote Control
Instructions for PK600GL Gate Moving Speed Trimmer To adjust the gate moving speed: turn clockwise to increase speed and counterclockwise to reduce speed. This setting affects the opening and closing travel time. Complete this adjustment before performing the travel setting. -
Page 24: Control Board Settings
Instructions for PK600GL 8.7 Control Board Settings 8.7.1 Base Menu Press the "PROG" to enter the base menu. The Digital screen will display “NE”, select other functions within this menu by “+” and “-” buttons. Press "SET" to confirm or to enter a sub-menu. - Page 25 Instructions for PK600GL consumption Low consumption mode OFF mode 8.7.2 Base Menu Instruction Option Menu Default Press "PROG" to Press “+” (up) or “-” (down) to select; /Attention enter the base menu Press “SET” to confirm Standard mode; OSC/PED/STP represents...
-
Page 26: Advanced Menu
Instructions for PK600GL Dual Gate/Single mode. Gate Mode Single gate mode. The gate opening time interval is 0-10 3 seconds. Gate Opening Time seconds (default is 3 seconds). If the interval is less Interval than 2 seconds, the electric lock cannot be used. - Page 27 Instructions for PK600GL Force of obstacle sensitivity in fast speed Force of obstacle sensitivity in slow speed Electric lock unlocked duration Time of motor continuously running after travel Photo sensor normally ON Photo sensor Photo sensor normally OFF Electric lock normally ON...
- Page 28 Instructions for PK600GL Default setting cancellation Factory default setting Factory default setting 8.7.4 Advanced Menu Instruction Menu Option Long press "PROG" 2 Default/Attention Press “+” (up) or “－” (down) to select; seconds to enter into Press “SET” to confirm. base menu.
- Page 29 Instructions for PK600GL Electric lock normally ON. (Default) Electric lock Electric Lock normally ON. Electric lock normally OFF. Reverse push lock mode OFF Reverse push lock mode ON Reverse push (When the electric lock is activated, the gate Reverse Push Lock...
-
Page 30: Others
Instructions for PK600GL 9. Others 9.1 Maintenance Monthly inspect the gate to ensure it is operating normally. For safety purposes, it is recommended that each gate be equipped with an infrared sensor, which should also be inspected regularly. Before installation and operation of the gate opener, please read all instructions carefully. -
Page 31: Troubleshooting
Instructions for PK600GL 9.3 Troubleshooting Problems Possible Reasons Solutions 1. Power is off. 1. Turn on the power switch. The gate cannot open or 2. Fuse is burned. 2. Check the fuse and replace it if close normally, and the 3.
