- Page 1 Installation manual Spiritello single group espresso machine (Original instructions) Revision date: … Document ID: Sup-Sllo-Eng Date of issue: November 22, 2024...
-
Page 2: Table Of Contents
Connect to drain/waste (when appropriate) ..................11 Connect electric mains ........................12 First use ..............................13 Fill ..............................13 Heat up .............................. 14 Adjust mix-water temperature......................15 Hand over machine ..........................16 Maintenance ............................17 Contact information ..........................17 Spiritello Installation manual page 1... -
Page 3: Introduction
GENERAL INTRODUCTION This document is the installation manual for the Spiritello espresso machine (in this document referred to as ‘espresso machine’). This document informs the user about the safe and correct installation of the espresso machine. This document is intended for the installer of the espresso machine. - Page 4 5 °C (41 °F). If the espresso machine and/or the pump are exposed to freezing conditions, ask a qualified technician to start the appliance. • Use, cleaning, and maintenance of the espresso machine shall never be done by children without supervision. Spiritello Installation manual page 3...
-
Page 5: Parts Identification
Parts identification Figure 1. Showing the main operational parts of the Spiritello. 1. Group lever 11. Display 2. Steam wand 12. Hot water button (mix-water) 3. Steam valve 13. Encoder knob 4. Brew pressure gauge 14. Heat switches steam and coffee 5. -
Page 6: Installation Summary
14. Write machine number, installation date and other specifics in Service record. When installed by third party: transfer machine to owner/user 15. Explain main features to new user(s) and manager. 16. Show User manual (on website). Spiritello Installation manual page 5... -
Page 7: Water Requirements
2. 2P-E: split Phase + Earth (2 lives and Earth, no neutral). Note that the 2P-E configuration does NOT make use of the neutral wire of the electric mains. The tension between the phase and neutral (P-N-E power) or the tension between the two phases (2P-E Spiritello Installation manual page 6... - Page 8 The electric power should match with the set-up of the machine ordered. Mismatching electric power connections may lead to costly repairs. Note! National rules/regulations may apply when the appliance is connected to the electric mains. Spiritello Installation manual page 7...
-
Page 9: Connect
Connect Tank or mains? Factory setting of the machine will be that water is taken from the internal water tank. When you want to connect the machine to water mains, you must change a physical and software setting at the machine, see section “connect to water mains”... -
Page 10: Connect To Water Mains (When Appropriate)
Figure 5. Ø=8mm push-in water mains connection at the back right of the machine and reinforced hose with push-in adapter. After turning the machine ON you must check (in SETTINGS – MACHINE) if the machine is set to function with water-mains. Spiritello Installation manual page 9... - Page 11 CONNECT Go to settings Go to Machine Go to Water Feed Change to Mains Note! National rules/regulations may apply when the appliance is connected to the water mains. Spiritello Installation manual page 10...
-
Page 12: Connect To Drain/Waste (When Appropriate)
The drain runs off best when the end of the hose is above water-level in the water lock. machine machine machine waste waste waste Figure 7. The drain hoses should not slope up (left) or make a sharp bend (centre) and end above water level in the waste. Spiritello Installation manual page 11... -
Page 13: Connect Electric Mains
Protective Earth (PE) Phase (P) = Live Neutral (N) • Re-establish electric power in the fuse box. Figure 8. Left: 230Vac 16A, type F Shuko plug on mains cable, right: mains cable with stripped leads and ferrules. Spiritello Installation manual page 12... -
Page 14: First Use
First use Fill 1. (Verify that both HEAT switches are in the OFF position: toggle-levers pointing down.) 2. With the water-mains open or water tank filled with fresh water and electric mains connected, turn the main switch ON (left hand side switch, toggle-lever up). The display will show a start-up screen with software-version information and then change to a screen with warning that the (steam-) boiler is empty (see fig. -
Page 15: Heat Up
10. Check the machine for leaks. 11. Fill out he machine number and installation date on a service record (see Figure 10) and keep this with the machine. fig. G fig. H fig. J Spiritello Installation manual page 14... -
Page 16: Adjust Mix-Water Temperature
Figure 9. Adjusting mix-water temperature. Right photo (taken from side with panel removed) shows the adjusting screw on the fill/mix-block that can be accessed without removing the side panel. Spiritello Installation manual page 15... -
Page 17: Hand Over Machine
Hand over machine Figure 10. Print service record and fill out installation data. Keep this with the machine. Print the service record pages from the User manual (see Figure 10). For distributors: Explain the new owner/user the most important functions of the machine. This should at least include: 1. -
Page 18: Maintenance
When seeking contact with the e-mail address above, please forward the model and serial number of the machine in question. Contact information Kees van der Westen Espressonistic Works B.V. Van Elderenlaan 6 5581WJ WAALRE The Netherlands Telephone +31 40 2223433 Email support@keesvanderwesten.com...
