Installation manual Spirit
Document ID: Sup-Rim-Eng
Date of issue: October 22, 2014
Revision date: May 31, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the spirit and is the answer not in the manual?

Questions and answers

Summary of Contents for Kees van der Westen spirit

  • Page 1 Installation manual Spirit Document ID: Sup-Rim-Eng Date of issue: October 22, 2014 Revision date: May 31, 2016...
  • Page 2: Table Of Contents

    First use ..............................25 Heating up ............................25 Set hot water dosage ........................25 Adjust coffee system pump pressure ....................26 Set hot water temperature ......................... 27 More information on our website ....................... 29 Contact information ..........................29 Spirit installation manual page 1...
  • Page 3: Installation Quickstart

    Spirit T-fitting Install water treatment system (not in shipment) and connect water treatment system to both pumps. (Lay-out is different for machine with individual pumps per group.) outlet inlet adjust pump pressure Spirit installation manual page 2...
  • Page 4: Connect Water Disposal

    C = centre coffee boiler (Triplette only) R= right coffee boiler S = steam boiler coffee boilers steam boiler Connect high pressure hoses of both pump outlets to Spirit. 2. Connect water disposal discharge pipe machine waste on drip tray Attach both drain hoses to Spirit.
  • Page 5: Make Sure That Machine Is Switched "Off

    Connect coffee pump cable(s) to coffee pump(s) and steam boiler pump cable to steam boiler pump. Double check that steam boiler cable and steam boiler hose are connected to the same pump, idem for coffee system. Spirit installation manual page 4...
  • Page 6: Fire Up And Adjust

    If the information in this section is not sufficient, we refer to the “installation manual” which you can find in a following section of this manual (page 14 onwards), or contact your local installation technician. Spirit installation manual page 5...
  • Page 7: Welcome

    Welcome Parts identification Figure 1. Showing main operational parts of the Spirit Duette Bastone version. The Spirit Triplette is wider since it has three groups but its functions are identical to the Duette. On the Touchpad version, the group brewing lever units are replaced with touchpads (see Figure 3).
  • Page 8: Note On This Manual

    WELCOME Note on this manual Work on the Spirit manual started in March 2012 and is a continuing process. Photographs in the manual are taken in the shop from (pre-production) machines being built at the time. For that reason, body panels and/or parts from the machines on display may be missing and parts in the machine you bought may not look identical to the parts shown in the manual.
  • Page 9: Prior To Installation

    You may want to have the water, drain and power fed through one or more openings in the countertop (see Figure 4: Footprints of the Duette and Triplette). As the Spirit has full free space underneath, the opening(s) in the countertop can be positioned anywhere. For a visually pleasing result we...
  • Page 10 INSTALLATION hoses cables hoses cables Figure 4. Footprints of Spirit Duette (top) and Triplette (bottom). Measurements in millimetres. Black circle……………………… Machine foot (diameter = 50 mm) White rectangles………………... Suggested locations for openings behind front feet to feed connections through the countertop...
  • Page 11 INSTALLATION Figure 5. Measurements of Spirit Duette. Note that the rubber feet are not present, these are 20 mm high and have a diameter of 50 mm. Spirit installation manual page 10...
  • Page 12 INSTALLATION Figure 6. Measurements of Spirit Triplette. Note that the rubber feet are not present, these are 20 mm high and have a diameter of 50 mm. Spirit installation manual page 11...
  • Page 13: Upon Arrival

    2 discharge hoses, inner diameter 15 mm (5/8”) with stainless steel hose clamps  Filter holders with filter baskets: Duette 2x; Triplette 3x  Stainless steel “Kees van der Westen” tamper; compliant with VST specifications  Blind filter: Duette 2x, Triplette 3x ...
  • Page 14 Figure 7b (right). Location of water supply connections between left legs of machine; C=coffee system, S=steam boiler. Machines with individual pumps per group have 3 (Duette) or 4 (Triplette) water connections marked L, C (Triplette only), R and S: left boiler, centre boiler, right boiler and steam resp. Spirit installation manual page 13...
  • Page 15: Installation

    Installation Precaution Installation of and maintenance on the Spirit should only be undertaken by a qualified technician. Parts of the machine can reach a temperature of close to 130 °C (266 °F). The steam/hot water boiler contains water and pressurised steam at 125 °C and 1.35 Bar overpressure (257 °F and 20 PSI), temperature and pressure in the coffee boiler system may reach up to 96 °C and 12 Bar overpressure...
  • Page 16: Connect Water Supply

    1. Use a 20 mm spanner to attach the elbow end of the two long high pressure hoses to the water supply of the steam boiler (rear fitting) and coffee water system (front fitting) on the Spirit respectively (3/8 connections; see Figure 7b). There is no need for any type of gasket. The rounded end of the hose fits snugly onto the fitting, providing a leak free connection when turned tightly.
  • Page 17 Figure 9. Water treatment system on right is connected to the pumps on left. Flow is shown by the short arrows. Water supply tap is right of figure, Spirit will be to left of figure. The water treatment system and the rightmost hose are not included in your shipment.
  • Page 18 0.5m hose 1.5m hose Figure 10. Lay-out of hoses, fittings and pumps for the standard Spirit (one pump for steam/hot water system, one pump for the coffee-system) and for Spirits with an individual pump for each group. Spirit installation manual...
  • Page 19: Connect Water Discharge

    4. If necessary, cut the discharge hoses to desired length. discharge pipe machine waste on drip tray Figure 11. Spirit seen from bottom front without hoses attached to the machine-waste and drain pipe on the drip dray. Spirit installation manual page 18...
  • Page 20: Connect Electrics

    Connect electrics Single- versus three-phase machines The Spirit is designed to operate on 220-240VAC with three-phase mains power (3x 230VAC) so as to divide power consumption over three different mains leads. The mains cable has five wires (2.5 mm each): three phases, neutral and earth. For safe operation of the machine, a phase shift of 120° per phase (which is common in Europe) is essential, as this 120°...
  • Page 21: Mains Switch

    1. Make sure that the mains switch is in position “OFF” (see Figure 12a). 2. The thinner electrical cables attached to the Spirit are the pump cables. Attach each pump cable to its corresponding pump motor by connecting it inside the box on top of the pump motor (see Figure 13).
  • Page 22  Danger! When your machine was ordered without a mains plug or when the mains plug has been removed to fit the cable through a small countertop opening, have a qualified electrician connect your Spirit to the mains. The yellow/green or green lead must be connected to earth to properly ground the machine. This is essential to work safely with the machine.
  • Page 23: Note On Phase Shift Of 120Vac (Or 115Vac)

    82% of its original rating (at 208VAC instead of 230VAC) thus 736W for the coffee boilers (was 900W) and 4907W (was 6000W in a Triplette) or 3925W (was 4800W in a Duette) for the steam boiler. Spirit installation manual page 22...
  • Page 24: Filling The Machine With Water From Empty

    Figure 15. Showing the temperature controllers and their on/off switches of the steam boiler and both groups on a Spirit Duette. Switches are in “off” position with levers pointing down, displays are not lit. Procedure 1. If present, remove the filter holders from all groups.
  • Page 25: Expel Air From Coffee System

    You now have to expel remaining air from the coffee system. Procedure 1. While the machine heats up, let each group run for approximately 10 seconds to expel any remaining air pockets.  Check if the machine is leaking. Spirit installation manual page 24...
  • Page 26: First Use

    Within 4 seconds, activate water dispensing by pressing down the hot water lever and releasing it. The control LED’s on all groups will be lit. The hot water lever (red knobs) is located on top of the front panel between the groups. Spirit installation manual page 25...
  • Page 27: Adjust Coffee System Pump Pressure

    Turn the screw counter-clockwise to decrease the pump pressure. 5. De-activate the group when the pressure is correctly set at 9 Bar.  Warning! The set screw is made from brass, to avoid damage use a screw driver that fits the slot snugly. Spirit installation manual page 26...
  • Page 28: Set Hot Water Temperature

    Figure 17. the steam boiler pump pressure is used to set the hot water temperature. Procedure 1. Wait for the machine to be completely warmed up: at least “ON” and heating for 25 minutes and used to dispense hot water at least 5 times over the last 5 minutes. Spirit installation manual page 27...
  • Page 29 Note! Do not adjust the temperature of the hot water by changing the temperature of the steam/hot water boiler as this will decrease the temperature stability of the machine. Spirit installation manual page 28...
  • Page 30: More Information On Our Website

    INFORMATION More information on our website Please check the “Spirit user manual” for information on how to operate the machine (set brew volumes and remarks thereabouts, adjust steam power, change temperature settings, etc.). http://www.keesvanderwesten.com/assets/spirit-user-manual.pdf Please check the “Spirit parts list” for spare parts.
