Surge Protection
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this luminaire. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This luminaire will not be used as a
'Working light' during construction. This will result in the warranty of the luminaire to be void. For warranty duration,
please refer to the data sheet.
Cleaning
Always clean carefully using a soft cloth and a ph-neutral,
alcohol-free, non-abrasive cleaning cloth. Clean & Maintain
the finish twice a year to avoid rust, oxidation or limescale
deposits. If this entire surface is not cleaned correctly, the
finish may become uneven.
Do not use abrasive pads, discs, sandpaper and/or high
pressure hose/gun to clean the luminaire.
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment)
Edition 29.10.24 | Product design and technical data may be subject to change
Page 4 of 4
unios.com/evio
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Evio
Base Codes
7W 600mm
7W 900mm
(One Direction)
EVIO0607
EVIO0907
Base Codes
7W 600mm
7W 900mm
(Two Direction)
EVIT0607
EVIT0907
Class I
Material
Install Person/s
220–240V ~ 50/60Hz
Aluminium
1x
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
One Direction
Two Direction
EVIO
EVIT
Ø A
Ø A
B
Edition 29.10.24 | Product design and technical data may be subject to change
BOLLARD LIGHT
20W 600mm
20W 900mm
EVIO0620
EVIO0920
20W 600mm
20W 900mm
EVIT0620
EVIT0920
IP65
Required Components
+
OR
Head
Head
(One Direction)
(Two Direction)
Sizing Variations
Product Code
A
EVIO0607/EVIT0607
Ø 80
EVIO0907/EVIT0907
Ø 80
EVIO0620/EVIT0620
Ø 115
B
EVIO0920/EVIT0920
Ø 115
All measurements are in millimetres.
Parts
OR
1x Allen Key
2x Allen Key
for 7W
for 20W
OR
3x Screws
3x Dynabolts
w/ plugs for 7W
for 20W
Page 1 of 4
unios.com/evio
Power
7 | 20 Watts
Power
7 | 20 Watts
Bollard
(Body)
B
600
900
600
900
