unios TCR70080 Quick Start Manual

Minimum clearance for luminaire
Risk of Fire – Required clearance from structure members and building elements. Details below:
Barrier required for loose fill insulation
or loose combustible materials
IC-4
Transformer
Thermal
IC-4 Luminaire
Insulation
Tested to and in
accordance with
AS/NZS 60598.2.2:2016
Cleaning
Warning: Before cleaning, disconnect from
mains supply and allow luminaire to cool.
1 2
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment).
Edition 9.7.20 | Product design and technical data may be subject to change
unios.com
Page 4/4
Please ensure the driver is
fixed above any insulation
Building Element Above Fitting
0
Building
0
Structural
0
Member
Recessed
Luminaire
All measurements are based in millimetres.
Corrosion Protection
It is important to note that care must be taken
during installation or maintenance to ensure that
the surface of the luminaire is not damaged. Any
damage, which is exposed to moisture will result
in corrosion occurring.
Please also note that any chemical applications on
the luminaire or chemical contact via installation will
cause corrosion of the surface of the luminaire and will
void the warranty.
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Titanium Curve
Base Small Medium
Codes
TCR70080 TCR70090
Class III
Luminaire only
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
Surge Protection
Ceiling For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this product. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This product shall not be used as a
'Working light' during construction. This will result in the warranty of the product to be void. For warranty duration,
please refer to the data sheet.
Edition 9.7.20 | Product design and technical data may be subject to change
Large
TCR70130
IP Rating Material Install Person/s
44 (Roomside) Aluminium 1x
Sizing Variations
Product Code
C
TCR70080
TCR70090
TCR70130
B
A
unios.com
Page 1/4
DOWNLIGHT
Power
11 ~ 25 Watts
A B C
80 87 70
90 97 79
130 121 114
All measurements are in millimetres.
