unios Zeron Series Quick Start Manual

Cleaning
Warning: Before cleaning, disconnect from
mains supply and allow luminaire to cool.
1 2
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment).
Edition 6.12.19 | Product design and technical data may be subject to change
unios.com
Page 4/4
Corrosion Protection
It is important to note that care must be taken
during installation or maintenance to ensure that
the surface of the luminaire is not damaged. Any
damage, which is exposed to moisture will result
in corrosion occurring.
Please also note that any chemical applications on
the luminaire or chemical contact via installation will
cause corrosion of the surface of the luminaire and will
void the warranty.
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Zeron
Base Surface Mounted Fixed One Fixed Two
Codes
ZESM0020 ZEF10020 ZEF20024
Class I IP Rating Material
220–240V ~ 50/60Hz 65 Aluminium
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
Surge Protection
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this product. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This product shall not be used as a
'working light' during construction. This will result in the warranty of the product to be void. For warranty duration,
please refer to the data sheet.
B
D
Edition 6.12.19 | Product design and technical data may be subject to change
unios.com
Page 1/4
SERIES
Power
20 | 24 Watts
Install Person/s
1x
Sizing Variations
Product Code A B C
ZESM0020 100 150 -
ZEF10020 100 150 120
ZEF20024 100 200 120
All measurements are in millimetres.
Parts
1x Allen Key 4x Wall Plugs 4x Screws
4x Seal Washers
D
-
100
100
