Summary of Contents for Safelift StockPicker SP50
- Page 1 ORIGINAL INSTRUCTIONS StockPicker SP50...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Health & safety regulations ..........Notification of safety precautions ........3 2. Product information ............... SP50 ...................4 Work table ................4 3. Technical data ................. 4. Lift controls ................Indications on the control panel .........6 5. Warning devices .............. -
Page 3: Health & Safety Regulations
1. HEALTH & SAFETY REGULATIONS The operator manual contains instructions for the daily work with the equipment to be handled and used by the operator. The operator manual must always be available to the operator(s) working with the equipment. It is important that: •... -
Page 4: Product Information
2. PRODUCT INFORMATION 2.1 SP50 The SP50 (SP = Stock Picker) is a lift equipped with a height- adjustable work table to handle goods and offer an ergonomic working situation. 2.2 Work table The work table is operated from the control panel in the platform. The work table can be folded up to take up less space when storing the lift. -
Page 5: Technical Data
3. TECHNICAL DATA Max total platform load (operator + work table load) ........... 165 kg Max number of people on the platform ................. Max load of work table 50 kg ................... Lifting time (165 kg) ....................16 s Lifting time of work table (0 kg) ................ -
Page 6: Lift Controls
4. LIFT CONTROLS Emergency stop Raising of work table Lowering work table Signal horn On/Off indicator driving On/Off driving Raising of basket Lowering of basket On/Off warning light Low/High speed indicator Regulation of low/high speed Joystick for driving Electric foot switch Lockable wheels - The SP50 also has automatic brakes on the drive wheels Flashing warning light... -
Page 8: Warning Devices
5. WARNING DEVICES Annual inspection of warning devices and protective devices must be carried out. This refers to the control of their function and status. 5.1 Warning texts WARNING! Ignoring this information will result in immediate danger to life. REQUIREMENT! Correct use of the personal protective equipment or other means. - Page 9 Electricity This lift is not isolated against electric current. It is therefore necessary to have a correct safety distance to the high-voltage conductors or other current carrying objects. Always lock the wheels to prevent the lift from being moved unintentionally Make sure that electric motor drive is activated or lock the swivel castors before raising or lowering the platform, for extra stability.
-
Page 10: Machine Safety
6. MACHINE SAFETY The lift is marked with a CE mark. This means that it is designed, manufactured and described in accordance with EU Machinery Directive 2006/42/EC (see page 17). 6.1 Requirements for personnel & safety regulations To avoid personal injury and machine damage, the operator and operating personnel will be instructed or trained in accordance with the manufacturer’s instructions. -
Page 11: Manufacturer
MANUFACTURER Låglyftar i Sverige AB Kvarnvägen 14 SE-35241 Växjö, Sweden www.safelift.se 6.5 Checks before use 1. Inspect the lift for damage, loose screws or oil leaks. 2. Check that the batteries are charged and that the charging cable is disconnected. -
Page 12: How To Use
7. HOW TO USE All safety regulations, operating instructions, labels and national safety instructions / requirements must be carefully read, understood and complied with. 7.1 Main switch The lift's main switch is located at the lift's left rear wheel. Always switch off the main switch when not in use to save power. -
Page 13: Emergency Lowering
7.8 Emergency lowering The lift is equipped with two emergency lowering systems. Emergency lowering of the platform is done either with an electric button located at the main switch on the side of the chassis or a mechanical button located on the top of the chassis covers. WARNING! If the platform can’t be lowered, NEVER climb the mast. -
Page 14: Maintenance
8. MAINTENANCE WARNING! The service or maintenance on the lift must never be performed with raised platform without having secured the platform against unintentional lowering. Do not stand under the platform when this is being secured in the raised position or when it is removed. -
Page 15: Maintenance Of Battery
Consult a physician in case of contact with battery acid. Old worn out batteries must be replaced with batteries from Safelift or with batteries approved by the manufacturer. Keep the poles and top of batteries clean. -
Page 16: Inspection & Maintenance Intervals
NOTE! The charger must be connected to a socket with earth-fault protection. Do not use the lift while charging. 8.5 Inspection & maintenance intervals A complete inspection consists of periodic visual and functional checks along with minor adjustments in order to ensure the function. The daily inspection prevents the abnormal wear and prolongs the life of all the lifts systems. -
Page 17: Declaration Of Conformity Ce Marking
9. DECLARATION OF CONFORMITY CE MARKING Declaration of conformity Manufacturer: Låglyftar i Sverige AB Kvarnvägen 14 SE-352 41 Växjö SWEDEN Låglyftar i Sverige AB, VAT-no: SE 556820966101, declares that the following product: Model: SP50 Serial number: Year of manufacture: is manufactured in accordance with the following product directive: 2006/42/EC;... - Page 18 NOTES ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 19 NOTES ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 20 ADDRESS WEBSITE Låglyftar i Sverige AB www.safelift.se Kvarnvägen 14 SE-352 41 Växjö E-MAIL Sweden info@safelift.se...
