M1500 – M2000 – M2500 – M3000
S1800 – S2500 – S3000
INSTALLATION WORKBOOK
POWER INVERTER SYSTEM / SLEEPER TRUCKS
TUNDRA INTERNATIONAL
ALL RIGHTS RESERVED
All rights reserved. No part of this publication may be reproduced or used without the prior
written permission of Tundra International. No liability can be accepted for any
inaccuracies or omissions in this publication, although every possible care has been taken
to make it as complete and accurate as possible. The right is reserved to make changes
at any time without prior notice, and without incurring an obligation to make such changes
applicable to previously manufactured products. All information contained in this
publication is based on the latest product information available at the time of publication.
Illustrations and photographs in this publication are intended for reference use only.
© ALL RIGHTS RESERVED
APRIL 2017
Part No. TDIW-0417-EN
First Edition
PRINTED IN CANADA
VISIT OUR WEBSITE
WWW.TUNDRAINVERTERS.COM
PN. TDIW-0417-EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tundra M1500
Summary of Contents for Tundra M1500
- Page 1 All rights reserved. No part of this publication may be reproduced or used without the prior written permission of Tundra International. No liability can be accepted for any inaccuracies or omissions in this publication, although every possible care has been taken to make it as complete and accurate as possible.
-
Page 2: Table Of Contents
MULTIDATA LCD MONITOR – SURFACE INSTALLATION 2-15 / 2-16 INSTALLATION – UNDER THE CAB CABLE PROTECTION CABLE ROUTING 3-2 / 3-3 BATTERIES – FUSE HOLDER INSTALLATION BATTERIES – CONNECTING CABLES BATTERIES – SECURING CABLES NOTES © Tundra International Publication No. TDIW-0417-EN... -
Page 3: General Information
It can cause fire, damage, serious injury, and even death. © Tundra International Publication No. TDIW-0417-EN... -
Page 4: Limitations
- Outstanding efficiency and ultra-precise performance levels at all times - Extends the life cycle of the truck’s electrical charging and starting systems - Lowest cost of ownership – up to 2½ times less than the competition © Tundra International Publication No. TDIW-0417-EN... -
Page 5: Parts Listing
5. Floor adapters (strain reliefs) 6. Drilling template 7. Steel clamps 8. Screws for steel clamps 9. Plastic loom 10. Fuse holder 11. Fuse* * The length and capacity of these parts vary according to each installation kit. © Tundra International Publication No. TDIW-0417-EN... -
Page 6: Installation - Inside The Cab
This electrical current has the potential to kill or injure anyone nearby. For safety reasons, a power inverter must always be installed inside the cab, in the luggage compartment under the bed. © Tundra International Publication No. TDIW-0417-EN... -
Page 7: Think Quality
INSTALLATION WORKBOOK Power Inverter System – Sleeper Trucks INSTALLATION – INSIDE THE CAB 2-2 THINK QUALITY QUALITY WORK RESULTS © Tundra International Publication No. TDIW-0417-EN... -
Page 8: Where To Install The Inverter
The power inverter MUST be installed inside the cab, in the luggage compartment under the bed. 1. Flat on the floor On a vertical steel wall - NEVER IN A CABINET - NEVER IN THE BOOTS STORAGE - NEVER BEHIND THE SEAT © Tundra International Publication No. TDIW-0417-EN... -
Page 9: Ventilation
If the power inverter is installed on the floor, make sure it is as close as possible to a wall. A protective plate could be installed over it so that this space can serve as additional storage. © Tundra International Publication No. TDIW-0417-EN... -
Page 10: Determining The Best Location
4. The cables should be kept close to the power inverter, but not too close. They need to be easily installed on the inverter’s DC inputs. 5. Be aware of the cylinders used to lift the bed. They must not come into contact with the power inverter or its cables during bed operation. © Tundra International Publication No. TDIW-0417-EN... -
Page 11: Floor Adapters - Pilot Holes
Power Inverter System – Sleeper Trucks INSTALLATION – INSIDE THE CAB 2-6 FLOOR ADAPTERS – PILOT HOLES 1. Using the template included in the CM installation kit, drill two 1/8″ pilot holes to validate your choice of location. © Tundra International Publication No. TDIW-0417-EN... -
Page 12: Floor Adapters - Hole Saw Drilling
Drill the carpet with a hole saw punch that’s the same size as the cables, and then drill the floor from underneath with the required hole saw for your floor adapters. You’ll get a better finish inside the truck. © Tundra International Publication No. TDIW-0417-EN... -
Page 13: Floor Adapters - Installation
DC inputs of the power inverter. Please note this when inserting cables through the floor. This will allow attaching both cables together and eliminate any possible vibrations of the cables, which could lead to loosening of connections. © Tundra International Publication No. TDIW-0417-EN... -
Page 14: Power Inverter - Installation 2-9
5. Secure the power inverter firmly to the vehicle using the included bolts and self-locking nuts. Make sure the power inverter is square with the surrounding surfaces before drilling. Your work will look much better! CONTINUED ON P. 2-10 © Tundra International Publication No. TDIW-0417-EN... - Page 15 2. Using the included bolts, install the cables to the DC inputs of the power inverter with the correct polarity. Maximum tightening torque is 20 lb-ft. © Tundra International Publication No. TDIW-0417-EN...
- Page 16 6. Install the plastic loom over both cable sections. Use the loom included in the CM installation kit. 7. Using a plastic tie, secure the cables together so they do not vibrate. © Tundra International Publication No. TDIW-0417-EN...
-
Page 17: Grounding Verification
1. Using a test lamp, connect a 12 V power source to the grounding bolt on the back panel of the power inverter. If the lamp comes on, the grounding is adequate. © Tundra International Publication No. TDIW-0417-EN... -
Page 18: Grounding Procedure (If Required)
2. The monitor cable measures 20 ft. (6 m). It must not be lengthened or doubled. 3. The multidata LCD monitor can be installed flush or surface mounted. © Tundra International Publication No. TDIW-0417-EN... -
Page 19: Multidata Lcd Monitor - Recessed Installation 2-14
5. Connect the monitor cable to the multidata LCD monitor and attach the monitor to the panel using the included screws or any other type of bolts or screws with a maximum diameter of 1/8″ (0.125″). © Tundra International Publication No. TDIW-0417-EN... -
Page 20: Multidata Lcd Monitor - Surface Installation 2-15
20 ft. (6 m) cable from the multidata LCD monitor to the desired location. 2. Make sure the monitor cable does not come into contact with sharp edges that could damage it. © Tundra International Publication No. TDIW-0417-EN... - Page 21 (part 1) and secure the cover to the desired surface. 5. Attach Part 2 to Part 1 by pressing firmly. 6. Connect the cable to the multidata LCD monitor. 7. Install the multidata LCD monitor with the included screws. © Tundra International Publication No. TDIW-0417-EN...
-
Page 22: Installation - Under The Cab
DC cables can produce magnetic fields strong enough to interfere with radio communication devices. Tying them together will fuse the positive and negative fields and eliminate most negative effects. © Tundra International Publication No. TDIW-0417-EN... -
Page 23: Cable Routing 3-2
1. Route the power inverter cables to the battery box. Fasten them securely to the chassis of the cab using the metallic clips and self- drilling screws included in the CM installation kit. © Tundra International Publication No. TDIW-0417-EN... - Page 24 Do not hesitate to use several plastic fasteners to distribute the weight of the cables and to limit the stress on each plastic tie. © Tundra International Publication No. TDIW-0417-EN...
-
Page 25: Batteries - Fuse Holder Installation
Never apply a greasy “protective” product on battery posts. This will attract contaminants, interfere with the quality of the connections, and discharge the batteries. If necessary, use a liquid protective product that dries completely. © Tundra International Publication No. TDIW-0417-EN... -
Page 26: Batteries - Connecting Cables
2. Connexion of the cables must be made in the following order: 1. Positive – 2. Negative A spark may occur when connecting the negative cable. This is normal if the power inverter capacitors are not charged. © Tundra International Publication No. TDIW-0417-EN... -
Page 27: Batteries - Securing Cables
It is preferable to never attach the fuse holder to a battery box wall. The safest location is on top of the batteries. © Tundra International Publication No. TDIW-0417-EN... -
Page 28: Notes
INSTALLATION WORKBOOK Power Inverter System – Sleeper Trucks NOTES 4-1 © Tundra International Publication No. TDIW-0417-EN... - Page 29 INSTALLATION WORKBOOK Power Inverter System – Sleeper Trucks Thanks to Kenworth Maska and their team for their collaboration in the preparation of this manual. TUNDRA INTERNATIONAL TRUCK POWER INVERTERS Publication No. TDIW-0417-EN Printed in Canada © Tundra International Publication No. TDIW-0417-EN...
