NEC POWERMATE PROFESSIONAL - SERVICE MANUAL 09-1997 Service Manual page 17

2-2 Illustrated Parts Breakdown
Table 2-1 PowerMate Professional Series Field-Replaceable
Item Description
1 AC Power Cable
2 Chassis Intrusion Switch and
Cable Assembly
2a Plastic Chassis Intrusion Switch
Housing
3 LED Power Cable
4 HDD LED Cable
5 Sleep Switch Cable Assembly
6 Reset Switch Cable Assembly
7 Audio Cable
8 Microsoft Mouse
9 Keyboard, Chicony
10 Plastic Blank Panel - 5 1/4"
11 Front Bezel w/IR PCB and Cable
12 PowerMate Professional Logo
Panel
13 Internal Power Cable and Switch
14 Reset/Sleep Button
15 PCB Guide
16 200-Watt Power Supply with Fan
w/o Power Switch
17 Power Supply Plastic Air Flow
Duct
18 Side Cover
19 Adaptec SCSI Host Adapter
20 Matrox Mystique video board with
2-MB video RAM
21 Number Nine Imagine 128
Series 2 video board with 4-MB
video RAM
22 Top Cover
23a 8-Watt Speaker with Cables and
Adapter
____________
*
This data was prepared January 1998. For an up-to-date listing of spare parts, please call FaxFlash at 1-888-329-0088
(or 1-978-635-6090 outside the U.S.) and order document 42181874.
Parts List*
Part Number
808-857649-101A
158-052263-000
158-052262-000
158-052170-001
158-052169-001
158-050895-004
158-050685-031
158-050824-000
158-052115-000
158-052121-000
158-030810-000
158-052129-000
158-030872-075
158-050906-001
158-050896-003
158-052127-012
158-052259-000
158-031073-000
158-052127-002
158-052132-000A
158-052254-000A
158-052264-000A
158-052127-013
158-050980-001
