Table 1-6 Lite-on 24X CD-ROM Reader Specifications
Feature
CD-ROM Reader
Features
Data Transfer Rate
Average Access Time
Disc
Interface
Audio Specification
Front Panel
Rear Panel
Power
Startup Current:
Seek Power (typical):
Operating Power (typical):
Idle Mode Power (typical):
Standby Mode Power
(typ):
Sleep Mode Power
(typical):
Voltage Tolerance:
Specification
Lite-on Technology 24X CD-ROM reader LTN-242
20X max: 1,600 ~ 3,000KB/Sec (12X ~ 20X)
24X max: 1,600 ~ 3,600KB/Sec (12X ~ 20X)
110 ms typical
Disc format:
ISO9660 Data Discs
CD-ROM (Mode 1 and Mode 2)
Mixed Mode (Audio Combined CD-ROM disc)
CD-ROM/XA (Mode 2, Form 1 & Form 2)
CD-I/FMV
Video CD
CD-DA
Photo-CD (Single & Multisession)
Karaoke CD
CD Extra
Disc Diameter: 8 cm and 12 cm
ATAPI/E-IDE
Signal to Noise Ratio: 70 dB typical
Headphone Level: 0.6 Vrms at 1 Khz, 33 Ohm Load
Power On/Busy LED
Open/close/Stop Button
Play/skip Button
Volume Control
Stereo Headphone Jack
Emergency Eject Hole
IDE Interface
Analog & Digital Audio Outputs
Power Input
Mode Select Jumper
12V (peak): 1.5 amps; 5V (RMS): 0.6 amps
5.6 watts
4.2 watts
3.8 watts
1.0 watts
0.7 watts
+5V +/-5%; +12V +/-10%
Specifications 1-7
