- Page 1 INSTALLATION & OPERATION MANUAL RPSI EVAPORATIVE COOLER ORIGINAL ENGLISH INSTRUCTIONS...
-
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS FAULT CODE DESCRIPTIONS COOLER VIEWS TROUBLESHOOTING COOLER CONTENTS MAINTENANCE SCHEDULE INSTALLATION COMPONENTS MAINTENANCE FREQUENCY OPTIONAL COMPONENTS WINTER OPERATION AND SHUTDOWN COOLER CONTROLS MAINTENANCE SAFETY MAINTENANCE CHECKLIST TRANSPORT MOVING THE COOLER MAINTENANCE INSTRUCTIONS LIFTING THE COOLER INSPECTION PROCEDURES UNPACKING THE COOLER PUMP... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS WARNING - TO REDUCE THE RISK OF FOR FUTURE REFERENCE. FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: FOR EUROPE a) Use this unit only in the manner intended This appliance can be used by children aged by the manufacturer. -
Page 5: Maintenance Note
• Check the proposed cooler location, to ensure that it is structurally capable of supporting the weight of the cooler, or Seeley International provides the following information as a provide an adequate alternate load bearing structure. guide to contractors and employees to assist in minimising risk •... -
Page 6: Cooler Views
COOLER VIEWS DOWN DISCHARGE BOTTOM 1150 1150 Drain Water Inlet Electrical Entry (Down & Side Discharge) 1190 Electrical Entry (Top Discharge) TOP DISCHARGE SIDE DISCHARGE ILL3989 Dimensions are in mm 6 | RPSI INSTALLATION, OPERATION & MAINTENANCE MANUAL 859753-A... - Page 7 COOLER VIEWS (DOWN DISCHARGE SHOWN) ILL3990 Item Description PAD FRAME ASSEMBLY CONTROL BOX FAN/MOTOR/SCROLL ASSEMBLY BOTTOM RAIL TOP RAIL WATER SPREADERS PUMP WATER INLET ADAPTOR WATER INLET ELBOW FLOAT VALVE WATER OVERFLOW ASSEMBLY BASE FRAME EXTRUSION CABINET TOP CABINET TOP PLATES CORNER PILLAR WATER RESERVOIR RPSI INSTALLATION, OPERATION &...
-
Page 8: Cooler Contents
TOLERANCES LINEAR TOLERANCES ANGULAR DATE STAMP This drawing is the property of Seeley International and must not be reproduced or copied in any way without written consent of the proprietors of the copyright. NIL DECIMAL PLACE ± NIL DECIMAL PLACE ±... -
Page 9: Installation
INSTALLATION COOLER LOCATION ACCESS FOR SERVICING AND MAINTENANCE Check the proposed cooler location to ensure that it is structurally capable of supporting the weight of the cooler, or The cooler should be installed in a position that allows adequate provide an adequate alternate load bearing structure. access for installation, and future maintenance and servicing activities. -
Page 10: Mounting / Support
INSTALLATION MOUNTING / SUPPORT SUPPLY AIR DUCT CONNECTIONS The cooler shall be fixed to its support structure using self It is the installers responsibility to adequately secure ductwork drilling screws (not provided) through the steel mount on the to the cooler. All ducts must be independently supported. bottom of unit. -
Page 11: Electrical Requirements
INSTALLATION OF THE COOLER MUST CONFORM TO LOCAL ELECTRICAL RULES, REGULATIONS AND STANDARDS. It is a requirement of Seeley International that all coolers be wired with a dedicated circuit and circuit breaker/fuse at the distribution board. A mains isolation switch, with all pole disconnection, shall be Legend furnished by the contractor and installed adjacent to the cooler. -
Page 12: Water Requirements
WATER REQUIREMENTS WATER SUPPLY INSTALLATION WATER FLOAT VALVE The cooler requires a permanent water supply to be connected. An internal float valve controls the water level inside the reservoir. The float valve must be set to maintain the water level INSTALLATION OF THE WATER SUPPLY MUST CONFORM approximately 30mm below the overflow level. -
Page 13: Water Bleed Control
WATER REQUIREMENTS WATER BLEED CONTROL OPTIONAL WATER MANAGER KIT Important! When using the overflow pipe, it is essential to An optional Water Manager Kit is available which contains an continuously bleed a small amount of water to reduce the inlet water solenoid valve, water salinity probes, and an electric accumulation of salts and minerals in the cooler. -
Page 14: Cooler Control Options
Coolers are supplied with a 20m (66’) control cable. Longer • Turn the SPEED knob, to select the required fan speed. cable lengths are available for order via Seeley International. To run the cooler in COOL mode: Failure of the product or components to operate correctly due •... -
Page 15: Magiqtouch Wall Control
COOLER CONTROL OPTIONS MAGIQTOUCH WALL CONTROL M1 INDUSTRIAL CONTROL The MagIQtouch M1 industrial controller is a 24Vdc (SELV) circuit that offers various inputs and outputs to achieve different functions of the cooler as well as status feedback. BM S IN BM S IN DU ST RI DU ST RI... -
Page 16: Magiqcool Wall Control
COOLER CONTROL OPTIONS MAGIQCOOL WALL CONTROL MANUAL MODE Manual mode offers independent control of the fan speed and cooling function. With the wall control switched ON, press the button until MAN is shown on the display. Press the button to switch between COOL and VENT INITIAL INSTALLATION ILL1123-B Upon initial installation of a cooler, or after the wall control has... -
Page 17: Delayed Start
COOLER CONTROL OPTIONS DELAYED START ENTERING PARAMETER MODE The wall control can be programmed to To enter Parameter mode, the following process must be start in a specified number of hours. It can carried out within 4 minutes of power being applied to the only be set when the cooler is OFF. -
Page 18: Commissioning
COMMISSIONING Owner Name: ................Dealer: ..................Address: ..................Date Installed: ....................................Model No: ................... Telephone: ............Serial No: ................... Installer: ..................INSTALLATION CHECKLIST This checklist only covers the key points to be observed during installation. Always refer to the relevant sections of the installation manual for full details. -
Page 19: Fan Check
COMMISSIONING FAN CHECK COOLING PAD SATURATION CHECKS Important! Risk of injury to body parts coming into contact with If the water flow rate to the cooling pads is too high, water draw- a rotating fan. Ensure fan is clear of all objects before starting. off or carryover will occur, often resulting in unit damage and premature component failures. -
Page 20: Control Box Leds
COMMISSIONING CONTROL BOX LEDS POWER LED INDICATES The cooler has a series of flashing LEDs visible on the Normal operation when electronics box. HALL EFFECT motor ON. No power to motor. THERMAL DIAG SPEED POWER ILL1856-A Note: If the POWER LED is ON but no other motor LED’s, check the Motor Sensor cable is plugged in correctly. -
Page 21: Fault Code Descriptions
FAULT CODE DESCRIPTIONS The DIAGNOSTIC LED can flash either Green or Red and indicates the fault status of the cooler. DIAG LED FAULT CODE FAULT DESCRIPTION SUGGESTED REMEDY 2 Green Flash then 2 seconds NORMAL OPERATION 1 Red Flash Check communication cable connections. COMMUNICATION FAILURE then 2 seconds Fault Code #1... -
Page 22: Maintenance Schedule
MAINTENANCE SCHEDULE MAINTENANCE FREQUENCY Maintenance of an evaporative cooler is essential in maintaining proper performance and reliability. All maintenance must be done by competent, qualified, licensed technicians, in accordance with National and/or Local Regulations. The frequency of service is largely dependent on the conditions under which the cooler is operated. External factors, such as air and water quality, can affect the serviceable life of the cooler and its components. -
Page 23: Maintenance Checklist
Replace - To remove the existing item and replace with a specified genuine replacement part. Note! It is important that only new Seeley International factory authorised replacement parts be used in this cooler. Failure to do so may void warranty, cause improper cooler performance, and unsafe operation. -
Page 24: Maintenance Instructions
MAINTENANCE INSTRUCTIONS INSPECTION PROCEDURES WATER PROBE Drain the cooler reservoir by initiating a manual drain Unscrew the probe from the pump body. Isolate and lockout the power supply to the cooler. Clean the pins by wiping the contact surfaces with a soft cloth - do NOT use abrasives. -
Page 25: Warranty Terms (Australia)
WARRANTY TERMS (AUSTRALIA) HOW TO REGISTER YOUR PRODUCT WARRANTY (Australia only) Please register your warranty online by visiting seeleyinternational.com Step 1 - select “Support” then “Register for Warranty” Step 2 Enter your product serial number and “Submit” Step 3 Enter the required information and “Submit” Important Note: You need to have the following information to complete your registration: •... - Page 26 WARRANTY TERMS (AUSTRALIA) In this warranty: We or us means Seeley International Pty Ltd (Seeley) ABN 23 054 687 035, and our contact details are set out at the end of this warranty; You means you, the original end-user purchaser of the Goods;...
- Page 27 PRIVACY NOTICE Seeley International Pty Ltd ABN 23 054 687 035 will use the personal information you provide us with to provide warranty support for the product you have purchased and to inform you about other products and services. If you choose not to supply us with the information requested, we may be unable to provide you with warranty support.
- Page 28 Online Support Portal (AUS/NZ) Scan or Click QR Code It is the policy of Seeley International to introduce continuous product improvement. Accordingly, specifications are subject to change without notice. Please consult with your dealer to confirm the specifications of the model selected.
