- Page 1 Height adjustable unit for Ropox Toilet Supports User manual This leaflet should always be kept with the product. TF 200.0124_eng / Rev 01 / Date 01-01-2025...
-
Page 2: Table Of Contents
Content Key to symbols ............................3 Safety ................................. 3 2.1 Product labelling ..........................5 General requirements ..........................6 3.1 Product information ........................6 3.2 Product description ........................7 3.3 Application purposes ........................7 3.4 Suitable operator ........................... 7 3.5 Product dimensions ........................7 Instructions for use .......................... -
Page 3: Key To Symbols
1. Key to symbols Warning Indication of a potentially dangerous situation. If not avoided, it can result in serious injury or death. Caution Indication of a potentially hazardous situation that may result in minor or moderate bodily injury. The symbol is also used to warn of improper use. - Page 4 The information in this manual is based on correct installation in accordance with the installation instructions for this product. Ropox cannot be held responsible if the product is used in a way that differs from that stated in this manual and/or installation instructions.
-
Page 5: Product Labelling
2.1 Product labelling This product is CE marked in accordance with: European Medical Devices Regulation (EU)2017/745 Council Directive 2011/65/EU, RoHS Manufacturer's name and address Production date Item number Serial number Consult manual before use Refer to the manual for important safety-related information, warnings and precautions. -
Page 6: General Requirements
3. General requirements 3.1 Product information Producent: Ropox A/S Ringstedgade 221, DK-4700 Næstved +45 55 75 05 00 Email: Info@ropox.com Variants Item number Model 40-40450 Quick release 05707581014802 40-40451 Requires tools 05707581014819 Life expectancy 5 years MDR Class Class I... -
Page 7: Product Description
3.2 Product description The height-adjustable unit allows for easy height adjustment of Ropox Toilet Supports, providing optimal comfort when in use. 3.3 Application purposes For users who need support to sit down and get up from the toilet, Toilet Supports are a great disability- friendly aid. -
Page 8: Instructions For Use
4. Instructions for use 4.1 Mounting interfaces Construction The wall must be made of screw-retaining material approved for wet rooms. The shaded area indicates the minimum area for wall reinforcement. Reinforcement is best installed from floor to ceiling. It is important that there is room for the plate cover to move 100 mm up and down. -
Page 9: Installing The Product
4.2 Installing the product 1. Drill holes according to the desired height and width of the toilet supports (see section on mounting interfaces) 2. Screw the wall plate to the wall, making sure it is straight horizontally and vertically TF 200.0124_en... - Page 10 3. Mount the faceplate from above in the wall bracket. Make sure that the clamping handle is loosened and that the locking piece connected to it is aligned to fit in the slot on the wall bracket. TF 200.0124_en...
-
Page 11: Installation Of Toilet Support
4. Mount the locking plate with the two screws at the bottom of the front bracket 5. Click the bottom cover plate on 4.3 Installation of toilet support 1. Find the 6 lock nuts supplied 2. Loosen the clamping handle so that it points outwards and place the toilet support over the threaded rods and guide the clamping... - Page 12 3. Screw the nuts tightly over the threaded rods. Take special care when installing the top two nuts as the screwdriver head can leave marks on the toilet seat drum 4. Slide the cover plate with cut-out over the clamping handle and click it into place 5.
-
Page 13: Operating The Product - Quick Release
4.4 Operating the product – quick release To adjust the height of the height-adjustable unit: First, unlock the height adjustment by pulling the handle upwards The toilet support can now be steplessly adjusted to the desired height. To lock into position, press the handle downwards. -
Page 14: Operating The Product - Without Quick Release
4.5 Operating the product – without quick release To adjust the height of the height-adjustable device without quick release: Remove the lower cover plate. A small flat screwdriver can be used in the slot on the underside Use an Allen key to loosen the screw by turning it anti-clockwise one turn The height adjustment is now freely adjustable. -
Page 15: Cleaning
Ethanol-based disinfectants can also be used as long as product specifications and safety precautions are followed. The following products have been tested by Ropox and can be used as long as they are diluted according to the product instructions. 5.1 Pre-approved disinfectants... -
Page 16: Environmental Considerations
7. Environmental considerations The product is not intended for disposal as municipal waste. Proper disassembly, sorting and disposal of components must be performed by waste management. Component Disposal recommendation Handle Metal Wall plate Metal Front plate Metal End caps Residual waste Accident/incident reporting The manufacturer of this product recommends that any accident/incident related to this product that fulfils all of the criteria below should be reported to the relevant authority and to the manufacturer.
