Installation, Operation, and Maintenance
Single Packaged Heat Pump
Entry, Convertible, 2-5 Ton, R-454B
A5PH3024A1000A
A5PH3030A1000A
A5PH3036A1000A
A5PH3042A1000A
A5PH3048A1000A
A5PH3060A1000A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
November 2024
N N o o t t e e : : "Graphics in this document are for representation only. Actual
model may differ in appearance."
N N o o t t e e : : "Unit specific Service Facts available online."
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
