Service Facts
Single Packaged
Cooling/Electric Heat
A5PA3030A1000A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
September 2024
N N o o t t e e : : "Graphics in this document are for representation only. Actual
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
A A 5 5 P P A A 3 3 0 0 3 3 0 0 A A - - S S F F - - 1 1 A A - - E E N N
model may differ in appearance."
Advertisement
Table of Contents
Related Manuals for Trane A5PA3030A1000A
Summary of Contents for Trane A5PA3030A1000A
- Page 1 Service Facts Single Packaged Cooling/Electric Heat A5PA3030A1000A N N o o t t e e : : “Graphics in this document are for representation only. Actual model may differ in appearance.” S S A A F F E E T T Y Y W W A A R R N N I I N N G G Only qualified personnel should install and service the equipment.
-
