Datacolor Light Booth ES User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Datacolor Light Booth ES
User Manual
 Please read the operation manual carefully before use.
 Please keep the manual properly for reference.
*This document has been translated by AI and may contain inaccuracies. Please refer to the
original text or consult a professional for precise information.
1
Datacolor Light Booth ES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Light Booth ES and is the answer not in the manual?

Questions and answers

Related Manuals for Datacolor Light Booth ES

Summary of Contents for Datacolor Light Booth ES

  • Page 1 Datacolor Light Booth ES Datacolor Light Booth ES User Manual  Please read the operation manual carefully before use.  Please keep the manual properly for reference. *This document has been translated by AI and may contain inaccuracies. Please refer to the...

  • Page 2: Security Information

    Datacolor Light Booth ES Please read carefully when any signs appear. This symbol is used to remind you of potential dangers and behaviors that require attention. Security information - Before installing and operating this device, please read this manual carefully and follow the instructions.

  • Page 3: Table Of Contents

    Datacolor Light Booth ES Contents Product Introduction ................... Function and Features ................Assembly instructions ................. Power on ....................... Operation .....................  Button Description ........................11  Turning on and off single light source ..................11  Turning on and off combined light sources ................12 ...

  • Page 4: Product Introduction

    Datacolor Light Booth ES Product Introduction This product is a compact standard light source box, which can provide up to 5 standard light sources. It can be widely used in the field of Color quality Management. Appearance of Light Booth Component list: luminaire x 1, box x 1, diffuse glass x 1, 45 °...

  • Page 5: Function And Features

    Datacolor Light Booth ES Function and Features  Light source Configuration Five Light sources: Daylight: CIE D65 (6500 K). - Option 1: Fluorescent CWF (4150 K) or LED 4000 K. Option 2: Fluorescent lamp TL84 (4000 K) or fluorescent lamp U35 (3500 K) or fluorescent lamp TL83 (3000 K).

  • Page 6: Assembly Instructions

    Datacolor Light Booth ES Assembly instructions for Light Booth Select a flat table for installation to ensure that there is enough space for installing the light booth. Be careful not to scratch the surface of the box during installation. Step 1 Place the base plate on a flat surface.
  • Page 7 Datacolor Light Booth ES Step 5 Insert the groove on the right side panel into the slit on the back panel and tighten the two screws at the back. Step 6 Tighten the screw between the right side panel and the bottom panel.
  • Page 8 Datacolor Light Booth ES Step 8 Ensure that the rough side of the diffuser faces downwards. Place the right pin of the diffuser into the right bracket under the light box emitter. Then place the left pin into another bracket.

  • Page 9: Power On

    Datacolor Light Booth ES Power On 1 Fully insert the AC power cord plug into the power inlet socket. The main power inlet socket is located at the rear of the luminaire. 2 The power switch is located on the lower left front side of the luminaire. Switch on and activate the device.

  • Page 10: Operation

    Datacolor Light Booth ES Operation Button Description 1 Light source button  [Daylight]: fluorescent light source  [Option 1]: set light source for option 1  [Option 2]: set light source for option 2  [CIE A]: Incandescent light source ...

  • Page 11: Turning On And Off Single Light Source

    Datacolor Light Booth ES Turning on and off single light source 1 Press the light source button to light up the required Light source. The LED indicator light in the upper right corner of the pressed button will light up. The LCD screen will display the Name of the required light source, the standard color temperature CCT, the current illuminance Ev or UV radiation intensity, and the lamp remaining life Timer.

  • Page 12: Turning On And Off Combined Light Sources

    Datacolor Light Booth ES Turning on and off combined light sources 1 The UVA lamp can be combined with any other light source. 2 Press other light source buttons to light up a light source. Press the UVA lamp light source button again to turn on the UVA lamp.

  • Page 13: Adjust The Uv Lamp Intensity In The Combined Light Sources

    Datacolor Light Booth ES Adjust the UVA intensity in the combined light sources 1 First, turn on the UVA light separately and press the DIM+ or DIM- button to adjust the UVA intensity value to the desired level 2 Refer to "Turning on and off Combined light sources" again to light up the combined light source.

  • Page 14: Appendix

    Datacolor Light Booth ES Appendix Maintenance 1 Replace the lamp Immediately replace the burnt out or expired lamp tubes to maintain overall performance standards. Note: We Recommend replacing the complete set of lamps. The service life of Recommend lamps is listed in the table below.
  • Page 15 Datacolor Light Booth ES Be careful:  Before maintenance, be sure to Close the power switch and unplug the input power cord.  Before replacing the lamp tube, please hold one hand under the diffuser glass and release the diffuser glass lock with the other hand. Slowly lower the front end of the diffuser glass until it reaches the fully open vertical position.
  • Page 16 Datacolor Light Booth ES 2 Replace fluorescent/LED tubes  Rotate the lamp tube by 1/4 turn with both hands simultaneously (rotation is not required), remove the lamp tube from the two grooves, and dispose of the waste lamp tube properly. The reference diagram is as follows.
  • Page 17 Datacolor Light Booth ES...
  • Page 18 Datacolor Light Booth ES 4 Query the Reset Times of the Lamp Lifespan Timer When the lamp lifespan timer is reset, the reset count will increase by 1 (initially 0). Press the light source button to be queried to light up the light source. Press the DIM+ button continuously for more than 5 seconds to enter the reset count query page.

  • Page 19: Switch The Light Source Configuration

    Datacolor Light Booth ES 2 Switch the light source configuration 1 Optional Lamp Tube Option 1 can be optionally equipped with CWF or LED 4000K. Option 2 can be optionally equipped with TL84, U35, or TL83. To replace the lamp tube, please refer to the "Replacing the lamp"...

  • Page 20: Replace The Fuse

    Datacolor Light Booth ES 3 Replace the Fuse  Before operation, please Close the power switch and unplug the input power cord.  Use tools to open the fuse box. The fuse box is located below the power socket.  Take out the damaged fuse and replace it with a spare fuse.

  • Page 21: Technical Specification

    Datacolor Light Booth ES Technical Specifications Light Booth Observation area Dimensions (H x W x D) H 585 x W 697 x D 541 mm H 420 x W 640 x D 480 mm Weight/Shipping Weight 26.5 Kg/31.5 Kg (excluding the weight of 2.2 Kg for the optional 45...
  • Page 22 Datacolor Light Booth ES About Datacolor Datacolor, a global leader in color management solutions, provides software, instruments and services to assure accurate color of materials, products, and images. The world’s leading brands, manufacturers and creative professionals have used Datacolor’s innovative solutions to consistently achieve the right color for more than 45 years.
