  • Page 2 User Documentation User Documentation ® ® Ahiba MUL TIPRECISE TC Ahiba MUL TIPRECISE TC Published: October 2003 Version 2003/1 Doc. No. 62-990036-ENG...

  • Page 4: Table Of Contents

    AHIBA MULTIPRECISE TC – Table of Contents Safety Precautions and Warnings............. Symbols That Appear on Unit..............Important Notes..................Introduction & Typical Applications............Operating Principle ................. Typical Applications ................Main Components ..................Front / Left Side ..................Rear......................Various Components ................Dye Container ..................
  • Page 5 AHIBA MULTIPRECISE TC – Table of Contents Controller ..................... Keypad / Display..................Keypad..................... Activating / Programming the unit............. LCD Display....................Control Functions..................Writing a Dyeing Program................. Program Example..................Main Menu....................Edit Program Menu................... Edit Program Names ................Run Program Menu................... Display actual Values................

  • Page 6: Safety Precautions And Warnings

    Safety Precautions Safety Precautions and W arnings and W arnings ahiba...
  • Page 8 AHIBA MULTIPRECISE TC – Safety Precautions & Warnings Safety Precautions and Warnings • The unit weight is approximately 68KG (149 lbs). It is recommended that a minimum of 4 persons lift the unit. • To prevent an electrical shock or fire, have a qualified electrician connect the unit to the appropriate power source.

  • Page 9: Important Notes

    AHIBA MULTIPRECISE TC – Safety Precautions & Warnings Important Notes: Please complete the product quality survey form and return it to the address printed on the form. Thank you for helping us to evaluate the quality of our products and services. This user’s guide is an essential part of the AHIBA Multiprecise TC.
  • Page 10 5 bar (tolerance ±0.5 bar) is reached. Residual Risks: Observe all auxiliary standards and regulations as cited in the material safety data sheets of all chemicals being used. Datacolor assumes no responsibility for the handling of chemicals. ahiba...

  • Page 12: Introduction & Typical Applications

    Introduction & T ypical Introduction & T ypical Applications Applications ahiba...

  • Page 14: Typical Applications

    AHIBA MULTIPRECISE TC – Introduction & Typical Applications AHIBA Multiprecise TC has two independently operated dyeing chambers which continuously circulate the dyebath through the sample, duplicating a beam-and-package dyeing process. Dyeing chambers may be configured as (2) 1 liter baths, (2) two liter baths or (1) one liter and (1) 2 liter baths.
  • Page 15 AHIBA Multiprecise TC – Typical Applications Type of material: Piece Skein Tops Loose Material Type of fiber: Synthetic, Natural, Blends Min. liquor ratio: 1 : 5 ahiba...

  • Page 16: Main Components

    Main Components Main Components ahiba...
  • Page 18 AHIBA Multiprecise TC – Main Components 1. Stainless Steel Outer Body 2. Memory Card Slot 3. Display Unit Indicator Switch 4. Keypad 5. Graphic Display 6. Alarm Indicator Lights 7. Status Panel Process Lights 8. Pressure Indicator Gauge 9. High Temperature Lid 10.
  • Page 19 AHIBA MULTIPRECISE TC - Main Components 1. Power Line 2. Alarm Output 3. Printer 4. Cold Water Inlet 5. Hot Water Inlet 6. Drain ahiba...

  • Page 20: Various Components

    AHIBA MULTIPRECISE TC - Various Components Control panel, consisting of LCD display, keyboard, control lights, beaker control switch, and memory card slot. The dye container (1000 or 2000 ml volume) with high temperature lid is shielded by a protective lexan glass, thus providing additional safety for the user.
  • Page 21 AHIBA MULTIPRECISE TC - Dye Container HT Lid Dye Basket Dye Glass Pump Motor Magnetic Coupling Metal Beaker Circulation Direction (from inside out) Dyebath ahiba...

  • Page 22: Dyebath Circulation Pump

    AHIBA MULTIPRECISE TC - Dyebath Circulation Pump Function Principle The function principle of the Ahiba Multiprecise TC is based on the centrifugal pump system, devoid of any lines and valves. The magnetically driven pump feeds the treatment dye bath continuously through the material.
  • Page 23 AHIBA MULTIPRECISE TC - Dosing Pump Diaphragm dosing pumps are used in the Ahiba Multiprecise allowing linear, progressive or degressive dosages. The dosing inlets are located on the left side of the unit ensuring rapid distribution of the dosing liquid within the dye container. Dosing Lines Attention: Before running a process you must prime the...
  • Page 24 AHIBA MULTIPRECISE TC - Material Carrier The different material carriers and accessories are made of rust and acid-resistant stainless steel. Loaded material carriers are coupled to the body of the pump and locked in place inside the dye container as one unit. Example Handle Locking Screw...

  • Page 26: Installation And Startup

    Installation and S tart Up Installation and S tart Up ahiba...

  • Page 28: Initial Steps

    AHIBA Multiprecise TC – Initial Steps • Setup and connect the warm water inlet supply • Setup and connect the cool water inlet supply • Connect the drain The tube from the drain outlet must be installed so that WARNING human contact with discharging water is impossible.
  • Page 29 Use only filtered, softened cooling water <10°dH ! Water filters (part number 942332) are available from Datacolor. The water pressure must be 5 bar (72.5 psi) or less, no less than 2.5 bar (36.25 psi). The water pressure must be consistant in order to achieve accuracy during a water fill.
  • Page 30 AHIBA Multiprecise TC - Set-up / Water Inlet and Drain Connections Use pressure hoses [1and 2] with a nominal inner diameter of ( 10mm / 3/8” ). Use pressure hose [ 3 ] with a nominal inner diameter of ( 25mm / 1” ). The drain hose must be able to withstand temperatures up to 140°C (284°F).

  • Page 31: Power Connection

    AHIBA Multiprecise TC – Power Connection Establishing the power connection Prior to connecting the Ahiba Multiprecise TC, ensure that the local line voltage agrees with the line voltage specified on the name plate. A qualified electrician must connect the proper line receptacle to the end of the power cable, in order to meet local requirements.
  • Page 32 AHIBA Multiprecise TC – Power Connections Main Power Supply Connection The Ahiba Multiprecise TC is shipped without a power disconnect plug. A certified electrician must install an appropriate plug that meets local requirements. The Plug must be rated for 20 amps, 480V minimum, 3L / N / GN. For 380 V AC standard mains (e.g.

  • Page 33: Printer Connection (Optional)

    AHIBA Multiprecise TC – Printer Connection (Optional) 1. Connect the serial printer via the RS 232 printer cable to the printer port [1]. Supported printer types: HP Deskjet (or equivalent) 2. Configure the serial printer: • 8 data bits • 1 stop bit •...

  • Page 34: Alarm Light (Optional)

    AHIBA MULTIPRECISE TC - Alarm Light (Optional) Alarm Light (Optional) Pin 3 (+) Pin 4 ( -) Instrument Connector: Amp 206430-1 Pins: Amp 66101-2 Mating Connector Connector: Amp 206429-1 Pin: Amp 66099-2 ahiba...

  • Page 36: Technical Data

    echnical Data echnical Data ahiba...
  • Page 38 AHIBA MULTIPRECISE TC – Technical Data • External dimensions: 540 x 660 x 670 mm (H x W x D) • Weight: 68 kg (150 lb) • Connections: RS 232 C for printer (data format: 8 data bits 1 stop bit no parity) Pin no.
  • Page 39 AHIBA Multiprecise TC – Technical Data Electrical voltages / power • Voltage: 230V ±10% or 380V ±10% 50/60Hz, 3 phase • Max. heating power: 2800 W • Total power input: 3300 W max. Water • Water pressure: 5 bar (72.5 psi) maximum •...
  • Page 40 AHIBA Multiprecise TC – Technical Data The following fuses are used for circuit protection: Note: Fuses must be changed by a trained technician. Power Interface Board F1 = 6.3AT F2 = 8AT Main Fuse = 8AT main 24V Unregulated Power Supply = 25AT ahiba...

  • Page 42: Procedure For Dosing

    Procedure for Dosing Procedure for Dosing ahiba...

  • Page 44: Dosing Manual Mode

    AHIBA Multiprecise Dosing - Manual Mode Dosing can be activated from manual mode or program mode. In manual mode there is only one dosing step allowed, while in program mode dosing can be activated multiple times. The MPTC dosing system is semi-automatic, this means that operator interaction is required.
  • Page 45 AHIBA MULTIPRECISE TC - Dosing Manual Mode - At this the desired dosing solution amount has been dosed out of the dosing beaker, but some of it still remains in the dosing tube. - After pressing [Esc] key or go to Run Program Menu the message below will appear.

  • Page 46: Dosing Program Mode

    AHIBA MULTIPRECISE TC - Dosing Program Mode · Single Dosing Same operation as in manual mode. · Multiple Dosing Before beginning a process: Ensure dosing tube is filled with water. Insert dosing tube in the first dosing auxiliary. Begin Process: When “Dos Start”...
  • Page 47 AHIBA MULTIPRECISE TC - Dosing Program Mode Second dosing begins (repeat steps 1-7). 10 All dosing will repeat steps (1-7) except the last dosing (steps 1-6). 1. INSERT TUBE IN 2ND SOLUTION 2. PRESS [ENTER] TO CONTINUE Fig. 3 ahiba...

  • Page 48: Calibration (Water Flow Meter)

    Calibration Calibration ahiba...
  • Page 50 AHIBA MULTIPRECISE TC - Calibration (Water Flow Meter) Water Flow Meter Calibration: A. Ensure tube is filled with water. Go to: MANUAL MODE, MANUAL FUNCTION, FILL CW 50ml to fill tube with water. B. Drain beaker. Go to: MANUAL MODE, MANUAL FUNCTION, DRAIN XXsec. Ensure the beaker lid is on to build pressure up so water is pushed out of the beaker.

  • Page 51: Calibration (Dsoing)

    AHIBA MULTIPRECISE TC - Calibration (Water Flow Meter) Calibration: A. Go to: CONFIGURATION, USER SETUP, CAL WATER FLOW B. The menu as shown below appears: PULSE / ltr 2220 EXECUTE Move cursor to EXECUTE and press [Enter]. C. Measure the water in the beaker. To measure the water, drain the water by opening the manual valve withdrawal knob.
  • Page 52 AHIBA MULTIPRECISE TC - Calibration (Dosing) General Instruction: - The dosing accuracy of fluids is dependent on the type of chemicals as well as thier stock solution concentration (specific gravity). - The Ahiba MPTC is calibrated with water at the factory. It is required for the operator to recalibrate the unit with the chemical to be used.

  • Page 54: Controller

    Controller Controller ahiba...

  • Page 56: Keypad / Display

    AHIBA MULTIPRECISE TC - Keypad / Display Process 1 Process 2 Temp > 85°C Temp > 85°C Temp > 145°C Temp > 145°C Dosing Dosing Elements above the display: (1) Process LED Flashes when a process (program) is running (2) Rotary knob Display contrast control (3) Switch Display unit selector switch...
  • Page 57 AHIBA MULTIPRECISE TC - Keypad Keys 0 and space . , ? ! - & % a b c d e f g h i j k l m n o p q r s t u v w x y z Function keys [ F ] [ Jump cursor to beginning of previous step...

  • Page 58: Activating / Programming The Unit

    AHIBA MULTIPRECISE TC - Activating / Programming the Unit Do not proceed unless the unit has been installed according to the installation instructions. Switch on the unit by pressing the power [on / off] button. The display is activated. After a few seconds the self diagnostic program is executed. The main menu is displayed.
  • Page 59 AHIBA MULTIPRECISE TC - Activating / Programming the Unit Status line Time, error and status messages are displayed in the status line. The last character of the status line indicates if a process is running. No process: ´M´ (blank) no «M», «P» or «H» blinking Manual process: ´M´...

  • Page 60: Lcd Display

    AHIBA MULTIPRECISE TC - LCD Display Error messages An error message will remain displayed until it is acknowledged by [ALARM RESET] and the fault is remedied. If more than one alarm is issued, the alarm with the greatest priority will be displayed. The current time will not be displayed until all faults are corrected.

  • Page 61: Control Functions

    AHIBA MULTIPRECISE TC - Control Functions General remarks The AHIBA MPTC controller can store up to 99 dyeing programs. Each program may contain up to 60 Time / Temp steps. Up to 99 additional programs may be stored on the memory card. Programs remain stored, even during a power failure. Limit values During programming all entries are checked against the following limits: TEMPERATURE:...
  • Page 62 AHIBA MULTIPRECISE TC - Witing a Dyeing Program General Information • The local memory can accommodate up to 99 programs. • The memory card can accommodate up to 99 programs. • A program may contain up to 60 steps. • A step consists of two types, a Function or a Process. A step for a Process consist of Temperature, Gradient, Time, Flow, and Dosing.

  • Page 63: Program Example

    AHIBA MULTIPRECISE TC - Introduction / Program Example Introduction The Multiprecise TC is a dual unit machine. Each unit runs independently and controlled by a single controller. The control function for both units can be accessed by switching the display information via the display unit selector switch.
  • Page 64 AHIBA MULTIPRECISE TC - Program Example STEP 05 TEMP 80.0°C [Enter] GRAD +4.0°C/Min [Enter] TIME 30 Min [Enter] FLOW [Enter] DOSAGE 3 DEGR [Enter] DOS DEGR [Enter] DOS START 5 Min [Enter] DOS VOL 20 ml [Enter] DOS TIME 25 min [Enter] STEP 06 DRAIN...

  • Page 65: Main Menu

    AHIBA MULTIPRECISE TC - Main Menu By positioning the cursor [ ] / [ ] at the desired command line you can branch to the following sub-menus: EDIT PROGRAM Menu for editing, deleting, copying programs. RUN PROGRAM Menu for running programs (process). MANUAL MODE Menu for editing and starting a manual process (only 1 step).

  • Page 66: Edit Program Names

    AHIBA MULTIPRECISE TC - Edit Program Menu UNIT 1 DIR PROGRAMS EDIT PROGRAM NO. _ DELETE PROGRAM NO._ DELETE ALL PROGRAMS PRINT PROG. NO_ COPY PROGRAM DIR MEM CARD LOAD FROM MEM CARD DEL MEM CARD PRG_ DEL ALL MEM CARD By positioning the cursor [ ] / [ ] at the desired command line the following...
  • Page 67 AHIBA MULTIPRECISE TC - Edit Program Menu COPY PROGRAM Copies a program from a local memory position to a different one. Call up the sub-menus by [ENTER]. DIR MEM CARD Displays the directory of the memory card. Unassigned locations = dot; assigned locations = number 1-99. Call up the function by [ENTER].
  • Page 68 AHIBA MULTIPRECISE TC - Edit Program Names The screen below is the default screen for a new program. Additional screen information will appear as program steps are added. Program Name xxxxxxxxxxxxxxxxxx ADD NEW PROCESS ADD NEW FUNCTION INSERT PROCESS 0 INSERT FUNCTION 0 DEL LAST STEP DEL STEP 0...

  • Page 69: Run Program Menu

    AHIBA MULTIPRECISE TC - Run Program Menu In the RUN PROG menu you can start or stop a program. The subsequent menu depends upon whether or not a process is running. If no process is running, the following menu is displayed: RUN PROG NO._ Start a program.

  • Page 70: Display Actual Values

    AHIBA MULTIPRECISE TC - Run Program Menu If process is running the following menu is displayed: DATA & OVERVIEW Activate the overview mode. Press [ENTER] to call up the function. DATA Display the detailed data menu. Press [ENTER] to call up the function. (See the following page: “Display Actual Values”) Terminate the current process.
  • Page 71 AHIBA MULTIPRECISE TC - Display Actual Values When the DATA menu is selected, the actual process values are displayed. This display can only be exited with [ESCAPE]. Depending upon the operating mode (M or P), the values are displayed as follows (refer to Appendix 4): No process running If no process is running, the ACTUAL temperature is displayed as follows: +___ •...
  • Page 72 AHIBA MULTIPRECISE TC - Display Actual Values Manual process (M) The following process values are displayed: +___ • _°C Actual temperature Tset +___ • _°C Set temperature of the step Time _ min Duration of Tset to be maintained GRAD +_ •...

  • Page 73: Manual Program Menu

    AHIBA MULTIPRECISE TC - Manual Program Menu In the MANUAL menu you can start and stop a 1 step dyeing process. The menu below is displayed when you enter into the MANUAL menu. MANUALPROCESS MANUAL FUNCTION MANUAL PROCESS Press [ENTER] to call up the submenu as shown below.

  • Page 74: Configuration Menu

    AHIBA MULTIPRECISE TC - Configuration Menu In this menu, you can configure your equipment to suit your application. See appendix SET TIME COMMUNICATIONS DOSAGE USER SETUP INSTALLATION SET TIME Enter the system time and date. Press [ENTER] to call up the function. To store the data press [ENTER]. COMMUNICATION Select the printer type (Epson FX80, HP Deskjet, or equivalent).
  • Page 75 AHIBA MULTIPRECISE TC - Communication Menu PRINTER BAUD RATE PRINT INTERVAL 00:00 PRINTER BAUD RATE Pressing [ENTER] on the selected field will activate the selection. The baud rate options are 300, 1200, 2400, 4800, 9600, and 19200. Use press [ENTER] to make selection. PRINT INTERVAL 00:00 This option allows actual data to be printed out via RS232 port at an interval specified by the user.

  • Page 76: Dose Verification Menu

    AHIBA MULTIPRECISE TC - Dose Verification Menu DOSE VERIFICATION RINSE DRAIN CALIBRATE DOSE VERIFICATION Menu to verify calibration result. Enter desired volume and press [Enter]. DOS VOL 0.0ml EXECUTE RINSE Used for rinsing dosing tube or fill (prime) the tube with water.
  • Page 77 AHIBA MULTIPRECISE TC - User Setup Menu BUZZER PROG END BUZZER SAFETYBOND OFFS. SEN +_._°C MAX. FILL XXXX ml CALL WATER FLOW PASSWORD SETUP LANGUAGE Buzzer ProgEnd _ Set “Beep duration” at end of program. Input value 0 = 15 sec. “Beep” Input value 1 = 15 min.

  • Page 78: Controller Messages

    AHIBA MULTIPRECISE TC - Controller Messages Action Display Info Description Limmited data that can be Stay within the limits Restricted access edited during the program. Program to be edited will be New program created as new. Program to be edited exists Old program Note the maximum No further programming steps...
  • Page 79 Process is done 1) Press [POWER] - wait 10 sec. - press [POWER] - O.K. ? - If the problem is not solved consult Datacolor “Ahiba” customer service. The nearest office can be found through the “Datacolor Worldwide Office Locator” at www.datacolor.com, or by contacting Datacolor Corporate Headquarters (609) 924-2189, and asking for customer support or email Hwsupport@datacolor.com.

  • Page 80: Error Messages

    “INFO” RANGE. tripped. STACK UNDERFLOW Internal program error. Save the programs and Battery low. Programs can be LOW BATTERY call Datacolor customer lost. support. Follow instructions on Expecting user action to Press Esc or goto the display. continue dosing operation.

  • Page 82: Protection

    Protection Protection ahiba...
  • Page 84 AHIBA MULTIPRECISE TC - Protection Excess Temperature As soon as the dye chamber sensor registers a temperature in excess of 140°C, the heater is shut off automatically and cooling water starts flowing. Excess Pressure An automatic pressure relief valve inside the unit is set to automatically release pressure at 5 bar ±...

  • Page 86: Maintenance

    Maintenance Maintenance ahiba...

  • Page 88: Cleaning

    AHIBA MULTIPRECISE TC - Maintenance / Cleaning Dye chamber Rinse the dye beaker thoroughly after each processing action. Datacolor does not recommend using brushes for manual cleaning, since brush hairs may become stuck in the drain valve resulting in leaks in the system.
  • Page 89 AHIBA MULTIPRECISE TC - Maintenance / Pump Dismantling the Body of the Pump There may be two reasons why the body of the pump may have to be dismantled. a) Cleaning of individual parts b) Replacement of worn parts To do so, use a slotted screwdriver or a coin to undo the bearing neck (1).
  • Page 90 AHIBA MULTIPRECISE TC - Maintenance / Beaker Chamber Replace Glass 1. Drain dye chamber (function DRAIN) 2. Remove protective glass (1) by pulling it 3. Use 6mm socket wrench and remove the 4 csk. hex socket screws (2) on the flange (3) above the glass cylinder.

  • Page 91: Leak Test

    AHIBA MULTIPRECISE TC - Maintenance / Leak Test Leak Test If any element has been replaced, proceed as follow: - Fill dye container up to the level of the upper glass seal. - Close the lid and build up pressure to 3 bar (function PRESSURE).

  • Page 92: Maintenance List

    AHIBA MULTIPRECISE TC - Maintenance / List Maintenance List Legend: U = User S = DCI Service Support Accessories Wash thoroughly. Machine Keep the exterior surfaces clean Dyeing Chamber Check for leaks and cracks in glass. Replace seals or glass if necessary Cooling Water Inlet, Warm Water Inlet, and drain Check that tubing is securely fastened onto plumbing nipples.

  • Page 94: Appendices

    Appendices Appendices ahiba...
  • Page 96 AHIBA MULTIPRECISE TC - Appendix 1 Main Menu Edit Program Menu EDIT PROGRAM DIR PROGRAMS RUN PROGRAM EDIT PROGRAM No.__ PRORAM NAME: MANUAL MODE DEL PROGRAM No.__ XXXXXXXXXXXXXXXXX DATA DEL ALL PROGRAMS 01 TEMP +___._°C DATA & OVERVIEW PRINT PROG No.__ 01 GRAD +_._°C/min CONFIGURATION...
  • Page 97 AHIBA MULTIPRECISE TC - Appendix 2 ahiba...
  • Page 98 AHIBA MULTIPRECISE TC - Appendix 3 Main Menu EDIT PROGRAM Manual Mode Menu RUN PROGRAM MANUAL MODE TEMP +___._°C MANUAL PROCESS DATA GRAD +_._°C/min MANUAL FUNCTION DATA & OVERVIEW TIME ___ min CONFIGURATION FLOW ___% DOSAGE 2 PROG DOS PROGR FILL CW DOS START __min...
  • Page 99 AHIBA MULTIPRECISE TC - Appendix 4 Main Menu No Running Process EDIT PROGRAM RUN PROGRAM MANUAL MODE DATA Automatic Process DATA & OVERVIEW CONFIGURATION +___._°C Tset +___._°C TIME ___min +___._°C GRAD +_._°C/min Tset +___._°C Manual Process POWER +/-___% TIME ___min FLOW GRAD +_._°C/min...
  • Page 100 AHIBA MULTIPRECISE TC - Appendix 5 Main Menu EDIT PROGRAM No Process Running RUN PROGRAM 120.0° MANUAL MODE DATA DATA & OVERVIEW CONFIGURATION 120.0° Manual/Automatic Process 180 min ahiba...
  • Page 101 AHIBA MULTIPRECISE TC - Appendix 6 ahiba...
  • Page 102 AHIBA MULTIPRECISE TC - Appendix 7 Configuration Menu SET TIME COMMUNICATION DOSAGE DOSE VERIFICATION DOS VOL 0.0ml RINSE EXECUTE USER SETUP INSTALLATION DRAIN CALIBRATE DRAIN __ml RINSE __ml Yes, press[Enter] press [ESC] Yes, press[Enter] press [ESC] CALIBRATE __._ml MEASURED __.__ml ahiba...
  • Page 103 Manufactured at: Datacolor Technology (Suzhou) Co. Ltd No. 288 Shengpu Road / Suzhou Industrial Park, Export Processing Zone B, Suzhou, Jiangsu, P.R. China Customer inquiries: Datacolor Lawrenceville, NJ 08648 Tel: 1-609-924-2189 www.datacolor.com...
