  • Page 1 2 channel 4-20mA option 2006-02-07 MANUS02/06 VER 1.00...

  • Page 2: Table Of Contents

    Damages ........................4 Packaging ......................... 4 Content ........................4 Module Overview ..................4 Mounting in the BB2 control box ..............5 Wiring Connections ....................5 Configuration ....................6 Baudrate ............. Fel! Bokmärket är inte definierat. Termination ............Fel! Bokmärket är inte definierat.

  • Page 3: Introduction

    1. Introduction The BB2 4-20mA module is used to expand the BB2 central unit with two 4-20mA loops. The user is assumed to be familiar with BB2 and 4-20mA technology. 2. A few words about this manual The manual primarily contains information about the BB2 4-20mA module. The operation and measuring principles of the sensors and the central unit is described in their respective manuals.

  • Page 4: Unpacking

    DAMAGES If damages occurred during shipment, immediately contact the shipping company and the Cerlic representative. The shipment should be returned only after an return authorization number has been issued by Cerlic or representative. PACKAGING The original packaging is designed to protect the equipment and should be used for storage or if the product must be returned.

  • Page 5: Mounting In The Bb2 Control Box

    Mounting in the BB2 control box The 4-20mA module shall be mounted in a BB2 control box. Make sure the power to the control box is switched off before mounting the module. Connect yourself and the control box chassis to protective ground before opening the antistatic package of the module to avoid static discharges that can damage the module or the box.

  • Page 6: Configuration

    7. Configuration There is no configuration neaded. - 6 -...

  • Page 7: Getting Started

    • Connect the mA loops, negative line to screw terminal 1, and 3, positive to terminal 2, and 4. • Switch on the power to the BB2 box and check that the module identifies itself in the BB2 menu under Settings / Exp.module.

  • Page 8: 10. Technical Specification For The Profibus Module

    9. Technical specification for the 4-20mA module Manufacturer Cerlic Controls AB, Sweden Name BB2 4-20mA expansion module Measurement See drawing in section 17 Enclosure NEMA4 (IP65) Weight 2.8 lbs (1,3 kg) Supply voltage 85 – 250 V AC, 50 – 60 Hz Fuse 3.15 A Slow 250V 4 x 20mm...
