5. ASSEMBLY
3#
1#
Step 1. Assemble the uprights, bottom panel with screws M6*12 as
shown.
Step 3. Insert the plastic end plugs into the uprights.
Step 5. To fix the cabinet on to the wall. Mark the wall out before
drilling the hole, after the wall has been marked drill a hole the size
required as illustration, Insert the wall plug 8*40.
© Jack Sealey Limited
5#
4#
Option 1
7#
Original Language Version
Step 2. Assemble the top panel with screws M6*12.
Step 4. To fix on the wall, mark the wall according to the hole which
is at the back of top panel, after assembly.
Step 6. Fix the cabinet to the wall using the self-tapping screw
ST4.8*30.
3#
Hole
6#
APMRT2 Issue 1 24/06/24
Hole
