Sealey APMRB3 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this product.
‰
Locate product in a suitable working area.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
WARNING! Use product on level and solid ground, preferably concrete. Avoid tarmacadam since the product may sink into the surface.
‰
Keep the product clean and tidy in accordance with good workshop practice.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT use the product for any purpose other than that for which it is designed.
8
DO NOT exceed maximum capacity of product.
8
DO NOT undertake work on the product without the work piece being adequately secured. Use clamps or a vice (not included) to secure the
8
work piece. Available from your Sealey stockist.
DO NOT use the product out of doors.
8
DO NOT get the product wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT clean the product with any solvents which may damage the paint surface or the protective coating.
8
2. INTRODUCTION
The Sealey modular racking system is finished with a heavy-duty textured powder coat to prevent against rusting. Simply choose
your base, middle and top units and push together using nylon connectors to create versatile storage for the workshop, garage, home
or office. All drawers have ball-bearing drawer slides for smooth operation and cupboard doors are fitted with spring loaded hinges
allowing them to be fitted the side that suits your environment. Buy individually (see specific model number for full specs) or as one of
our pre-created combo's.
3. SPECIFICATION
Model no:
Nett Weight:
Overall Size (W x D x H):
Shelves:
4. CONTENTS
Item Part Description
1 APMRB3-01 Panel, Left Side
2 APMRB3-02 Panel, Right Side
3 APMRB3-03 Top Panel (Bottom Panel)
4 APMRB3-04 Back Panel
5 APMRB3-05 Shelf
6 APMRB3-06 Door
7 APMRB3-07 Skirting board
8 APMRB1-07 Plastic End Plug
9 MSP612.S Machine Screw Pan Head Phillips M6 x 12mm
12 MSP410.S Machine Screw Pan Head Phillips M4 x 10mm
13 APMRB1-11 Plastic Connector
14 APMRB3-14 Lock
-- APMRB1-09 Self-Tapping Screw ST4.8 x 30mm (Not Shown)
-- APMRB1-10 Expansion Plug M8 x 40mm (Not Shown)
© Jack Sealey Limited
MODULAR RACKING BASE CUPBOARD UNIT
580MM
MODEL NO:
APMRB3
20.1kg
580 x 340 x 991mm
3
Original Language Version
APMRB3
13
1
14
6
8
9
3
7
12
APMRB3 Issue 2 03/07/24
4
2
5
