MULTI DISPLAY
MONITOR ID
IR CONTROL
NORMAL
PRIMARY
SECONDARY
LOCK
TILE MATRIX
H MONITORS
V MONITORS
POSITION
TILE COMP
ENABLE
POWER ON DELAY
POWER INDICATOR
MULTI DISPLAY RESET
DISPLAY
POWER SAVE
PROTECTION
All inputs except for TV
STANDBY MODE
Not Available
HEAT STATUS
FAN CONTROL
SCREEN SAVER
GAMMA
BRIGHTNESS
MOTION
SIDE BORDER COLOR
AUTO BRIGHTNESS
DVI, VGA, RGB/HV inputs only
CHANGE SECURITY
PASSWORD
SECURITY LOCK
DDC/CI
DISPLAY PROTECTION
RESET
Sets the monitor ID number from 1-26.
Selects the mode of the monitor for use with the infra-red remote control when using the
RS-232C daisy chain.
The monitor will be controlled normally by wireless remote controller.
Choose "PRIMARY" for the first monitor within an RS-232C daisy chain.
Choose "SECONDARY" for all subsequent monitors within an RS-232C daisy chain.
Prevents the monitor from being controlled by wireless remote controller. To return to normal
operation, press the "DISPLAY" button on the remote controller for 5 seconds.
Allows one image to be expanded and displayed over multiple screens (up to 25) through a
distribution amplifier.
Number of monitors arranged horizontally.
Number of monitors arranged vertically.
Select which section of the tiled image to be displayed on the monitor.
Turns the TILE COMP feature on.
Enables Tile Matrix.
Adjusts the delay time between being in "standby" mode and entering "power on" mode.
"POWER ON DELAY" can be set between 0 and 50 seconds.
Turns ON or OFF the LED located at the front of the monitor.
If "OFF" is selected, LED will not light when the LCD monitor is in active mode.
Resets the following settings within the MULTI DISPLAY menu back to factory setting:
MONITOR ID, IR CONTROL, TILE MATRIX, POWER ON DELAY.
Sets how long the monitor waits to go into power save mode after a lost signal.
Note: When connecting DVI, video card might not stop sending digital data even if image has
disappeared. In this case the monitor does not get to power management mode.
Lowers power consumption.
Displays status of the COOLING FAN, BRIGHTNESS and TEMPERATURE.
Cooling fan reduces the temperature of the display.
Use the SCREEN SAVER function to reduce the risk of Image Persistence.
The display gamma is changed and fixed when "ON" is selected.
The brightness is decreased when "ON" is selected.
The screen image is slightly expanded and moves in 4 directions (UP, DOWN, RIGHT, LEFT)
at user determined intervals.
Adjusts the color of the side borders when a 4:3 image is displayed.
Press + button, the bar will become lighter.
Press - button, the bar will become darker.
Adjusts the brightness level according to the input signal.
Allows the security password to be changed.
The factory preset password is 0000.
Locks the security password.
ENABLE/DISABLE: Turns On or OFF the two way communication and control of the monitor.
Resets the following settings within the DISPLAY PROTECTION menu back to factory setting:
POWER SAVE, FAN CONTROL, SCREEN SAVER, SIDE BORDER COLOR,
AUTO BRIGHTNESS.
English-30
